USB2-H-6002 –Quick Start Guide

Clearance Number: CP#014

Document Reference Number: CP_000024

USB2-H-6002_Quick_Start_Guide Version 1.1

Congratulations on your purchase of the Connective Peripherals USB2-H-

6002 USB to dual port RS422 adapter. Getting started is quick and easy:

Detailed device driver installation instructions, port information and

mechanical details are available in the USB2-H-6002 datasheet. This can be

downloaded from: http://www.connectiveperipherals.com.

To begin, connect the USB cable to your PC USB Host or a USB Hub

connector and the USB2-H-6002. Power is supplied by the USB

interface, so no external power supply is required.

Device drivers are needed for the PC to communicate with the USB2-

H-6002. If your computer is connected to the Internet, you can use

the Microsoft Windows Update service to automatically download

the latest WHQL-certified device drivers. Alternatively these can be

downloaded from: http://www.connectiveperipherals.com. To

install the drivers , follow the following steps:

1. Download and unzip the drivers to a folder.

2. Connect the USB cable to your PC USB Host or a USB Hub

connector and the USB2-H-6002. Power is supplied by the USB

bus, so no external power supply is required.

3. The Windows “Found New Hardware Wizard” will appear. Select

the choice to install the drivers from a specific location, then

browse to the folder just created when the drivers were

downloaded from the Connective Peripherals website.

4. If a notice appears indicating that the drivers are not signed,

select “Install Anyway”.

USB2-H-6002 –Quick Start Guide

Clearance Number: CP#014

Document Reference Number: CP_000024

USB2-H-6002_Quick_Start_Guide Version 1.1

5. The Driver wizard will appear a second time. Repeat the steps 2

to 4 above to complete the installation.

The dual port DE-9P pin-out is as follows:

Revision History:

Version 1.0

2009-07-07

Initial release

Version 1.1

2019-03-11

Re-branding to reflect the migration of the product from EasySync to

Connective Peripherals name (changed logo, copyright, internal hyperlinks)

Function

TXD- = Transmit Data, negative polarity

TXD+ = Transmit Data, positive polarity

RXD+ = Receive Data, positive polarity

RXD- = Receive Data, negative polarity

GND = signal ground

RTS- = Request To Send, negative polarity

RTS+ = Request To Send, positive polarity

CTS+ = Clear To Send, positive polarity

CTS- = Clear To Send, negative polarity
