Cooper CF2000 Manual de usuario
CF2000
INSTALLATION MANUAL
Wheatley Hall Road
Doncaster
South Yorkshire
DN2 4NB
Tel 01302 321 541
www.cooperfire.com Assessed to ISO 9001:2000
Certification number 714h/02
Document Drg Ref PR200-50-502-20
QUALITY
MANAGEMENT
0832 – CPD – 1089
EN54-2 1997 & A1;2006
EN54-4:1997 & A1;2002 A2:2006
Approved to
P 8
Introduction to the Manual
CF2000
Analogue Addressable Fire Detection System
This manual provides information on the installation, operation and
maintenance of the Cooper Fire Systems CF2000 System.
NOTICE
The operating system of the CF2000 may be revised as a result of
enhancements to the system software or hardware. Revisions to this
manual will be issued and supplied on request and should be logged
in the table supplied on the contents page.
Introduction
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE
DISPOSE OF THE USED BATTERIES ACCORDING
TO THE INSTRUCTIONS ( Appendix Page 92 )
Contents
Contents Page
1.0 System Design & Installation 5
Introduction 6
Project Planning 7
System Design Guidelines 8
Compatible Equipment 9
Detectors 10
Call Points 14
Sounders 16
Interfaces 17
3 Channel I/O 17
1 Channel I/O 17
Zone Monitor Unit 18
Shop Unit Interface 18
Spur Isolater 19
4 Way Sounder Circuit 19
20
21
24
26
28
Equipment Compatiblity
System Overview
Technical Specification
Optional Functions
External Connections
Installation 29
Fixing details 30
System Wiring 31
2.0 Commissioning CF2000 33
Commissioning Software 34
Panel Fault Finding 38
Protocol 39
3.0 Panel Controls and Indicators 40
41
42
43
44
44
46
47
48
50
51
52
Panel Controls and
Indicators System Healthly
View Event
Fire Event
View Fires
View Pre-Alarm
View Fault
View Disabled Address View
Disabled Zone
View Disabled I/O
View Log
Operations
Soft Reset 53
Evacuate 54
Silence Alarms 55
Lamp Test 56
Weekly Test 57
Contents
Contents Page
Access Level 2
Commissioning 59
Panel Settings
Erase Log 60
Change Password 61
Change Lanuage 62
Date Time 63
System Details 64
Testing
Testing Device 65
Test Zone 66
Test Sound Levels 67
One Man Walk Test 68
Global Flashing LED 69
Analogue Levels 70
Device Config
71
72
Add Device
Delete Device
4.0 Appendix 73
74
75
76
77
78
79
80
81
82
83
84
85
86
Spur Isolator
4 Way Sounder Controller
Zone Monitor Unit
Shop Monitor Unit
1 Way Input Output Unit
Sensor Base Wiring
System Wiring
IP66 Wall Sounder
Internal Wall Sounder
Base Sounder Wiring
3 Way Input Output Unit
Loop Powered Beacon Call
Point
CE Marking
Battery Disposal Instructions
87
88
System Installation and Design
Section 1
5
Introduction
CF2000 provides all of the sophisticated features required of a leading edge analogue
addressable fire system along with the simple operation and neat installation
demanded by installers and building users.
The panel can be flush or surface mounted and the generously sized metal back box
allows ample facilities for rear or top cable entries.
It is available as a two loop panel with or without an integral printer.
A comprehensive range of ancillary devices is available to operate with the CF2000
panel, including Optical, Ionisation, photo-thermal and heat sensors, callpoints and a
comprehensive range of interfaces.
Each of the CF2000 system components has been specifically designed to operate as
part of a CF2000 system, this provides an assurance that the panel, the sensor, the
interfaces and the ancillaries are all fully compatible with each other and that the full
range of system functionality is supported by each device.
Each loop of a CF2000 panel can accommodate up to 200 (99 Belgium) addresses.
6
Project Planning
The following is a typical program and timetable for a CF2000 installation project, once
the initial order has been received:
1. Project Meeting
Installer and user to be present; system specifications, schematic diagram and
proposed circuit drawing to be available. CF2000 Installation & Commissioning
Guide to be provided.
2. Equipment Fix
Typically 2 week's notice is required for equipment to be delivered. Cable to be
installed and bases/back boxes to be fitted. Then fire sensors, call points, alarm
sounders and interface units can installed.
3. Address Schedule
Schedule of sensor locations to be completed by installer and returned to enable
System programming.
4. Auto Learn
Fire panel/repeater panels to be installed and terminated. System to be powered
up by installer and auto learn mode activated (see Auto Learn section). System
to be tested and verified by installer, prior to final commissioning.
5. Final Commissioning
Minimum 2 weeks notice is required from receipt of Address Schedule and
Commission request form for a Cooper Fire Systems Service Engineer to attend
site to implement/oversee the final commissioning procedures (see
Commissioning section), in conjunction with the installer.
7
Guidelines
Systems should to the relevant local standards and codes of practice, for the UK this is
BS5839 part 1. CF2000 meets all the relevant requirements of BS5839 part 1: 2002.
Installation planning is simplified by the fact that every addressable CF2000 device contains an
integral short circuit isolator. Care must be taken to ensure that local standards requirements
regarding aspects such as loop coverage, area covered by a single spur and cable
specification are observed.
There may be certain applications in which deviations from the code may be necessary and
these must be listed on the commissioning certificate. (See commissioning section)
Loop lengths
The maximum permitted loop length is 2 km measured from the near to the far terminals on the
CF2000 Motherboard PCB. There is no minimum limit to loop length. Any wiring spurs off the
loop must be included within the 2 km limit. On long loop runs, the lengths of wiring rises and
falls (between floors, down to manual call points) must be included. Remember to include
these especially when taking loop lengths from plan drawings.
Loop loading - total number of addresses
The total number of addresses per loop is 200 (99 Belgium). this includes detectors, call points
and all other addressable items and call points. When designing systems its recommended
that allowances are made for future expansion, Short circuit isolators are incorporated into
every CF2000 loop device, including Smoke detectors, heat detectors, sounders, callpoints
and interfaces. Therefore, no further fault protection is required , in the event of a single fault,
none of the devices connected to the loop will fail to operate as the fault will be isolated by the
two adjacent devices.
Spur connected devices downstream of a cable fault will cease to function.
System Design Guidelines
8
Compatible Equipment
Addressable Call Points
CBG370 Addressable call point - Flush 85(H) x 85(W) x 30(D)
CBG370/S Addressable call point - Surface 85(H) x 85(W) x 53(D)
CBG370/W P W eatherproof addressable call point 108(H) x 108(W ) x 65(D)
Ana logue Se nsors
CAH330 Analogue heat detector 101 Dia x 43(D)
CAP320 Analogue optical smoke detector 101 Dia x 33(D)
CAI310 Analogue ionization smoke detector 101 Dia x 33(D)
CAPT340 Analogue photo/thermal dual detector 101 Dia x 43(D)
CAB300 Common mounting base 104 Dia x 22(D)
Addressable Interface s
CSI350 Spur Isolator 85(H) x 145(W ) x 58(D)
CIO351 3 Channel I/O Unit 130(H) x 180(W ) x 60(D)
CZMU352 Zone Monitor Unit 85(H) x 145(W ) x 58(D)
CMIO353 230v Relay I/O Unit 130(H) x 180(W ) x 60(D)
CSC354 4 W ay Sounder Controller 300(H) x 300(W ) x 74(D)
CSUM355 Shop Unit Monitor 130(H) x 180(W ) x 60(D)
Addressable Sounders and Beacons
CAS380 Loop Mounted Base Sounder 102 Dia x 40(D)
CAS381 W all Sounder 105(H) x 105(W ) x 95(D)
CAS381/W P W all Sounder - weatherproof 110(H) x 110(W ) x 105(D)
CAB382 Loop Mounted Beacon 93 Dia x 53(D)
CASBB384 Loop Mounted Base Sounder/Beacon 115 Dia x 35(D)
CASB383 Wall Sounder/Beacon 106(H) x 106(W ) x 91(D)
CASB383/WP W all Sounder/Beacon IP66 110(H) x 110(W ) x 100(D)
Conventional Ca ll Points
CBG375 Flush mounting call point 87(H) x 87(W) x 20(D)
CBG375/S Surface mounting call point 87(H) x 87(W) x 53(D)
CBG376 W eatherproof surface call point 110(H) x 110(W ) x 65(D)
Conventional De tectors
CPD320 Photoelectric smoke detector 101 Dia x 33(D)
CID310 Ionization smoke detector 101 Dia x 33(D)
CPT340 Combined photo/thermal detector 101 Dia x 43(D)
CFR330 Fast response heat detector 101 Dia x 43(D)
CMT360 Medium response heat detector 101 Dia x 43(D)
CHT390 High temperature heat detector 101 Dia x 43(D)
CDBB300 Common mounting base 104 Dia x 22(D)
Conventional Sounders
AC/R 24V flush mounting electronic sounder 86(H) x 86(W) x 42(D) *
CXBB/R Surface mounting back box for AC/R
SY/R 24V low current sounder 105(H) x 105(W ) x 95(D)
SQ/R Base sounder 112 Dia x 30(D)
ROLP/R/S Electronic sounder - shallow base for indoor applications 93 Dia x 75(D)
ROLP/R/D Electronic sounder - deep base (W eatherproof) 93 Dia x 105(D)
Conventional Sounder/Bea cons
FL/RL/R/D Combined sounder/beacon deep base 93 Dia x 92(D)
FL/RL/R/S Combined sounder/beacon Shallow base 93 Dia x 121(D)
9
CPD320 Conventional Photoelectric Detector, this is the
most commonly used detector and is most suitable for
detecting slow burning fires.
The range of compatible detectors for the CF2000 system consists of the following:
CPT340 Conventional Photo/thermal Detector, this is a
new addition to the Cooper Fire Systems range of
detectors. It is the ideal detector for a multi-use
environment as it has an excellent response to
smouldering and fast burning fires.
CMT360 77°C Fixed Conventional Heat Detector,
Heat detectors are suitable for dusty environments or
environments where smoke is likely to be present under
normal operating conditions.
Compatible Equipment Conventional Devices
Model CID310 CPD320 CFR330 CMT360 CHT390 CPT340
Operating voltage
Standby current (max) 70µA
Start-up Current (max 20 seconds) 340µA
Alarm current (max) 20mA
Ambient Temperature (max) 45ºC 60ºC 75ºC 75ºC
Ambient Temperature (min)
Alarm temperature (static) 60ºC 77ºC
Heat detector class
as defined by EN54-5:2000
Radioactive material/strength Am 18.5KBq
Relative humidity (non cond)
Height (w/o base)
Height (with base)
Diameter
Weight (w/o base) 86g 78g 78g
Material
Colour
76g
15 to 30V dc
25mA
30µA
210µA N/A
47mm 56mm
100mm
N/A
N/A
60ºC
-20ºC
34mm
White
90ºC
N/A
0 to 95%
43mm
A2R BS CS A2S
PC/ABS
10
