ControlFreq QUICK-FIT Manual de usuario
QUICK-FIT
COMPACT GSM INTERCOM SYSTEM
INSTALLATION MANUAL
Version: QUICK-FIT GSM-Installation-Manual_v1.6
QUICK‐FITGSMINSTALLATIONMANUAL
Page2
Contents
1FOR YOUR SAFETY................................................................................................................................................5
2INTRODUCTION ......................................................................................................................................................6
3FEATURES AND APPLICATIONS...........................................................................................................................7
4START UP ................................................................................................................................................................8
5LED DISPLAY...........................................................................................................................................................9
6CLEAR ALL PROGRAMMED DATA FROM SIM ...................................................................................................10
7CONNECTION DIAGRAM ......................................................................................................................................11
8PROGRAMMING QUICK-FIT GSM........................................................................................................................12
9THE QUICK-FIT GSM PARAMETERS...................................................................................................................13
9.1 ALARM SUPPORT...............................................................................................................................................................13
9.2 OUTPUT MANAGEMENT ...................................................................................................................................................17
9.3 SECURITY LEVEL -SL........................................................................................................................................................18
9.4 SET-UP PARAMETERS.......................................................................................................................................................21
9.5 SMS MESSAGES EDITOR....................................................................................................................................................24
9.6 INTERCOM.........................................................................................................................................................................25
9.7 CLIP....................................................................................................................................................................................28
9.8 EVENT LOGGING..............................................................................................................................................................30
9.9 SPECIAL SMS COMMANDS......................................................................................................................................................31
10 PRINT-OUT OF THE PARAMETERS....................................................................................................................33
10.1 RECEIVE ALL PARAMETERS (PALL)..................................................................................................................................33
10.2 CHECK SW REVISION (PSW).....................................................................................................................................................33
10.3 CHECK SIGNAL QUALITY (PSQ)..................................................................................................................................................33
10.4 RECEIVE TELEPHONE NUMBERS (PTN)...........................................................................................................................33
10.5 RECEIVE LINKS (PLN)........................................................................................................................................................33
10.6 RECEIVE INPUT PARAMETERS (PIN)................................................................................................................................33
10.7 RECEIVE INPUT FILTER VALUE (PID)...............................................................................................................................34
10.1 RECEIVE INPUT FILTER VALUE (POD).............................................................................................................................34
10.2 RECEIVE DELAY BEFORE DIAL VALUE (PDD)...................................................................................................................34
10.3 RECEIVE ACCESS TELEPHONE NUMBERS (PSL)..............................................................................................................34
10.4 RECEIVE OUTPUT PARAMETERS (POS)...........................................................................................................................34
10.5 RECEIVE ALL PROGRAMMED SMS MESSAGES (P#)..........................................................................................................34
10.6 RECEIVE SET UP PARAMETERS VALUE (PPA)..................................................................................................................34
10.7 RECEIVE CREDIT PARS PARAMETERS (PCREF).............................................................................................................................35
10.8 RECEIVE ALL CLIP PARAMETERS (PCLP)..........................................................................................................................35
10.9 RECEIVE INTERCOM BUTTON 1PARAMATERS (PDEA)...................................................................................................................35
10.10 RECEIVE INTERCOM BUTTON 2PARAMATERS (PDEB)..............................................................................................................35
10.11 RECEIVE INTERCOM BUTTON 3PARAMATERS (PDEC)..............................................................................................................35
10.12 RECEIVE INTERCOM BUTTON 4PARAMATERS (PDED)..............................................................................................................36
10.13 RECEIVE INTERCOM BUTTON 5PARAMATERS (PDEE)..............................................................................................................36
10.14 RECEIVE INTERCOM BUTTON 6PARAMATERS (PDEF)..............................................................................................................36
QUICK‐FITGSMINSTALLATIONMANUAL
Page3
10.15 RECEIVE INTERCOM BUTTON 7PARAMATERS (PDEG)..............................................................................................................36
10.16 RECEIVE INTERCOM BUTTON 8PARAMATERS (PDEH)..............................................................................................................36
10.17 STATE OF THE CREDIT FOR THE PREPAID CARD.......................................................................................................36
10.18 STATE OF THE OUTPUTS (PORC)...............................................................................................................................37
10.19 MANUAL GSM MODULE RETARD (MRES).....................................................................................................................37
10.20 RECEIVE STATUS OF INPUTS (INS).....................................................................................................................................37
10.21 RECEIVE QUICK-FIT GSM LOG.....................................................................................................................................37
11 CHANGING PARAMETERS USING THE SMS COMMAND...................................................................................38
12 DEFAULT SETTINGS ON QUICK-FIT GSM .........................................................................................................39
13 TECHNICAL SPECIFICATION...............................................................................................................................43
14 CONTROL FREQ GSM...........................................................................................................................................44
QUICK‐FITGSMINSTALLATIONMANUAL
Page4
Figures
Figure 1: Enclosures options .....................................Error! Bookmark not defined.
Figure 2: QUICK-FIT GSM Connection diagram .................................................. 11
Figure 3: Input Connection diagram .............................................................. 13
Figure 4: Output Connection diagram............................................................ 17
Tables
Table 1: IN, ID and DD parameters................................................................ 14
Table 2: IN, ID, DD parameters example......................................................... 14
Table 3: Remote alarm reporting parameters .................................................. 16
Table 4: Remote alarm reporting example ..................................................... 16
Table 5: DTMF control example ................................................................... 17
Table 6: Output management parameters....................................................... 18
Table 7: Output management parameters example ........................................... 18
Table 8: SL parameter .............................................................................. 19
Table 9: SL example................................................................................. 19
Table 10: Prepaid card validity parameters..................................................... 20
Table 11: Credit example .......................................................................... 20
Table 12: Set-up parameters. ..................................................................... 22
Table 13: Set-up parameters example. .......................................................... 23
Table 14: Message parameters. ................................................................... 24
Table 15: Message parameters example. ........................................................ 24
Table 16: Intercom parameters. .................................................................. 27
Table 17: Intercom parameters example. ....................................................... 27
Table 18: CLIP parameters......................................................................... 28
Table 19: CLIP parameters example.............................................................. 29
Table 20: LOG parameters. ........................................................................ 30
Table 21: LOG parameters example.............................................................. 30
Table 22: SMS commands........................................................................... 32
Table 23: SMS commands example................................................................ 32
Table 24: QUICK-FIT GSM default settings....................................................... 42
QUICK‐FITGSMINSTALLATIONMANUAL
Page5
1FOR YOUR SAFETY
Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user
guide for further information.
SWITCH ON SAFELY
Do not switch the unit on when use of wireless phone is prohibited or when it may cause interference or
danger.
INTERFERENCE
All wireless phones and units may be susceptible to interference, which could affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the unit off near medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in aircraft.
SWITCH OFF WHEN REFUELING
Do not use the unit at a refueling point. Do not use near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the unit where blasting is in progress.
USE SENSIBLY
Use only in the normal position as explained in the product documentation. Do not touch the antenna
unnecessarily.
QUICK‐FITGSMINSTALLATIONMANUAL
Page6
2INTRODUCTION
QUICK-FIT GSM is a simple GSM intercom communication system that is designed to
ensure low-cost, reliable and single box solution for intercom application. It is designed
for unlimited range, wire free GSM intercom and Caller ID remote control.
In addition QUICK-FIT GSM supports alarm detection, stay-alive (SIM) messages, low
credit alert, unauthorised access attempt and various other alerts…
QUICK‐FITGSMINSTALLATIONMANUAL
Page7
3FEATURES AND APPLICATIONS
Features:
⇒Built-in 2 or 4 band GSM module
⇒Up-to 4 buttons call support
⇒2 alarm inputs, 2 additional on extension connector
⇒2 outputs ( relay supported ), 2 additional on extension connector
⇒Up to 100 telephone numbers for CLIP support
⇒Programming by USB SIM Key editor
⇒Download programming by SMS command
⇒Anti-tampering input
Applications:
⇒Single box, wire free intercom solution
⇒Remote gate opener (CLIP)
⇒Simple alarm support
QUICK‐FITGSMINSTALLATIONMANUAL
Page8
4START UP
⇒Insert SIM card to be used for QUICK-FIT GSM into a mobile phone that allows the
use of the network the SIM card is on. Make sure the SIM card works before you
start!!!
IMPORTANT
ERASE THE PIN CODE IF THE PHONE ASKS!
⇒Insert SIM card in QUICK-FIT GSM device. The unit must be switched OFF when you
insert the SIM!
⇒Connect alarm inputs if you need & relay outputs to gates / doors etc
⇒Connect the antenna to antenna connector
⇒Connect power supply (12-24V AC or DC) to QUICK-FIT GSM
⇒Wait until LED3 display is turned ON (green) and LED1 (blue) starts flashing. This
is usually set within 30 secs or less
⇒You will hear a beep every 10 secs while it looks for the network and 3 quick
beeps when it connects
⇒QUICK-FIT GSM unit is now ready to use
IMPORTANT
Before sending any SMS commands to QUICK-FIT GSM device, you must wait for
it to connect
QUICK‐FITGSMINSTALLATIONMANUAL
Page9
5LED DISPLAY
GREEN LED (LED1)
-Indicates the level of the GSM signal from 1 to 5 LED flashes (1 is weak signal, 5 is
excellent signal)
Red LED (LED2)
-When LED 2 is ON the unit has a problem with a GSM network connection or the
GSM part of the unit is out of order. In this case immediately call the service!
Yellow LED (LED3)
-Short flashing indicates that the GSM module is ON, but it is not yet connected on
the GSM network. After connection, yellow led is flashing with short pulse ON and
a long pulse OFF.
QUICK‐FITGSMINSTALLATIONMANUAL
Page10
6CLEAR ALL PROGRAMMED DATA FROM SIM
This is highly recommended when a SIM card you are going to use for the QUICK-FIT GSM
is not new and it already has some data stored in the phone book memory.
By sending this SMS to QUICK-FIT GSM all programmed parameters and numbers are
cleared:
;SDCLR;
After sending SMS you should wait at least 30 seconds for the command to be executed!
NOTE
By sending this command to the QUICK-FIT GSM all programmed data are
erased from the SIM card!
After the unit boots up again (3 quick beeps), send ;SSRES; which resets it and clears
any old data from the memory.
