Conceptronic
(Wireless) Internet Camera
CNETCAM / C54NETCAM
User’s Guide
Version 1.0
Table of Contents
1. Package Contents
2. System Requirements
2.1 Networking
2.2 Accessing the Camera
3. Explanation of the Controls
4. Hardware Installation
4.1 Attaching the Camera to the Stand
4.2 Connecting the Ethernet cable
4.3 Attaching the Powersupply
5. Security
6. Using the (Wireless) Internet Camera through the webbrowser
6.1 Web Configuration Utility
6.2 System Administration
6.3 System Administration
Æ
Management
6.4 System Administration
Æ
Configuration
6.5 System Administration
Æ
Tools
6.6 System Administration
Æ
About
6.7 View Video – ActiveX Mode
6.8 View Video – Java Mode
7. Using the (Wireless) IP Camera through the IPView SE Utility
7.1 Installation
7.2 Getting Started
8. Adding your (Wireless) Internet Camera to your website
8.1 Xplug Control Installation to Webserver
8.2 Configure the (Wireless) IP Camera for Website Usage
8.3 Router Configuration
8.4 Website Configuration
9. Appendix
9.1 Frequently Asked Questions
9.2 Ping your IP Address
9.3 Troubleshooting
9.4 Xplug Control Installation
9.5 Adjust Internet Camera Focus
9.6 Specifications
9.7 Glossary Of Terms
1. Package Contents
• Conceptronic CNETCAM / C54NETCAM
• Camera stand which can be used for wall mount
• Power supply, 5V DC, 2.5A
• Antenna (Only with the C54NETCAM)
• CD-ROM with software and manual
• Quick Installation Guide
2. System Requirements
2.1. Networking
• Local Area Network : 10Base-T Ethernet or 100Base-TX Fast Ethernet.
• Wireless Local Area Network : IEEE 802.11g Wireless LAN.
2.2. Accessing the Camera
For Web Browser Users
• Operating System: Microsoft® Windows® 98SE/ME/2000/XP
• CPU: Intel Pentium II, 266 MHz or above
• Memory Size: 32MB (64MB recommended)
• Resolution: 800x600 or above
• Microsoft® Internet Explorer 5.0 or above (ActiveX & JAVA Mode – Image View for
Windows OS and JAVA Mode – Image View for other OS); Netscape 6.0 or above
(JAVA Mode – Image View)
For IPView SE Application Users
• Operating System: Microsoft® Windows® 98SE/ME/2000/XP.
• CPU: Intel Pentium III, 450 MHz or above
• Memory Size: 128 MB (256 MB recommended)
• Resolution: 800x600 or above
3. Explanation of the controls
This section describes the externally visible features of the Wireless Internet Camera.
4 5 6 7
1 2
3
1. Screw Hole
Located on the top/bottom panel of the camera, the screw hole is used to
connect the camera stand onto the camera by attaching the screw head on
the camera stand into the screw hole of the camera.
2. Power and Link LED
The Power LED is positioned on the right side of the Wireless Internet
Camera’s lens while facing the Wireless Internet Camera. A steady BLUE
light confirms that the Wireless Internet Camera is powered on.
The Link LED is positioned on the right side of the Wireless Internet
Camera’s lens while facing the Wireless Internet Camera. It is located right of
the Power LED. A steady ORANGE light confirms that the camera has good
connection to LAN connectivity. Dependent on the data traffic the LED will
begin to flash to indicate that the Wireless Internet Camera is
receiving/sending data from/to the network.
3. Lens Cap
By turning the Lens Cap to the right or the left, you can adjust the sharpness
of the recording image.
4. Network Cable Connector
The Wireless Internet Camera’s rear panel features an RJ-45 connector for
connections to 10Base-T Ethernet cabling or 100Base-TX Fast Ethernet
cabling (which should be Category 5 twisted-pair cable). The port supports
the N-Way protocol and “Auto-MDIX” function, allowing the Wireless Internet
Camera to automatically detect or negotiate the transmission speed of the
network.
5. External Antenna (Only on C54NETCAM)
The rotatable external antenna allows you to adjust its position to obtain the
maximum signal.
6. Reset Button
Reset will be initiated when the reset button is pressed once, and Power
LED begins to flash.
Factory Reset will be initiated when the reset button is pressed continuously
for three seconds or when Power LED begins to light up. Release the reset
button and the Power LED will begin to flash, indicating the Wireless Internet
Camera is changing to factory reset. When factory reset is completed, the
Wireless Internet Camera will be set to de fault on channel 11 and SSID is
set as “NULL String” (This default setting will let the Wireless Internet Camera
connect to ANY access point on the infrastructure network). The IP address
will also return to the default setting as 192.168.0.20.
7. DC Power Connector
The DC power input connector is located on the Wireless Internet Camera’s
rear panel, and is la beled DC5V with a single jack socket to supply power to
the Wireless Internet Camera. Power will be generated when the power
supply is connected to a wall outlet.
4. Hardware Installation
4.1. Attaching the Camera to the Stand
The Wireless Internet Camera comes with a camera stand (optional) with a swivel ball
screw head that can be attached to the Wireless Internet Camera's bottom screw
hole. Attach the camera stand to the Wireless Internet Camera and station it for your
application. There are three holes located in the base of the camera stand allowing
the Wireless Internet Camera to be mounted on the ceiling or any wall securely.
4.2. Connecting the Ethernet cable
Connect an Ethernet cable to the network cable connector located on the Wireless
Internet Camera’s rear panel, and then attach it to the network.
4.3. Attaching the Power Supply
Attach the external power supply to the DC power input connector located on
Wireless Internet Camera’s rear panel, and then connect it to your local power supply.
HINT: You can confirm power source is supplied from the LED indicators label Power
on the Wireless Internet Camera is illuminated.
5. Security
To ensure the highest security an d prevent unauthorized usage of the (Wireless)
Internet Camera the Administrator has the exclusive privilege to access the System
Administration for settings and control requirements to allow users the level of entry
and authorize the privileges for all users. The (Wireless) Internet Camera supports
multi-level password protection and access to
the Wireless Internet Camera is strictly restricted to defined the user who has a “User
Name” and “User Password” that is assigned by the Administrator.
The administrator can release a public user name and password so when remote
users access the Wire less Internet Camera they will have the right to view the image
transmitted by the Wireless Internet Camera.
NOTE: Since the default settings are empty, it is highly recommended to set the "Admin ID"
and "Admin Password" when you are the first time to use the (Wireless) Internet
Camera. Once the ID and Password are defined, only the administrator has the acce
ss to management the (Wireless) Internet Camera. This procedure should be done
as soon as possible since the security featur es with the (Wireless) Internet Camera
will not be enabled until the "Admin ID" and "Admin Password" is defined.
6. Using the (Wireless) IP Camera through the webbrowser
You can access and manage the Wireless Internet Camera through:
1) a web browser, and 2) the enclosed software IPView SE.
This chapter describes the Web Configuration Utility, and provides the instructions on
using the camera with a web browser.
6.1. Web Configuration Utility
The (Wireless) Internet Camera can be configured with the Setup Wizard, or through
its built-in Web-based Configuration. ( Extensive knowledge of LAN will be helpful in
setting up the Wireless Internet Camera.) From the web browser, enter the default IP
address to access the Welcome screen of the (Wireless) Internet Camera.
To configure your (Wireless) Internet Camera, type http://192.168.0.20 in the address
box. The number is the default IP address of your (Wireless) Internet Camera. Then,
press [Enter].
NOTE: The computer’s IP address must correspond with the camera’s IP address in
the same segment for the two devices to communicate.
Welcome Screen of the Configuration Utility
After the default IP address is entered from the browser, the Wireless Internet
Camera Welcome screen will appear with a still image. There will be three options to
choose from to set-up and view your Wireless Internet Camera, including:
View Video – ActiveX Mode
View Video – Java Mode
System Administration
6.2. System Administration
Under the Welcome screen of the Configuration Utility, click System Administration to
enter the administration window that contains the settings required for the camera in
the top menu bar, including Management, Configuration, Tools, Help, and Home.
HINT: Once you have changed the settings in each option, click Save to store the
settings, or Cancel to abandon, or Refresh to reload the status. During the
configuration, whenever you click Home in the top menu bar will make you return to
the Welcome window.
6.3. System Administration ÆManagement
The Management window contains the information of your configuration. Click the
items in the left column to view your settings, including: System, Video, Wireless,
Network, and User.
6.3.1. System
Click the System item in the left column to display the device status of your camera.
- Device Status: The information about the camera, including the Camera
Name, Location, Model, Firmware Version, MAC Address
and IP Address, can be found in this field.
- Ethernet Status: You can monitor the networking status in this field, including
the Link (network connection), Speed, and the Duplex mode.
6.3.2. Video
Click the Video item in the left column to display the video configuration of your
camera.
- Video Status: The video configuration about the camera, including the
Video Resolution, Compression Rate, Frame Rate, Frame
Size and IP Address, can be found in this field.
6.3.3. Wireless (Only for C54NETCAM!)
Click the Wireless item in the left column to display the information of the wireless
LAN.
- Wireless Status: The items in this field display the information of the wireless
LAN, such as the Connection Mode (Infrastructure or Ad-
Hoc), Link, SSID, Channel, Transmission Rate, and WEP
Encryption.
6.3.4. Network
Click the Network item in the left column to display the information of the LAN.
- Network Status: The items in this field display the information of the LAN,
such as the IP Address, SubnetMask, Default Gateway,
Primary DNS Address, Secondary DNS Address, Dynamic
DNS, Secondary
HTTP Port, and UPnP.
6.3.5. User
Click the User item in the left column to display the user(s) information.
- Active Users: The items in this field display the user(s) information,
including the user(s) IP address, Name, and DateTime.
6.4 System Administration ÆConfiguration
The Configuration window contains commands for settings that are required to input
key details to setup the camera for operation. Click Configuration in the top menu bar
and the configuration window will appear as below:
6.4.1. System
Click the System item in the left column to setup the basic configuration of your
camera.
- Camera Name: This field is used to enter a descriptive name for the device.
The default setting for the Camera Name is C07-060-xxxxxx,
where xxxxxx is the last six digit of the MAC Address. The
maximum
length is 32 (printable ASCII).
- Location: This field is used to enter a descriptive name for the location
used by the camera (optional).
- Admin: This field is used to enter the administrator name along with
the password to access the System Administration settings.
Be sure to enter the password twice to confirm the details
once in the Admin Password field and again in the Confirm
Password
field. The default setting for administrator is empty, and you
need to key in the administrator name with a maximum
length of 12 (printable ASCII) characters and enter the
administrator password with a maximum length of 8
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Cámara IP de Conceptronic
