Continuous Computing Corp. Page 1 File: CC00313-00
San Diego, CA Dual Feed DC Telecom Power Supply User’s Guide Last saved: 2/12/01 4:57 PM
Dual Feed DC Telecom
Power Supply
Installation and User’s Guide
9380 Carroll Park Drive
San Diego, CA 92121-2256
858-882-8800
www.ccpu.com
Continuous Computing Corp. Page 2 File: CC00313-00
San Diego, CA Dual Feed DC Telecom Power Supply User’s Guide Last saved: 2/12/01 4:57 PM
©2000-2001 Continuous Computing Corporation. All rights reserved.
The information contained in this document is provided “as is” without any express representations of warranties. In addition,
Continuous Computing Corporation disclaims all implied representations and warranties, including any warranty of merchantability,
fitness for a particular purpose, or non-infringement of third party intellectual property rights.
This document contains proprietary information of Continuous Computing Corporation or under license from third parties. No part of
this document may be reproduced in any form or by any means or transferred to any third party without the prior written consent of
Continuous Computing Corporation.
Continuous Computing, the Continuous Computing Corporation logo, Continuous Control Node (CCN), Continuous System Controller,
CCPUnet, CCNtalk, Field Replaceable Microprocessor (FRµ), and Field Replaceable System are trademarks or registered trademarks of
Continuous Computing Corporation in the United States and other countries.
Sun, the Sun logo, SPARCengine, Solaris, and OpenBoot are trademarks or registered trademarks of Sun Microsystems Inc. in the
United States and other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC
International, Inc. in the United States and other countries. Products bearing SPARC trademarks are based upon an architecture
developed by Sun Microsystems, Inc.
CompactPCI is a registered trademark of PICMG.
The information contained in this document is not designed or intended for use in human life support systems, on-line control of aircraft,
aircraft navigation or aircraft communications; or in the design, construction, operation or maintenance of any nuclear facility.
Continuous Computing Corporation disclaims any express or implied warranty of fitness for such uses.
Continuous Computing Corp. Page 3 File: CC00313-00
San Diego, CA Dual Feed DC Telecom Power Supply User’s Guide Last saved: 2/12/01 4:57 PM
Table of Contents
1INTRODUCTION ...........................................................................................................5
DESCRIPTION...........................................................................................................................................5
USING THIS GUIDE..................................................................................................................................6
TYPOGRAPHIC CONVENTIONS .................................................................................................................6
DEFINITIONS OF TERMS...........................................................................................................................7
POWER SUPPLY WIDTHS .........................................................................................................................7
SYSTEM BLOCK DIAGRAM ......................................................................................................................7
PHOTOS ...................................................................................................................................................8
2UNPACKING, INSTALLING, AND STARTING UP .......................................................10
ELECTROSTATIC DISCHARGE (ESD)......................................................................................................10
STORAGE...............................................................................................................................................10
UNPACKING...........................................................................................................................................10
INSTALLING THE POWER SUPPLY ..........................................................................................................10
INSTALLING THE POWER INPUT MODULE..............................................................................................11
3GROUNDING YOUR SYSTEM.....................................................................................13
DEFINITIONS OF TERMS.........................................................................................................................13
SYSTEM GROUNDING OPTIONS..............................................................................................................13
Frame Ground to Digital Ground Connected.............................................................................13
Frame Ground to Digital Ground Isolated .................................................................................15
POWERING ON THE SYSTEM..................................................................................................................17
Enabling system from CCN front panel.......................................................................................17
Enabling system from Craft console............................................................................................17
POWERING OFF THE SYSTEM.................................................................................................................18
Disable system from CCN front panel.........................................................................................18
Disable system from Craft console..............................................................................................18
4TROUBLESHOOTING .................................................................................................19
TROUBLESHOOTING SCENARIOS............................................................................................................19
CHECK THE LEDS.................................................................................................................................19
USE THE CCN .......................................................................................................................................19
Use the faults command.........................................................................................................19
Use the voltages command ....................................................................................................20
CHECK THE FUSES.................................................................................................................................20
REMOVING THE POWER SUPPLY............................................................................................................21
REMOVING THE POWER INPUT MODULE ...............................................................................................21
CONTACT TECHNICAL SUPPORT............................................................................................................21
5LEDS, CONNECTOR USAGE, AND SPECIFICATIONS ................................................22
LEDS....................................................................................................................................................22
The INPUT LED..........................................................................................................................22
The ON LED................................................................................................................................23
The FLT LED ..............................................................................................................................23
CONNECTOR USAGE..............................................................................................................................23
J1000 Pinout ...............................................................................................................................23
SPECIFICATIONS ....................................................................................................................................24
6TECHNICAL SUPPORT...............................................................................................26
CONTACTING TECHNICAL SUPPORT ......................................................................................................26
Continuous Computing Corp. Page 4 File: CC00313-00
San Diego, CA Dual Feed DC Telecom Power Supply User’s Guide Last saved: 2/12/01 4:57 PM
TABLE OF FIGURES
FIGURE 1 SYSTEM BLOCK DIAGRAM.......................................................................................................7
FIGURE 2 100W DUAL FEED DC TELECOM POWER SUPPLY..................................................................8
FIGURE 3 150W DUAL FEED DC TELECOM POWER SUPPLY..................................................................9
FIGURE 4 350W DUAL FEED DC TELECOM POWER SUPPLY..................................................................9
FIGURE 5 CARD INSTALLATION AND REMOVAL....................................................................................11
FIGURE 6 CONNECTING THE POWER INPUT MODULE CONNECTOR TO MIDPLANE.................................12
FIGURE 7 CCN FRONT PANEL...............................................................................................................17
FIGURE 8 LEDS FOR 100W, 150W, AND 350W POWER SUPPLIES .......................................................22
FIGURE 9 J1000 PINOUT VIEWED FROM BOARD EDGE...........................................................................23
TABLE OF TABLES
TABLE 1 TYPOGRAPHIC CONVENTIONS ..................................................................................................6
TABLE 2 POWER SUPPLY SLOT WIDTHS..................................................................................................7
TABLE 3 FRAME GROUND TO DIGITAL GROUND CONNECTED WITH BARRIER STRIP POWER ENTRY.....13
TABLE 4 FRAME GROUND TO DIGITAL GROUND CONNECTED WITH POWER ENTRY CONNECTORS.......14
TABLE 5 FRAME GROUND TO DIGITAL GROUND ISOLATED WITH BARRIER STRIP POWER ENTRY.........15
TABLE 6 FRAME GROUND TO DIGITAL GROUND ISOLATED WITH BARRIER STRIP ENTRY.....................16
TABLE 7 VOLTAGES COMMAND OUTPUTS.............................................................................................20
TABLE 8 SPECIFICATIONS.....................................................................................................................25
Continuous Computing Corp. Page 5 File: CC00313-00
San Diego, CA Dual Feed DC Telecom Power Supply User’s Guide Last saved: 2/12/01 4:57 PM
1 Introduction
Welcome to the Dual Feed DC Telecom Power Supply User’s Guide. This guide contains information
about the installation and use of Continuous Computing Corporation’s 100W, 150W, and 350W Dual
Feed DC Telecom Power Supplies.
This guide includes the following information related to the 100W, 150W, and 350W Dual Feed DC
Telecom Power Supplies:
• Unpacking, installing, and starting up
• Grounding your system
• Troubleshooting
• Connector usage and specifications
Description
The Continuous Computing Telecom Power Supply offers 100, 150, or 350 watts of Hot Swappable,
load-sharing power for a CompactPCI system. The Power Supply is designed for the Central Office,
with dual input feeds and –48V DC input. Typical systems combine two Supplies to provide redundant
power. Each Power Supply also provides a standby power output for use by a Continuous Control Node
(CCN).
Features of the Dual Feed DC Telecom Power Supply include:
• Hot Swap and Load Sharing
The Power Supply is designed for redundant operation. A failed Power Supply can be
replaced without application downtime. Load sharing ensures that supplies run cooler,
leading to increased system reliability.
• Standby Power
Standby power provides an output that is always on to power a Continuous Control Node.
This enables remote power cycling and system diagnostics even when the Power Supply is
off.
• Over Temperature and Short Circuit Protection
Protection features reduce the possibility of hardware damage during extreme temperatures
or fault conditions.
• Remote Sense on +5 and +3.3V
Remote sense provides high-quality power to critical system components.
• Dual Input Feeds
Dual power feeds allow the system to continue running even if one feed drops out.
• 6U CompactPCI Form-Factor
Standard 6U form-factor allows for easy integration into CompactPCI system without
awkward divider rails.
The Telecom Power Supply is a Basic Hot Swap device. PICMG 2.1 R1.0 describes Basic Hot Swap as
a board powered and enabled for access by the PCI bus in configuration space only upon insertion. The
board’s configuration space is not yet initialized. You must initiate software connection at the system
console. The power circuitry is controlled so that inserting in or extracting from a live redundant system
will not cause any electrical damage. If the system is not redundant, it must be halted before servicing.
Continuous Computing Corp. Page 6 File: CC00313-00
San Diego, CA Dual Feed DC Telecom Power Supply User’s Guide Last saved: 2/12/01 4:57 PM
Using This Guide
This guide is written for computer technicians and hardware and software engineers.
It is assumed that the user of the Power Supply is:
• Familiar with the handling of ESD-sensitive electronic equipment.
• Standard -48V wiring techniques and safety precautions.
Typographic Conventions
A summary of the typographic conventions used in this guide is listed in Table 1 below.
Typeface/Symbol Meaning Example
AaBbCc123 The names of commands,
files and directories; on-
screen computer output
Edit your .login file.
At the ok prompt….
AaBbCc123 What you type, contrasted
with on-screen computer
output
To turn the unit on, type on
at the ccpu> prompt. i.e.,
ccpu>:on
<AaBbCc123> Command-line placeholder or
token to be replaced with a
real name or value (do not
type brackets)
To delete a file, type rm
<filename>.
[AaBbCc123]Optional argument (do not
type brackets) [help]
dir [<filename>]
{<a><b>}Required argument (do not
type brackets) {<na><cmd>}
grade {a, b, c, d, f}
AaBbCc123 Book titles, new words or
terms, or words to be
emphasized
• This manual is used in
conjunction with the
SPARCengine CP1500
User’s Manual.
• You must be grounded
to avoid ESD damage to
the equipment.
ABC Acronyms Locate the On / Off toggle
switch on the CCN front
panel.
!
Caution Failure to heed the
instructions that follow the
Caution symbol may result
in damage to the equipment.
Table 1 Typographic conventions
Continuous Computing Corp. Page 7 File: CC00313-00
San Diego, CA Dual Feed DC Telecom Power Supply User’s Guide Last saved: 2/12/01 4:57 PM
Definitions of Terms
Power Supply Refers to the larger card installed in the front of the
system. Power Supply also refers to the larger card and
Power Input Module as a unit.
Power Input Module Refers to the interface module installed at the back of the
system.
Continuous Control Node (CCN) Refers to the module that monitors and controls a
compute node in a CompactPCI system.
Power Supply Widths
Power Supply Width
100W 1 slot (4HP)
150W 1 ½ slots (6HP)
350W 2 slots (8HP)
Table 2 Power Supply slot widths
System Block Diagram
Figure 1 System block diagram
Continuous Computing Corp. Page 8 File: CC00313-00
San Diego, CA Dual Feed DC Telecom Power Supply User’s Guide Last saved: 2/12/01 4:57 PM
Photos
Figure 2 100W Dual Feed DC Telecom Power Supply
Feed A & B fuses
Alarm/Standby (STBY)
power fuse
Continuous Computing Corp. Page 9 File: CC00313-00
San Diego, CA Dual Feed DC Telecom Power Supply User’s Guide Last saved: 2/12/01 4:57 PM
Figure 3 150W Dual Feed DC Telecom Power Supply
Figure 4 350W Dual Feed DC Telecom Power Supply
Feed A & B fuses
Alarm/Standby
(STBY) power fuse
Feed A & B fuses
Alarm/Standby
(STBY) power fuse
Continuous Computing Corp. Page 10 File: CC00313-00
San Diego, CA Dual Feed DC Telecom Power Supply User’s Guide Last saved: 2/12/01 4:57 PM
2 Unpacking, Installing, and Starting Up
Electrostatic Discharge (ESD)
!
Caution – The Power Supply contains electronic components that
are extremely sensitive to static electricity. Ordinary amounts of
static from clothing and the surrounding environment may destroy
components.
What to do
• Use an antistatic mat.
• Use an antistatic wrist or foot strap.
Storage
• If the Power Supply is to be stored before unpacking, see Table 8 for environmental storage
specifications.
Unpacking
!
Caution – Always maintain an ESD-safe environment when handling
the Power Supply. It contains many components that can be
destroyed by ESD.
• Inspect the shipping container for any in-transit damage and report it to shipping agent if
necessary.
• Carefully unpack the Power Supply from its shipping container.
Installing the Power Supply
!
Caution – You may only install the Power Supply in a slot
specifically provided for it by Continuous Computing. The Power
Supply is not interchangeable with supplies from other
manufacturers, even if they use the same connector.
Tabla de contenidos
