QuickSpecs Compaq iPAQ Microportable Projector MP1410
DA-11000 Canada — Version 1 — October 15, 2001
1
QuickSpecs Compaq iPAQ Microportable Projector MP1410
DA-11000 Canada — Version 1 — October 15, 2001
2
M
ODELS
Compaq iPAQ Microportable Projector MP1410
230315-001
Option Part Numbers
246161-001 – iPAQ Home Theater Kit HT110
246162-001 – iPAQ Multimedia Adapter Kit MMA110
253364-001 – Deluxe Carrying Case
253365-001 – Lamp L50
A
T A
G
LANCE
• 1.95 kg (4.3 lbs)/444.5 cubic cm (175 cubic in)
• 800 ANSI, 950 Peak Lumens
• Texas Instruments DLP technology
• Native SVGA resolution
• One-year worldwide limited warranty with Advanced Unit Replacement Program
Note: Certain restrictions and exclusions apply. For details, consult the Product Information Centre at 1-888-88-COMPAQ.
QuickSpecs Compaq iPAQ Microportable Projector MP1410
DA-11000 Canada — Version 1 — October 15, 2001
3
S
PECIFICATIONS
Brightness in Lumens (ANSI) 800 ANSI, 950 Peak Lumens
Display Resolution Displays native SVGA (800 x 600) resolution but will automatically scale up from VGA or scale down from XGA to
fill screen. Will also scale from Macintosh 832 x 624 compatible.
Audible Noise Level 36 dB (Decibels)
Image Quality Technology Texas Instruments Digital Light Processing (DLP)
technology
Contrast 500:1 contrast full-on; 150:1 checkerboard
Colour SMPTE-C – 24 bit 16.7M
White Point 7200°Kelvin
Uniformity 80%
Plug and Play Yes
Lens Type Fixed Focal Length (adjustable focus)
Throw Ration (D/W) 1.75:1
Lens Height 15.18 cm (6 in)
Throw distance 3´ to 30´
Offset 125% of image above centreline
Focus Manual focus via focus ring around lens
Keystoning Digital keystone correction
Portability General Fits in existing notebook carrying case along with
notebook computer. Additional projector bag also included.
Size/Volume (HxWxD) 20.9 x 6.25 x 22.84 cm and 2,861 cubic cm (8.25 x 2.5 x 9
in and 175 cubic in)
Weight 1.95 kg (4.3 lbs)
Casing Magnesium
(Stronger than plastics; 30% lighter than aluminum)
Connectivity Signal Interface Standard analog VGA cable and DFP standard cable
User Interface Standard Compaq 3 button OSD (includes zoom and
keystone correction), Power and Resynch
Standards Supported VGA and DFP
USB Capabilities 8-pin to USB/RS-232 cable included with optional
Multimedia Adapter for remote mouse functions
QuickSpecs Compaq iPAQ Microportable Projector MP1410
DA-11000 Canada — Version 1 — October 15, 2001
4
S
PECIFICATIONS
(continued)
Approvals/Certifications CE Yes
C.I.S.P.R. Yes
VDE / TUV Yes
UL Approval Yes
FCC Class B Approval Yes
On-Screen Controls Yes
Language Selection English Yes
German Yes
French Yes
Spanish Yes
Italian Yes
Dutch Yes
Japanese Yes
Chinese Yes
User Controls Brightness, Contrast Yes
Positioning Yes
Keystone Correction Yes
Digital Zoom Yes
Clock Yes
Clock Phase Yes
Colour Temperature Yes
Picture Control Yes
HDTV Settings Yes
Menu Location Control Yes
Power Saver Yes
Lamp Hours Yes
Lamp Hours Reset Yes
Standby Lamp Delay Yes
Serial Number Yes
Master Reset Yes
Image Control (upside down, reverse, upside down
and reversed) Yes
Tilt Feature Up to 10 degrees
Horizontal Frequency 15 to 69 kHz for analog signals and 15 to 60 kHz for digital signals
Vertical Frequency 48 to 85 kHz for analog signals and 48 to 75 kHz for digital signals
Power Consumption 15 Watts (standby)/185 Watts (full power)
Operating Temperature 10°to 40°C (50°to 104°F) (sea level)
Operating Humidity 20% to 80%
QuickSpecs Compaq iPAQ Microportable Projector MP1410
DA-11000 Canada — Version 1 — October 15, 2001
5
S
PECIFICATIONS
(continued)
Video Projector is capable of displaying video from a VGA or DFP source (ex. DVD on Portable PC). Video and S-Video
capability (from DVD, Camcorder, or VCR) with optional iPAQ Home Theater Kit HT110 or through optional iPAQ
Multimedia Adapter Kit MMA110
HDTV Support 720p, 1080i
Audio Laptop or external audio source, or the optional Multimedia Adapter with integrated 8 Watt Premier •Sound
system speaker
Power supply 90V to 255V Fully US and European compliant (auto switching): warm restrike after 45 seconds
Lamp/Module User Replaceable
Tripod Mount Yes
Warranty The MP1410 projector comes with a one-year worldwide limited warranty. In North America, Europe and Asia
Pacific, the Advanced Unit Replacement program offers a new or “like new” replacement of a defective unit in 48
hours during the one-year warranty period. In all other regions, a replacement is available by mail-in. There is a
180-day standard bulb warranty. Within the bulb warranty period, defective bulbs will be replaced via overnight
shipment. Multimedia adapter and Home Theater Kit come with a one-year worldwide limited warranty. Compaq
telephone hotline support is available 7 x 24 (terms and conditions vary from region to region).
Note: Certain restrictions and exclusions apply. For details, consult the Product Information Centre at 1-888-88-
COMPAQ.
Compaq PCs use genuine Microsoft
Windows
www.microsoft.com/piracy/howtotell
2001 Compaq Canada Corporation. All rights reserved. Compaq is a trademark of Compaq Computer Corporation. Microsoft and Windows are trademarks
of Microsoft Corporation in the U.S. and other countries. The information in this publication is subject to change without notice. Printed in Canada.
