Comelit 2703U Manual de usuario

Door-entry phone art. 2703U

TECHNICAL

MANUAL

Warning

Intended use

This Comelit product was designed for use in the creation of audio and video communication systems in residential,

commercial or industrial settings and in public buildings or buildings used by the public.

Installation

All activities connected to the installation of Comelit products must be carried out by qualiﬁed technical personnel, with

careful observation of the indications provided in the manuals / instruction sheets supplied with those products.

Wires

Use wires with a cross-section suited to the distances involved, observing the instructions provided in the system

manual.

We advise against running the system wires through the same duct as the power cables (230V or higher).

Safe usage

To ensure Comelit products are used safely:

• carefully observe the indications provided in the manuals / instruction sheets

• make sure the system created using Comelit products has not been tampered with / damaged.

Maintenance

Comelit products do not require maintenance aside from routine cleaning, which should be carried out in accordance

with the indications provided in the manuals / instruction sheets.

Any repair work must be carried out

• for the products themselves, exclusively by Comelit Group S.p.A.,

• for systems, by qualiﬁed technical personnel.

Disclaimer

Comelit Group S.p.A. does not assume any responsibility for

• any usage other than the intended use

• non-observance of the indications and warnings contained in this manual / instruction sheet.

Comelit Group S.p.A. nonetheless reserves the right to change the information provided in this manual / instruction

sheet at any time and without prior notice

Description

Universal door-entry phone, compatible with most of the door-entry phones produced by leading international manufacturers.

Ideal in door-entry phone system replacements and repairs.

Fitted with door-open push button and an extra button for additional services with independent common. Electronic ringtone.

3 position ringtone / Privacy service selector, activation of the Privacy function is shown by a red indicator appearing. Can be

used for systems with positive common or systems with negative common.

Dimensions: 103 x 190 x 30 mm

1. Loudspeaker

2. Audio hook

3. Three position selector:

High position: Maximum ringtone volume

Middle position: Medium ringtone volume

Low position: Privacy function activation (Privacy service

means exclusion of the call ringtone from the external

unit and switchboard)

4. Red mark: Privacy enabled

5. P1 (See “Use for various purposes of button P1”)

6. Key button

7. TM2 Loudspeaker volume control (Do not change)

8. TM1 Microphone volume control

9. Terminal block:

ELoudspeaker

DCall

CCommon

BCondenser microphone

ALock release

C2 P2 Button P1 C. NO. 24V 100mA

10. Ringtone / Privacy service selector

11. Ringtone selector:

MRingtone type A (Default)

ERingtone type B

11.

TM2

TM1

10.

max 7 cm

32D2C

cm 160

cm 130

2B2A1

1CLACK!

CLACK!

2703U

Installation

Use for various purposes of button P1

COMELIT 2703U A B C D E E

ACET 5 10 2 9 7 M

ALCAD TEL-001 - TEL002 1 3 2 5 4 E

AMPER D A C E B M

ATEA 2 4 3 5 1 M

AUTA 10 3 4 12 7 M

AUTA TF92 10 3 4 12 7 E

AUTELCO P5 a 1 2 b M

BELL SYSTEM TELEPHONE Z R O I T M

BITRON 9 2 6 C7 1 E

BOGEN T 1 3 6 2 M

BPT 9 9 5 7 8 E

BPT 2 1 4 3 5 M

CENTRAMATIC 4 2 1 5 3 M

CITESA 1 4 C B 3 M

CITOVOX 5 10 9 T 7 M

COFREL (LT TERRANEO) T1 1 3 6 2 M

COFREL (LT TERRANEO) 6 4 1 5 3 E

COFREL 600 /603 (LT TERRANEO) T 1 3 6 2 M

COMELIT VOX 2100 /2102 /2103 P1 3 4 1 2 M

COMELIT VOX 2101 /2104 P1 3 4 S 2 E

COMELIT CIAO 2300 /2301 /2302 P1 3 4 S 2 E

COMELIT CIAO 2304 P1 3 4 1 2 M

COMELIT OKAY 2402W /2404W /2405W P1 3 4 S 2 E

COMELIT STYLE 2602 /2602E P1 3 4 S 2 E

COMELIT STYLE 2603U A B C D E E/M

ELBEX MIC LOW + SPEC M

ELVOX 2 6 9 + 4 M

ELVOX 7 2 4 6 1 M

ELVOX 6200 7 2 3 6E 1 E

ENTRA 97 1 2 3 5 6 M

ENTRYPHONE 3 P F,B,G 4 L M

ERICSSON DEPN 40101 5 3 2 1 4 M

ERICSSON DEPN 60121 3 5 1 4 7 M

FARFISA 5 1 3 6 2 M

FERMAX GONDOLA 4 1 3 V/5 2 M

FERMAX REKTO TF-4 P A C E B M

FRINGE 2 3 1 4,* 6 E/M

COMELIT 2703U A B C D E E

GAME P 2 3 Z 1 M

GIRO 2 3 1 4 6 M

GOLMAR X M A N S E/M

GOLMAR C2 5 3 7 10 E

GOLMAR 11 5 3 12 4 M

GOLMAR T-600 T 1 3 6 2 M

GOLAMR T810B P1 5 3 7 10 M

GOLAMR T-2800 4 5 3 7 10 M

LT TERRANEO (COFREL) T1 1 3 6 2 M

LT TERRANEO (COFREL) 6 4 1 5 3 E

LT TERRANEO (COFREL) 600 /603 T 1 3 6 2 M

MM DI MARCHESI 1 3 2 5 4 M

OSTELVI 9 2 6 7 1 M

PORMAT 4 3 2 V 1 M

RIPOLLES 3 1 8 4 2 M

RITTO ELEGANT 40518 11 12 13 15 14 E

SAFNAT 4 1 2 V 3 M

SELTI 5 1 3 6 2 M

SIEDLE HT611-01 I 12 9/C 7 11 M

SPRINT “/“ 1 3 6 2 M

STR NH200 1 M O T S M

STR NH205 1 M O T S E

TAGRA 8 2 6 4 1 M

TEGUI GL 3 4 2 1 5 M

TEGUI HORIZON 3 4 2 1 5 E/M

TELEVES 4 2 3 T 1 M

TESLA DDZ 85 1 2 3 4 6 M

TESLA DDZ 93 Z 2 3 4 6 M

TUNE 8 2 6 4 1 M

URMET 730/1 9 2 6 7 1 M

URMET DOMUS 1131-1132-1133 9 2 6 CA 1 E

URMET DOMUS 1130 9 2 10 7 1 M

URMET DOMUS 1134 9 2 6 CA 1 E

VIDEX 5 1 3 4 2 E

VIDEX 5 1 7 6 2 M

YUS PHONE EL T - B/PT R M

Compatibility table

CERTIFIED MANAGEMENT SYSTEMS

www.comelitgroup.com

Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy

1ª edizione 09/2016

cod. 2G40001816
