Continental Refrigerator DL2RE-SGD Manual de usuario

EXTRA-WIDE

SLIDING GLASS DOOR

DISPLAY REFRIGERATOR

REFRIGERATORS

Utilizing Environmentally Safe, CFC-free R-134a Refrigerant

Standard Features

• Modern, State-of-the-Art Styling

• Performance Rated Refrigeration System Utilizing

Environmentally Safe R-134a Refrigerant

• 3" Non-CFC Polyurethane Foam Insulation

• Self-Closing Doors

• Cylinder Lock in Each Door

• Automatic Electric Condensate Evaporator

• 6" Stainless Steel Legs

• Heavy Duty, Epoxy-Coated Steel Shelves

• External Dial Thermometer

• Double-Pane, Tempered Sliding Glass Doors

• Fluorescent Interior Lighting

Options & Accessories

Standard (S/S Front, Aluminum Ends & Interior)

Suffix SA (S/S Exterior, Aluminum Interior)

Suffix SS (S/S Exterior & Interior)

•Half Door

•Remote

•Pass-Thru

(Glass One Side Only)

•Pan Slide Assemblies

•Casters

•Stainless Steel

Shelves

•Consult Factory

DL2RE-SS-SGD

Refrigeration System

A “Performance Rated”, air cooled, hermetically

sealed, capillary-type refrigeration system is installed

on the top of each refrigerator. Plasticized fin coil and

air circulating fans are contained within a concealed

“plug” type insulated housing, readily accessible on

top of the cabinet and separate from the food zone to

increase food storage capacity. The entire “plug” sys-

tem is fully charged with environmentally safe R-134a

refrigerant and mounted on a sturdy steel, rail-type

base which can be easily removed if freezer conver-

sion is desired. Refrigerators are designed to main-

tain 38 to 40 degrees Fahrenheit (3 to 5 degrees

Centigrade) while operating with an unrestricted air

supply in a maximum ambient temperature of 100

degrees Fahrenheit . All condensate water is evapo-

rated by an automatic non-electric, corrosion-resist-

ant condensate evaporator. A strict quality-assurance

team inspects all materials and components to certify

that each model conforms to the most exacting stan-

dards. All models are factory performance tested for a

minimum of 16 hours prior to crating.

Cabinet Construction

All materials are of top quality, assembled to conform

with strict quality-assurance requirements. The cabi-

net front is constructed of heavy-gauge polished

stainless steel for durability. All cabinet joints and

seams are sealed vapor-tight. Case is of all metal,

welded construction and internally supported and

braced for a rigid unit construction. Cabinet design

eliminates overlapping panels with raw edges.

Cabinet body is insulated with non-CFC, foamed-in-

place polyurethane foam with an average thickness of

3 inches to ensure increased energy efficiency. Full

length louvered air grille located above the doors

allows equal air circulation to the condensing unit.

Easily removable, low wattage, anti-sweat door

heaters concealed by a non-metallic, non-conductive,

high-impact thermal breaker strip eliminate conden-

sate build-up on the cabinet front. Fluorescent lighting

is activated by an easily accessible interior switch.

Cabinets are equipped with 6-inch adjustable stain-

less steel legs.

Shelving

Shelves are designed for heavy-duty use with .306"

diameter frame and brace members and .140" diam-

eter fill wires spaced 3/4" apart. Shelves are welded

steel and epoxy-coated for a durable, long, rust-free

service life. Adjustments are in 1/2" increments and a

wide door opening allows the use of a variety of

optional pan and tray slide types.

Door Construction

Self-closing double-pane, tempered sliding glass is

encased by a heated, heavy-duty aluminum extruded

frame. Doors glide on stainless steel, heavy duty, ball

bearing wheels. Doors are provided with built-in

cylinder lock.

DLRESGD305

REFRIGERATORS

A Division of National Refrigeration & A/C Products, Inc.

539 Dunksferry Road Bensalem, PA 19020

(800) 523-7138 Fax: (215) 244-9579

www.continentalrefrigerator.com

DIMENSIONAL DATA REACH-IN PASS-THRU

(GLASS ONE SIDE ONLY)

Net Capacity (cu. ft.) 52 52

Width, Overall (in.) 57 57

Depth, Overall (Incl. Hdls.) (in.) 34 36

Depth (Less Door(s) (in.) 32 32

Clear Door Width (in.) 217/8217/8

Clear Full-Door Height (in.) 581/4581/4

Clear Half-Door Height (in.) 27 27

Height, Overall

(Incl. 5" Casters)

831/4831/4

No. of Full Door(s) 2 4

No. of Half Door(s) 4 8

No. of Shelves 8 8

Shelf Area (sq. ft.) 47.6 47.6

Tray Slide Capacity (Half) 12 ea. 12 ea.

Tray Slide Capacity (Full) 24 ea. 24 ea.

REFRIGERATION DATA

Condensing Unit Size (H.P.) 1/21/2

Capacity (BTU/Hr)* 4010 4010

ELECTRICAL DATA

Cabinet Specifications 115/60/1 115/60/1

Feed Wires (Incl. Ground) 3 3

Condensing Unit Specs. 115/60/1 115/60/1

Total Amperes 13.6 14.3

Cabinet Amperes 4.1 4.8

Defrost Amperes - -

Power Supply Cord yes yes

SHIPPING DATA

Height – crated (in.) 82 82

Width – crated (in.) 58 58

Depth – crated (in.) 42 42

Volume – crated (cu.ft.) 116 116

Weight Std – crated (lbs.) 545 645

Weight SS – crated (lbs.) 675 725

Weight Std – uncrated (lbs.) 375 445

Weight SS – uncrated (lbs.) 455 525

* Rating @ +25°F Evaporator, 90° Ambient

Note: All specifications subject to change without notice.

Note: If the cabinet is located directly against wall and/or under low ceiling,

a minimum clearance of 2" is required.

CHARACTERISTICS DL2RE-SGD DL2RE-SGD-PT
