Continu.us CA-1000WIFI Hoja de datos
A
CA-1000WIFI
OMNI-DIRECTIONAL DIGITAL ANTENNA
INSTALLATION INSTRUCTION GUIDE
FOR NEW INSTALL OR UPGRADE KIT
5935 W. 84th St. Suite A Indianapolis, Indiana 46278 (855) 423-2181 www.continu.us
F
L R O-D P O
W P
H P
O-D
,
40 .
-25° 145° O
T. D
.
T CA-1000WIFI
HD A
.
F 2 (T) TV
O. T CA-1000WI-
FI W P
TV.
Improper installation may cause personal injury and/or property damage. Make sure you
understand these instructions before you install this mounting hardware.
It is the responsibility of the installer to ensure that this mount is installed safely.
Check that all listed parts were included with your mount before you begin installation.
Frequency Range
Gain
Impedance
Power Supply
VIDEO: 54 - 698 MHz | FM: 87- 108 MHz
20 dB
75
DC 12V 150mA
S
P L
N
D Q.
Antenna Head
Instruction Manual
Base Mount (Pre-Installed in Upgrade Kit)
Wall Plate
Dipole Antenna
M4*25 - Screw for Wall Plate
#8, 1/2” Screw
Reset Switch
1
1
1
1
4
2
4
1
5935 W. 84th St. Suite A Indianapolis, Indiana 46278 (855) 423-2181 www.continu.us
WF R U T A H M
L
WF N. T
W-F .
5935 W. 84th St. Suite A Indianapolis, Indiana 46278 (855) 423-2181 www.continu.us
Choose a location for the antenna. The antenna should be placed away from any
other metal objects which might interfere with reception. (FIG. 1)
1)
Note: The direction of the base mount determines the direction of the antenna. The base of the
mount is an oval, which will help you determine the direction with its long and short sides (FIG 2).
The long sides will run from the front of the vehicle to the back. With the Dipole’s directed
towards the back.
N I I
1) Attach the four dipole antenna’s included with the CA-1000WIFI
2) Align the antenna head with the base mount. Dipole antenna’s need to face the back
of the vehicle.
Insure that cables are long enough to reach their destination points inside the
vehicle.
4)
3)
Use the provided #8, 1/2” screws to secure the Antenna head to the base.
5) Apply sealant around the base mount to seal edges.
After the base has been secured to the roof of the vehicle, follow these instructions.
A A H
N M I
FIG. 2
10”
10”
20”
Min. Distance
Front of Vehicle
RECOMMENDED
ZONE
FIG. 1
Antenna Head
Roof / Ceiling
Apply Sealant around edge of
the base, sealing all gaps
between Base Mount & Roof.
Base Mount
Dipole antenna
#8, 1/2” Screws
Before installing CA-1000WIFI, it is recommended that you check with your vehicle
manufacturer for any special screw or installation requirements. Follow the assembly
diagram below (FIG 3.) to install your CA-1000WIFI.
FIG 3.
Front of Vehicle
Dipoles
Long Side
Short Side
5935 W. 84th St. Suite A Indianapolis, Indiana 46278 (855) 423-2181 www.continu.us
With the CA-1000WIFI upgrade kit, the baseplate will come pre-installed on the RV.1)
Note: The CA-1000WIFI uses the same baseplate as the CA-1000 antenna that is installed by
the factory. If your RV does not have a CA-1000 antenna, please refer to the instructions on page
2 for installing a new CA-1000WIFI antenna baseplate.
U K I I
1) Detach the screws in the CA-1000 antenna, and disconnect all attached cables.
2) Take the CA-1000WIFI antenna head, and align it with the original baseplate.
Note: Dipole antenna’s need to face the back of the vehicle.
The CA-1000WIFI includes an additional CAT5 ethernet cable, and a 20 AWG Wi-Fi
reset cable. Insure that all cables are long enough to reach their destination points
inside the vehicle.
a)
3)
The optional ethernet connection will connect directly into the CWP-2000B
wall plate, for wired connections.
a) Option 1: (Recommended) Run the 20 AWG wire from the CA-1000WIFI to the
CWP-2000B Wall Plate inside the RV.
b) Option 2: The CA-1000WIFI-RS reset switch is an independent switch that can
be installed inside the RV, or placed in the opening between the CA-1000WIFI
antenna head and the baseplate.
5) Use the provided #8, 1/2” screws to secure the Antenna head to the base.
6) Re-apply sealant around the base mount if necessary.
4) The CA-1000WIFI Reset switch has two installation options.
With the CA-1000 baseplate already installed. You will begin by removing the old antenna.
U CA-1000WIFI
U K M I
Antenna Head
Roof / Ceiling
Reapply Sealant if Necessary.
Existing Base Mount
Dipole antenna
#8, 1/2” Screws
Before installing CA-1000WIFI, it is recommended that you check with your vehicle
manufacturer for any special screw or installation requirements. Follow the assembly
diagram below (FIG 4.) to install your CA-1000WIFI.
FIG 4.
1) Coaxial Cable: This cable sends TV signal to your TVs inside the RV.
2) Reset Switch Cable: Black & Red 20 AWG cable that needs to be tied to the reset
switch. Pressing the reset switch restores default settings on antenna.
3) Ethernet Cable: (Optional) plugs directly into the wall plate to deliver a wired internet
connection. WiFi Range extender capabilities will still work without connecting this
cable.
5935 W. 84th St. Suite A Indianapolis, Indiana 46278 (855) 423-2181 www.continu.us
©2018 Continu.us. All Rights Reserved
Please contact our Customer Support line at (855)423-2181 if you notice any missing or
damaged pieces.
Please visit us Online at www.continu.us to learn more about Continu•Us products.
W CA-1000WIFI
C S
CI-02180
Amplified
Signal
Connect the appropriate cables and wires, and tape all the coax connections. The
CA-1000WIFI has 3 wires you will need to connect to the CWP-2000B Wall Plate. (FIG 5.)
1 2
Ethernet
TV
12V DC
TV ANT IN
RESET
ETHERNET
TO TV2
TO RADIO
FM RADIO
h F Connector
FIG 5.
CABLE IN
Park Cable Input
Ethernet Connection
