Using the SC6PLUS printer and PC software

•

Introduction

The Stuart S 6PLUS colony counter consists of a touch-

sensitive illuminated receiver plate and keypad with a digital

LED display. Pressure applied to the receiver plate by marking

a colony registers a count indicated by an audible bleep and

advance on the digital display.

To give a more permanent record of the colony counts, the

counting results together with plate averages and statistics

can be printed on the accessory printer or alternatively sent

to a computer via USB and viewed using the S 6PLUS

software.

We describe here how to use the S 6PLUS colony counter with

the accessory printer and P software.

•

Using the printer

If using the accessory printer, connect the printer to the socket on the rear of the unit and

connect the printer to the mains supply. The power indicator should illuminate.

To print individual counts:

•ount the colonies present on the plate in the usual way then press the save key to

confirm. The unit will beep and the display will show three dashes ---.

•Press the print key. The printer will print the count of the plate.

•To clear the counts, press the save key then press and hold the correct/reset key. The

unit will beep and reset to 0.

To print the results of several counts:

•ount the colonies on the first plate then press the save

key twice.

•Repeat for the remaining plates but after the last count

press the save key only once. The individual counts are

saved as in the averaging function and the display ends

with ---.

•Press the print key. The printer will print the counts of all

the plates together with the population and sample

standard deviations, % Vs, maximum and minimum

counts as shown in the example opposite.

•To clear the memory, press and hold the correct/reset

key. The unit beeps twice and resets the count to 0. The memory is cleared of the

saved counts.

Using the SC6PLUS printer and PC software

cptechsupport@coleparmer.com | Tel: +44 (0)1785 810433 | 05/2017

•

Using the PC software

If intending to use the S 6PLUS software, follow the instructions for installing the software

given at the following link:

http://www.stuart-equipment.com/adminimages/S 6PLUS_P software_Setup(1).pdf.

After installing the software, connect the unit to a P using the supplied USB cable. The

S 6PLUS software screen will be displayed on the computer. The icons perform the

following functions:

Save the data as a text (txt) file for import into a

spreadsheet.

lear the current data.

Go to the Stuart website

To print individual counts to the PC:

•ount the colonies on the plates then press the save key to confirm. The unit will beep

and the display will show three dashes ---.

•Press the print key. The software will display the counts for Dish 1.

•To clear the counts on the unit, press and hold the correct/reset key. The unit beeps

twice and resets the count to 0.

•To clear the counts in the S 6PLUS software, click on the red cross icon to clear the

display.

To print the results of several counts to the PC:

•ount the colonies on the first plate then press the

save key twice.

•Repeat for the remaining plates but after the last

count press the save key only once. The individual

counts are saved as in the averaging function and

the display ends with ---.

•Press the print key. The software will display the

counts of all the plates.

•In the S 6PLUS software, click the file save icon and save the data. The data is saved

as a .txt file in the selected location.
