Cooper Lighting Corelite JAYLUM Manual de usuario

1Fold in tabs for corresponding

mounting method.

1Remove Top Lens and Reector

2Using provided Hardware secure xtures to MOUNTING BRACKET,

and connect xtures together as shown.

3Re-Install Reector and Top Lens

Fold Tab A if xture to be joined to another xture (row).

Make electrical connections and tuck wires into wire cavity

prior to hanging xture on mounting bracket.

#10-32 Screw

Hardware should be positioned

at bottom of keyhole slot and

tightened securely.

#10-32 Nut

#10 Star Washer

Fold Tabs B and C if xture to be mounted as single unit

or if xture is at end of row.

See Page 1 Mounting Bracket Specications and Dimensions.

INSTALLING FIXTURES

ROW MOUNTING

WALL LED Luminaire

INSTALLATION

JAYLUM

ADE130028

REFLECTOR

TOP LENS

Wire xture to requirements following all

National and Local Electrical Codes.

Tuck wires back into xture.

Hang Fixture on MOUNTING BRACKET

and secure with included fasteners.

Pull wires from J-Box thru end of xture

for easy wiring while xture is hanging.

WALL LED Luminaire

MOUNTING BRACKET

USE ONLY HORIZONTALLY

MOUNTED 2x4” J-BOXES (by others)

AT POWER LOCATIONS.

MOUNT NON-POWER LOCATION

BRACKETS TO STRUCTURE.

INSTALLATION OF MOUNTING BRACKETS

SAVE THESE INSTRUCTIONS

INSTALLATION

JAYLUM

ADE130028

WARNINGS

1) WARNING! – Risk of Fire/Electric Shock. Disconnect power at fuse or circuit breaker before installing or servicing.

2) WARNING! – Risk of Fire/Electric Shock. If not qualiﬁied, consult an electrician.

3) WARNING! – Avoid contact with LED modules.

NOTES

1) NOTE! – This product must be installed in accordance with local/ national electrical codes.

2) NOTE! – Only those open holes indicated in the photographs and/or drawings may be made or altered as a result of kit installation. Do not leave any other open holes in an

enclosure of wiring or electrical components.

3) NOTE! – To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or any sharp objects.

4) NOTE! – Disconnect all power before proceeding.

Mounting For Single Fixture

Mounting For Beginning or End Of Row

END

4’

8’

4’

8’

4’

8’

END

43.0” [1092 mm]

91.0” [2311 mm]

45.5” [1156 mm]

93.5” [2375 mm]

Mounting For Middle Of Row

48.0” [1219 mm]

96.0” [2438 mm]

Install provided fasteners fully, then back out 1/4 turn.

Loosen or Tighten as necessary to ensure a

tight t when END CAP is installed.

Fit END CAP fasteners into KEYHOLE SLOTS.

- THIS SPACE INTENTIONALLY LEFT BLANK -

END CAP

INSTALLING END CAPS

WALL LED Luminaire

INSTALLATION

JAYLUM

ADE130028

KEYHOLE SLOTS

SUPPORT FIXTURE

Press END CAP downward to snap into position.

Ensure xture is securely supported while

installing END CAP.
