Commax CMV-70MX Manual de usuario

User Manual

C M V - 7 0 M X ( H o m e Io T )

•

Thank you for purchasing COMMAX products.

•

Please carefully read this User’s Guide (in particular, prec autions fo r safety) before using a product and follow

instructions to use a product exactly .

•

The com pany is not responsible for any safety accidents caused by abnorm al operation of the product.

www.safemag.ru

Table of Contents

Warnings and Cautions 2

1. Start

1.1. Parts Name 4

1.2. Screen Composition 5

1.3. Button at Buttom of Home screen 5

1.4. Home Screen Composition (Set Contol Area) 6

1.5. Home Screen Composition (Value of Information Area) 7

1.6. Setting WIFI 9

1.7. Registration 10

1.8. How to use Smartphone 11

2. Set control 13

2.1. Adding another device 13

2.2. Moving device or deleting 13

2.3. Device setting and control 13

3. Calling 14

3.1. Screen Composition 14

3.2. Front Door 16

3.3. Guard Station 17

3.4. Telephone records 18

3.5. Answering by Smart phone 18

4. Security 19

4.1. Emergency 19

4.2. Away mode 20

4.3. Anti-Crime mode 22

4.4 CCTV 23

4.5. Emergency Record 24

4.6. Visitor 25

5. Home IoT 27

5.1. Home IoT Log-in 27

5.2. Set up screen 27

5.3. Wireless device register / delete 27

5.4. Wireless device monitoring and control 28

5.5 Mode set up and control(Mode) 29

5.6. Reserved control set up (IF-RUN) 29

6. Convinient function 31

6.1. Calculator 31

6.2. Voice Recorder 32

7. Setting 33

7.1. Setting 33

7.2. P/W change 33

7.3. Other set up 34

7.4. Wi-fi

fi connection 34

7.5. Setting the screen 35

7.6. Set language and key 35

7.7. Setting the date and time 36

7.8. System Information 36

8. Register / Disable Wireless Device 37

9. Installation 44

10. Wiring Diagram and components 45

11. Specification 46

User’s Guide

B-type equipment

This unit getting the EMC registration as a home unit can be

used in not only residential place but also every area.

www.safemag.ru

Warnings and caution

Please follow the things described below in order to prevent any

danger or property damage.

Prohibition.

No disassembly

No touch

Must follow strictly.

Showspluggingout the power cord

without an exception

Shows the warning and caution for an electric shock.

Shows the warning and caution for a fire.

Warning

Please plug out the power

cable from the socket when

not using it for a long period

of time.

·It may shorten the product

lifespan or cause a fire.

Please don’t use and connect When installing the product

this product with other that generates heat, please

products with different rated install the product away from

voltage

the wall (10cm) for the

·It may cause a disorder or ventilation.

fire.

·It may cause a fire due to

the increased internal

temperature.

Please don’t install the

product with the lightening

andthunder.

·It may cause an electric

shock or fire.

Please don’t install the

product in the place where

there is much oil, smoke or

humidity.

·It may cause an electric

shock or fire.

Power & Installation

www.safemag.ru

Caution

Please plug the power cable

firmly into the inner end

·It may cause a fire.

Please hold the plug tightly

when unplugging the power

cable (a part of the copper

wire may be disconnected if

the grabbing is only made on

the cord when pulling out the

cable).

·It may cause an electric

shock or fire

When connecting the power When installing the product,

cables after cutting the cable, please fix it firmly while using

please install the product with the wall-mounting unit and

power off screws.

·It may cause an electric ·It may cause an injury from

shock or fire the falling object.

Please be careful when using Please check the use voltage Please avoid direct rays of the Please don’t install the

an AC circuit breaker since and current for the DC-only sun or heating devices at a product on an unstable place

there is a possibility of an pr oducts and use the time of installation. or small support board.

electricshock.

appropriate rectifier.

·It may cause a fire. ·It may cause an injury if it

·It may cause a fire. falls down while in use.

Please use only the designated

batteries for the products of

using DC power.

·It may cause an electric

shock or fire.

Warning

Please don’t

disassemble,

repair or rebuild this product

arbitrarily (please contact the

service center if a repair is

needed.

·It may cause an electric

If an abnormal sound, burning

smell or smoke is coming out

of the product, please plug out

the power cable and contact a

servicecenter.

·It may cause an electric

shock or fire.

Please don’t insert any

metallic or burnable materials

into the ventilation hole.

·It may cause an electric

shock or fire.

Please use the designated

connection cable within the

maximum calling distance

designated for the product

·It may reduce the product

performance.

Cleaning & Use

Power & Installation

Cleaning & Use

www.safemag.ru

Start

1.1.

Parts Name

CD Monitor

Ci Speaker

@ Emergency

® Guard Station

® Door Release

® Calling

Home

® MIC

® Power On/Off switch

Connecting Terminal

www.safemag.ru

1.2.

Screen Composition

Press Button

Moving screen by touching

1.3. Button at Bottom of Home Screen

Return Home Screen

View of Running screen

Back

Alert Icon

Icon shows according to each event.

Detailed Information would be shown when dragging down while pushing information line on upper screen.

Failure on System access

Emergency

Success on System access

Captured visitor’s Image

Failure on adding telephone no.

Miss-call

Success on adding telephone no.

Alarm set

www.safemag.ru

1.4.

Home Screen Composition (Set Contol Area)

Away mode

Setting away mode

Security

Setting security sensor

Emergency

Alert when emergency situation happens

Home IoT

Setting wireless device

All Apps

All Application ist

www.safemag.ru

1.5.

Home Screen Composition (Value of Information Area)

Value of Infomationain Area(Main)

Value of Info.(sub)

Showing application can be different according to area.

Wireless Device shows when Wi-Fi connects.

Value of Information Area

Clock

1) The current time and date is shown on display.

Weather Information

Weather condition is shown on display.

(Default : Seoul)

www.safemag.ru

Showing all value of information

Touch this area

Touch area of Value of Information (sub).

You can check all information on viewer page by scrolling.

Setting information Can set the detail about value of information by clicking button.

Setting information

Setting area

1) You can set area about whether.

Select value of information

Can set value of information.

Press 'Confirm’ button after choosing value of Information that you want to show.

(At least one information should be selected.)

www.safemag.ru
