Commax AP-2RAG Manual de usuario

Audio Phone AP-2RAG

User Manual

•Thank you for purchasing COMMAX products.

•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

•The company is not responsible for any safety accidents caused by abnormal operation of the product.

To prevent fire or shock hazard, do not expose

This symbol is intended to alert the use to the

“

“dangerous Voltage”

”

within the product’s enclose that

may be of sufficient magnitude to constitute a risk of

This symbol is intended to alert the use to the

accompanying the appliance

1. W arnings and Caution

the unit to rain or moisture.

presence of uninsulated

electric shock to persons.

presence of important operating and maintemance

(servicing) instructions in the literature

2. Overview

CAUTION : To reduce the risk of electric shock, do not

personnel.

caution

Risk of electric shock

do not open

part inside refer servicing to qualified service

remove cover(or back) no user-serviceable

3. Wiring

Non polarity

Installation

* Caution

Do not place the handset close to your ear and

operate the hook switch.

You may damage your hearing because of the sound

produced during product operation.

4. Operation

Call from a lobby phone

• When the lobby phone pages, you can hear the ring tone.

• When you pick up the handset, you can talk to a visitor at the lobby phone.

• You can open the door if you press the door release button or hook switch while you are

talking to a visitor at the lobby phone.

• When you finish the call, please hang up.

Call from a guard station

•When the guard station pages, you can hear the melody.

•When you pick up the handset, you can talk to guard.

• When you finish the call, please hang up.

Call a guard station

•When you pick up the handset, it pages the guard station automatically.

At that time, you can hear the recall sound from the handset.

•When the guard station answers your call, you can talk to guard.

•If you want to talk to other household units, the guard station can transfer

your call during the call with guard.

• When you finish the call, please hang up.

Power source

From floor distributor

Paging sound Lobby : Electric chime bell, Guard : Melody

Ø)

Operation Temp. 0°C ~ +40°C

Distance

Transmission 2 wires with non-polarity

Dimension(mm)

With handset : 60(W) x 210(H) x 48(D)

100m( 0.65

Printed In Korea / 2019.05.105

513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea

Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133

Web site : www.commax.com

Edited 2019.05.23
