Compaq ProLiant ML350

Rev. 0.41 1of 13

Compaq ProLiant ML350 Server Overview

Description

The 2nd generation ProLiant ML350 server is a dual processor capable,

expandable server that comes in both non-hot-plug and hot-plug hard drive

models. New features of this server include the latest 1-GHzprocessor, an

integrated dual channel Wide Ultra3 SCSI controller, additional 64-bit PCI

slots and support for USB ports. The server also has a new bezel, variable fan

control, a built-in connector for Remote Insight Board Lights Out Edition ,

ROM-based BIOS setup and Remote ROM Flash support.

Note

The system uses the FC-PGA (flip-chip) processor which has a different socket

than the previous generation ProLiant ML350 and therefore cannot be used to

upgrade previous generation systems.

New Models

The following table provides the part numbers and configuration codes for the

updated ProLiant ML350.

Table 1: Part Numbers and Configuration Codes

Server Model Part Number Configuration

Code

ProLiantML350T02 P1000-256KB128MBHP 195471-xx1 FSJ1

ProLiantML350T02 P1000-256KB128MB NHP 160247-xx1 FSH1

ProLiantML350T02 P1000-256KB128MB9.1GBNHP 160247-xx2 FSH2

New Features

This model brings the following changes to the ProLiant ML350 Pentium III

line:

n1-GHz FCPGA (Flip-Chip) Intel Pentium III (Coppermine) with 256KB

integrated Level 2 cache

nFour 64-bit (33MHz) PCI slots (vs. two in 1st generation) but no legacy

ISA slot (vs. one in 1st generation)

nSupport for 4MB memory

nTwo USB ports

nInternal Remote Insight Lights-Out connector

nAdaptec 7899 integrated dual channel Wide Ultra3 SCSI controller (vs.

Ultra2 in 1st generation)

nSupport for Compaq RAID LC2 (Zorro)

nATI Rage XL, 4MB SDRAM Video Memory

nROM-based BIOS setup and Remote ROM Flash support

Compaq ProLiant ML350

Rev. 0.41 2of 13

nCompaq SmartStart 4.90 and Compaq Insight Manager 4.90

nIntelligent (variable) fan control

nStreamlines ID bezel

Figure 1 illustrates the new features on the ProLiant ML350 server feature board:

Figure 1: Feature Board

Figure 2 illustrates the new features found on the ProLiant ML350 system board:

Figure 2: System Board

ATI Rage XL 4MB

Video Controller

Adaptec 7899 Dual Channel

Ultra3 SCSI Controller

New FCPGA

packaging

Four 64-bit

PCI slots

RIB Connector

USB Ports

Compaq ProLiant ML350

Rev. 0.41 3of 13

Upgrade Options

Table 2 lists unique option kits that compatible with both 1st and 2nd

generation ProLiant ML350’s. Table 3 lists new and newly supported

recommended options.

Table 2: Unique Option Part Numbers

Option Part Number Installation Guide

ML350 Internal to External SCSI Kit 159547-B21 174862-002

ML350 Tower-to-Rack Conversion Kit 158438-B21 201346-001

ML350Hot-plug Hard Drive Upgrade Kit 161275-B21 159373-002

Table 3: Recommended Option Part Numbers

Option Part Number Installation Guide

6/1000-256K (FC-PGA) Processor Option Kit 207068-B21 203800-001

RAID LC2 Controller (U3, single internal RAID) 188044-B21 191996-021

Smart Array 5302/32 Controller (Maxwell) 166207-B21 189488-002

Wireless Hardware Access Point (11MB) 158603-XX1

56K PCI Modem 171914-001

Software Supported

Operating Systems

In addition to the software supported by the 1st generation system, the

ProLiant ML350 now supports IBM OS/2 including:

nOS/2 Warp Server 4.0

nOS/2 Server Advanced 4.0, SMP

nOS/2 Warp Server for E-business

For a complete and up-to-date listing of supported OSs and versions, visit the

Compaq OS Support Matrix FTP site:

ftp.compaq.com/pub/products/servers/os-support-matrix-310.pdf

Utilities

Following are the versions of utilities that support the 2nd generation ProLiant

ML350:

Table 4 Utility Versions

Utility Version

SmartStart 4.9

Insight Manager 4.9

OS Drivers

For an up-to-date listing of the latest drivers available for the new 1-GHz

models of the ProLiant ML530, visit the Compaq website:

Compaq ProLiant ML350

Rev. 0.41 4of 13

www.compaq.com/support/files/server/us/index.html

New Component Installation or Replacement Procedures

Processor Option and Spares Kits

The option kit contains a processor, heatsink and Processor Power Module

(PPM). If you are replacing an existing processor the spares kit will contain

the processor and heatsink but not a PPM. If needed, the PPM would have to

be ordered separately. In the following procedures, ignore the removal steps if

you are adding a second processor and are not replacing an existing processor.

Note

The processor option kit is for the FC-PGA (flip-chip) processor which has a

different socket than the previous generation ProLiant ML350 and therefore

cannot be used to upgrade previous generation systems.

Compaq ProLiant ML350

Rev. 0.41 5of 13

Locating the Processor or Processor Power Module

Figure 3: Processor Locations

In the Figure 3 you can see the locations of

the processor modules and processor

power modules (PPMs). They are

numbered as follows:

1. Processor socket 1

2. Processor power module socket 1

3. Processor socket 2

4. Processor power module socket 2

Removing and Replacing Processor Module

!Important

Do not remove the processor heatsink unless you are replacing the processor.

When the heatsink is removed, its thermal seal to the processor is broken, and

the thermal effectiveness of the heatsink is compromised. You must then

replace it with a new heatsink.

Figure 4: Heatsink Removal

To remove the heatsink:

1. Press one side of the heatsink retainer

clip (1)to disengage the heatsink from

the processor socket.

2. Unhook the opposite side of the

heatsink retainer clip from the

processor socket (2).

3. Lift up the heatsink from the

processor socket (3).

Compaq ProLiant ML350

Rev. 0.41 6of 13

Figure 5: Processor Removal

To remove the old processor module:

1. Lift up the lever on the processor

socket (1).

2. Remove the processor from the

socket (2).

Figure 6: Processor Replacement

To install the new processor module:

1. Press the new processor into the

socket aligning the marked corner

with the upper left corner of the

socket.

2. Lower the lever to lock the processor

into place.

Figure 7: Heatsink Preparation

To prepare the new heatsink for

installation:

1. Peel the protective covering from the

thermal pad on the heatsink.

2. Align the heatsink so that it is seated

in the groove on the processor

socket.

Compaq ProLiant ML350

Rev. 0.41 7of 13

Figure 8: Heatsink Replacement

To install the new heatsink:

1. Place the heatsink (1) onto the

processor.

2. Secure the heatsink retainer clip to

the hook on the processor socket (3).

3. Secure the opposite side of the

heatsink retainer clip (2) to the hook

on the opposite side of the socket.

Removing and Replacing the Processor Power Module

Figure 9: PPM Removal

To remove the old PPM:

1. Open the latches (1) on the PPM

socket.

2. Remove the module from the socket

on the system board.

Figure 10: PPM Replacement

To install the new PPM:

1. Insert the new module (1) in the

socket making sure the notch on the

module aligns with a tab on the

mounting bracket.

2. Close the latches (2) on the PPM

socket.

Compaq ProLiant ML350

Rev. 0.41 8of 13

Removing and Replacing System Fan 2

Figure 11: System Fan 2 Location Figure 12: System Fan 2 Connection

A new feature

of the ProLiant

ML350 is the a

second system

fan on the

center wall. It is

connected to the

system board

through an

opening in the

center wall. System Fan 2 Fan Cable

Figure 13: System Fan 2 Replacement

To remove the system fan 2 module:

1. Disconnect the fan cable from the

system board (see figure 12).

2. Loosen the thumbscrew (1)

securing system fan 2 to the

chassis.

3. Gently pull the system fan 2

module out and away from the

chassis (2).

4. Reverse steps 1 through 3 to

replace system fan 2 module.

Service Considerations

SmartStart 4.9

SmartStart 4.9 Assisted OpenServer Install

Starting from SS4.9, the SmartStart assisted OpenServer install has been

changed. In order to install OpenServer, the user has to input boot strings to

Compaq ProLiant ML350

Rev. 0.41 9of 13

specify which driver should be loaded for the primary controller. Without the

right boot string, OpenServer may not be able to detect the root disk.

Following are the boot strings for different controllers:

nAdaptec controllers:(Poseidon and Arsalan)

defbootstr link=ad160 hd=Sdsk Srom=wd(0,0,0).

nMaxwell controller: (Smart Array 5300)

defbootstr link=ciss hd=Sdsk Srom=wd(0,0,0).

nIDA controllers:(Smart 2/E, Smart 2/P, Smart 2/DH, Smart 2/SL, Smart

Array 221, 3200, 3250ES)

defbootstr disable =ida link=ida hd=ida0

Srom=wd(0,0,0).

nROC controllers (Embedded ROC, Smart Array 4200, 4250ES and

Smart Array 431)

defbootstr link=clad hd=Sdsk Srom=wd(0,0,0).

nCompaq SymBios SCSI Controllers(825, 875, 876, 895, 896 and non

intelligent ROC):

defbootstr link=cha hd=Sdsk Srom=wd(0,0,0).

SmartStart 4.9 Assisted Install Procedure for SCO OpenServer 5

1. Boot machine and insert the SmartStart 4.9 or later.

2. Follow the install procedure.

3. Create BTLD diskette during SS Interview process.

4. Remove floppy disk and CDROM when the system requests this action.

5. Insert SCO 5.05 CD when system requests this action.

6. The system reboots.

7. At the SCO5 boot prompt, enter the necessary boot string based on the

boot controller.

8. Insert the BTLD diskette when prompted and continue with the

installation.

9. During hard disk setup, select Interactive fdiskoption to preserve the

system partition created by SmartStart.

ROM-Based BIOS Setup Utility (RBSU)

RBSU is a ROM-based configuration utility that displays and modifies the

system configuration settings of a server. RBSU replaces BIOS Setup and

provides a simplified setup process that is machine-specific and tailored for

each type of server. RBSU Version 1.0 on the ProLiant ML350 is intended to

facilitate transition to the “look and feel” of RBSU Version 2.0 which will be

available on future products.

Compaq ProLiant ML350

Rev. 0.41 10 of 13

Among the configuration activities that can be performed are:

nViewing system information

nSelecting the operating system

nConfiguring system devices and installed options

nSelecting the primary boot controller

nManaging storage options.

Starting and Exiting RBSU

During initial installation when the server is not yet configured, RBSU starts

automatically. After the server has been configured, you can launch RBSU by

pressing F9 during the power up. Once you are finished with configuration

activities you can exit RBSU by pressing Escape at the main menu and

confirming your intention by pressing F10. The current boot controller is

displayed for reference purposes.

Initial Boot

On initial boot (for a system that has not yet been configured) you will be

required to enter the following information:

nLanguage and Operating System

nPrimary boot controller

nDate and time

Note

To bypass this step you must insert a Compaq Diagnostics ROMpaq diskette

into the floppy drive before booting the server. This would enable you to

upgrade the ROM or run the SmartStart scripting tools.

Otros manuales para ML350 - ProLiant - G2

Tabla de contenidos

Otros manuales de Servidor de Compaq

Compaq

Compaq 195294-001 - ProLiant - ML370R Guía de instalación

Compaq

Compaq DL760 - ProLiant - 1 GB RAM Manual de instalación y operación

Compaq

Compaq ProLiant 5500 Instrucciones de funcionamiento y seguridad

Compaq

Compaq ProLiant 3000 Instrucciones de funcionamiento y seguridad

Compaq

Compaq ML350 - ProLiant - G2 Instrucciones de funcionamiento y seguridad

Compaq

Compaq 1850R - ProLiant - 128 MB RAM Guía de inicio rápido

Compaq

Compaq 307560-001 - ProLiant - 2500R Manual de usuario

Compaq

Compaq 850R - ProLiant - 32 MB RAM Manual de usuario

Compaq

Compaq ML350 - ProLiant - G2 Manual

Compaq

Compaq ProSignia 200 Guía de inicio rápido

Compaq

Compaq ProLiant 5500 Instrucciones de funcionamiento y seguridad

Compaq

Compaq DL760 - ProLiant - 1 GB RAM Manual

Compaq

Compaq DL360 - ProLiant - Photon Instrucciones de funcionamiento y seguridad

Compaq

Compaq 1850R - ProLiant - 128 MB RAM Manual de usuario

Compaq

Compaq ProLiant 4500 Servers Manual

Compaq

Compaq 6000 - ProLiant - 128 MB RAM Guía de inicio rápido

Compaq

Compaq Evo Thin Client t20 Hoja de especificaciones

Compaq

Compaq CL380 - ProLiant - 256 MB RAM Guía de seguridad

Compaq

Compaq ML330 - ProLiant - G3 Guía de referencia rápida

Compaq

Compaq ProLiant 8000 Manual

Compaq

Compaq ML530 - ProLiant - 128 MB RAM Manual de usuario

Compaq

Compaq AlphaServer DS10 Hoja de información del producto

Compaq

Compaq ProSignia 500 Manual

Compaq

Compaq ProLiant 3000 Instrucciones de funcionamiento y seguridad

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario

Planet

Planet NAS-7410 Manual de usuario
