Copernicus BTHC2 Manual de usuario
BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
Please Recycle
Chart Caddy Center Premium
Assembly Guide
BTHC2_2013_A
Check out our other products online at
www.copernicused.com
?This product is meant to be assembled by an adult.
?In its unassembled state, small parts present a hazard.
?To be used under direct supervision of an adult.
WARNING
For assistance, please contact us:
1-800-267-8494
Email [email protected]
Have your packing slip ready for reference
Don’t forget to check out our tips for your whiteboard at:
www.copernicused.com
Page Paw (2)
Not Shown
Loop Hook (2)
Front Frame With
Whiteboard (1)
Ultra Safe
Book Ledge (1)
#PABL30
2” Twin Wheel Caster
with Brake (4)
Book Display
Rack (1)
#31041
Needs Assembly
Telescoping Arms
(left & right) (1 each)
Open Tub (4)
Chart Caddy (10)
Pencil Basket (1)
Bottom Rack (2)
Hidden
Hang Tags (100)
Not Shown
Knob (2)
“S” Hook (2)
BTHC2
BTHC3
Chart Caddy
Stretcher (1)
Short Bend Arm (2)
Back Frame (1)
Long Bend Arm (2)
Bottom Stretcher (1)
BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
Bottom Whiteboard
Stretcher
1x
FM6 Acorn Nut
10x
Contents - Box 1
M6x35mm Bolt
8x
Allen Key
(Not to Scale)
1x
Before beginning, you should have:
Additional tools required:
Rubber Mallet
Contents - Box 2
Pencil Basket (#1607)
1x
Book Display Rack
(#31041)
needs assembly
1x
Open Tub
4x
(CC4068)
10 lbs Weight Limit
M6 Lock Washer
22x
M6x45mm Bolt
4x
Chart Caddy Center - Premium Parts
Front Frame with
Whiteboard
1x
Back Frame
1x
Long Bend Arm
2x Short Bend Arm
2x
2” Twin Wheel
Caster with brake
4x Chart Caddy
Stretcher
1x
Knob
2x
M6x15mm Bolt
10x
M6x20mm Bolt
8x
Bottom Rack
2x
Ultra Safe Book Ledge
1x
(PABL30)
Loop Hook
2x
“S” Hook
2x
Page Paw
2x
A
B
C
D
E
M6 Lock Nut
8x
G
BTHC2
Hardware
Actual Size
Chart Caddy
10x
Hang Tags
100x
Telescoping Arms
1x Right
1x Left M6 Nut
4x
H
BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
lThis symbol denotes a 2 Person Task. For safety, please ensure that there are two people
working on steps displaying this symbol
lWatch for this symbol throughout the Assembly Instructions. Wherever you see it, pay close
attention. The symbol denotes a step needing extra attention to ensure it is done correctly.
lThe Star symbol highlights an advisory note
Tips for Assembly - Using this Manual
2 Person
Watch for These Helpful Symbols
Before You Begin
As You Assemble the Unit
Layout and identify all of the included parts
l
The hardware has been packed by step
l
Read the assembly instructions over once to familiarize yourself with them
l
Please note that in its unassembled state, this product contains parts that can be a hazard
l
to small children; it should be assembled by an adult.
lFollow the steps in sequence
lBefore beginning each step, find the part(s) that you need for that step
lPay attention to the labeling on the parts, they are there to help direct you at certain stages
lThe title of each step states what you will be doing. Review the text and the pictures as you
build the unit.
After Assembly; Before Use
lRemove the plastic film from the Whiteboard before writing on it
To validate your warranty submit the ON-LINE form at www.copernicused.com
Validate Your Warranty On-Line
Don’t forget to check out our tips for your whiteboard at:
www.copernicused.com
Life
Time
Parts
Warranty
Life
Time
Frame
Warranty
BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
1
Secure Whiteboard in Place
You will need: (Not to Scale)
Actual Size:
2
Install Short & Long Bend Arms
You will need: (Not to Scale)
Actual Size:
Front Frame with Whiteboard
1x
Short Bend Arm
2x
M6x35mm Bolt
x 2
M6 Lock Washer
x 2
Long Bend Arm
2x
H
E
D
M6x45mm Bolt
x 4
M6 Lock Washer
x 4
M6 Nut
x 4
C E
For easy assembly build
the unit on its side
D E H
1 2
EC
Bottom Whiteboard Stretcher
1x
BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
3
Install Back Frame
You will need: (Not to Scale)
Actual Size:
4
You will need: (Not to Scale)
Actual Size:
Back Frame
1x
M6 Lock Washer
x 4
M6x35mm Bolt
x 4
2” Twin Wheel Caster with Brake
4x
C E
C
E
Install Casters
Press Casters firmly into the Base:
?Casters will click into place
?If necessary, tap the caster in using a
rubber mallet.
BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
5
You will need: (Not to Scale)
Actual Size:
6
You will need: (Not to Scale)
Actual Size:
Chart Caddy Stretcher
1x
M6x35mm Bolt
x 2
M6 Lock Washer
x 2
TelescopingArms (left & right)
1x Knob
2x
Install Telescoping Arms & Knobs
Note the hooks face
the back of unit
Tightening the knobs will
stop the arms from sliding.
Loosen knobs to adjust.
C E
Install Chart Caddy Stretcher
EC
CE
Note the orientation of bend is
toward the front of unit
TIGHTEN ALL FASTENERS.
BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
7
Assemble Book Display Rack
You will need: (Not to Scale)
Actual Size:
Rack 1
Rack 2
Rack 3
Rack 4
Rack 5
Top Rack
Main Rack
AF
Tip, work from largest
to smallest rack
1
2
3
4
5
M6x15mm Bolt
x 10
A
M6 Acorn Nut
x 10
F
Bolt is threaded through
the rear of the back frame.
Tighten bolts securely.
x 10
M6 Lock Washer
E
E
Hook bottom first then
bolt.
BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
8
You will need: (Not to Scale)
Actual Size:
9
You will need: (Not to Scale)
Actual Size:
Install Book Display Rack
Book Display Rack
1x
B
G
M6x20mm Bolt
x 8
M6 Lock Nut
x 8
Bottom Rack
2x
Install Bottom Racks
Top of
Rack
Bottom of
Rack
Note wire is on top
BG
BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
10
You will need: (Not to Scale)
Actual Size:
11
You will need: (Not to Scale)
Actual Size:
Install Tubs
10 lbs Weight Limit Open Tub
4x
Ultra Safe Book Ledge
1x
Install Book Ledge
Please note that the spring tension
is designed to discourage children
from unhooking Book Ledge.
There are a number
of positions to
choose from.
BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
12
You will need: (Not to Scale)
Actual Size:
Install Loop Hook & “S” Hooks
Tip, to avoid scratching the
frame place an empty hardware
bag over the frame. Simply
remove when finished.
13
You will need: (Not to Scale)
Actual Size:
Attach Page Paws, Chary Caddies, & Pencil Basket
Loop Hook
2x
“S” Hook
2x
Chart Caddy
10x Pencil Basket
1x
Page Paw
2x
Don’t forget to check out our tips for your whiteboard at:
www.copernicused.com
Don’t forget to peel off
your protective film
from your whiteboard.
