Cocoon HE161512 Manual de usuario
VIRTUAL REALITY
CAMERA
I
N
S
T
R
U
C
T
I
O
N
M
A
N
U
A
L
Model Number: HE161512
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a period
of 12 monthsfrom the date of purchase. Defects that occur within this warranty period,
under normal use and care, will be repaired, replaced or refunded at our discretion.
The benefits conferred by this warranty are in addition to all rights and remedies in respect
of the product that the consumer has under the Competition and Consumer Act 2010 and
similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage.You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
AFTER SALES SUPPORT
YEAR WARRANTY
1
customercare@winplus.com.au1300 663 907
AUS
VIRTUAL REALITY 360º CAMERA
MODEL: HE161512 PRODUCT CODE: 55406 09/2016
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a period
of 12 monthsfrom the date of purchase. Defects that occur within this warranty period,
under normal use and care, will be repaired, replaced or refunded at our discretion.
The benefits conferred by this warranty are in addition to all rights and remedies in respect
of the product that the consumer has under the Competition and Consumer Act 2010 and
similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage.You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
AFTER SALES SUPPORT
YEAR WARRANTY
1
customercare@winplus.com.au1300 663 907
AUS
VIRTUAL REALITY 360º CAMERA
MODEL: HE161512 PRODUCT CODE: 55406 09/2016
Warranty Note
If you experience any issues with this product, or it’s
performance is not what you had expected, please
contact us at Winplus before returning the item to the
store.
It is likely that we can resolve any problems for you via
phone or email.
We can be reached on:
Phone: 1300 663 907 (Mon - Fri; 8:30am - 6:00pm EST)
Email: [email protected]
Web: www.winplus.com.au
Important
Getting the most out of your Camera:
Read the manual carefully
It will help you get set up with ease
Visit www.winplus.com.au
We’ve got additional support guides online
Call After Sales Support - 1300 663 907
Available Monday - Friday, 8:30am - 6:00pm AEST
We’re always happy to help
4
After Sales Support
1300 663 907 Model Number HE161512 09/2016
customercare@winplus.com.au
Safety Instructions
Read this manual thoroughly before rst use and keep it in a safe place for future reference,
along with warranty card, purchase receipt and packaging. The safety precautions enclosed
herein reduce the risk of re, electric shock and injury when correctly adhered to.
Follow all instructions and take notice of all warnings to reduce risk of re or electric shock.
• Keep the Virtual Reality 360 Camera away from liquid.
• Keep away from heat sources such as heaters and ovens.
• Do not drop or jar the Virtual Reality 360 Camera.
• Dropping or rough use of the unit will cause damage.
• Do not place near strong magnets or strong electric currents.
• In the case of improper usage or if you have opened, altered and repaired the product
yourself, all guarantees are void.
• The supplier does not accept responsibility for additional or consequential damage other
than covered by legal product responsibility.
• The supplier is not responsible for the end use of this product including any improper use
or when used for purposes that are not specied.
• When using your Cocoon Virtual Reality 360º Camera as part of your active lifestyle,
always be aware of your surroundings to avoid injury to yourself and others, and to
prevent damage to your camera.
5
After Sales Support
1300 663 907 Model Number HE161512 09/2016
customercare@winplus.com.au
Contents
Warranty Details 2
Safety Instructions 4
Parts List 6
Technical Specications 6
Features 6
Product Overview 7
1.1 Virtual Reality 360º Camera Front and Back View 7
1.2 Virtual Reality 360º Camera Side Views 7
1.3 Virtual Reality 360º Camera Top and Bottom View 8
1.4 LCD Display 8
Operation 9
2.1 Charging your Camera 9
2.2 Using your Camera 9
2.3 Camera Menu Settings 10
3.1 Using your Camera with your Smartphone 10
3.2 Cocoon360 APP Interface 12
3.3 Taking Photos and Recording Videos 13
3.4 Cocoon360 APP Viewing Modes Overview 15
3.5 Downloading Photos and Video 17
3.6 Downloading Photos and Videos to your PC or Mac 17
3.7 Viewing and Converting Videos on your PC 17
FAQs 18
Repair and Refurbished Goods or Parts Notice 19
For the most up to date version of this manual, please visit www.winplus.com.au
6
After Sales Support
1300 663 907 Model Number HE161512 09/2016
customercare@winplus.com.au
Parts List
Technical Specications
Features
1x Virtual Reality 360 Camera
1x Tripod
1x USB Charging Cable
1x Carry Case
1x Instruction Manual*
1x Getting Started Guide*
1x Warranty Certicate*
*Not shown
Lens Aperture: F 2.0
Lens Eective Focal Length: f=1.1mm
Lens View Angle: 2x 220 degrees
LCD Monitor Size: 0.96”
LCD Resolution: 128 x 64
Photo Resolution (JPG): 3008 x 1504
Video Resolution (MOV): 1920 x 960 30 fps
Sensor: 10MP Combined (2 x 5MP)
Frequency: 50HZ/PAL
Microphone: Built-in
External Memory: MicroSD card up to 64GB (not included)
Battery Type: Built-in Lithium-Ion 1500mAh Battery
Battery Life: 1 hour per charge
Charging Time: 3 Hours
Dimensions: 60 x 50 x 45mm
Weight: 105g
Software: ‘COCOON360’ App
• Full 360⁰ recording horizontally and vertically
• Combine with VR headset (sold separately) for complete 3D immersion
• Custom APP converts video into 3D VR on the go
• Control your camera via mobile APP
• Also view scrollable image to pan around in 360 degrees
• Built in Wi-Fi for live view, playback, download to smartphone
• Works with iOS and Android smartphones
7
After Sales Support
1300 663 907 Model Number HE161512 09/2016
customercare@winplus.com.au
1
2
4
3
1 2
Product Overview
1. Lens 1 2. Microphone 3. Speaker 4. Lens 2
1. Charging Port 2. Micro SD Port
1.1 Virtual Reality 360º Camera Front and Back View
1.2 Virtual Reality 360º Camera Side Views
8
After Sales Support
1300 663 907 Model Number HE161512 09/2016
customercare@winplus.com.au
Product Overview
2
2
1
1
4
3
3
4
5
57
8
9
6
1. Power/Charging
Indicator (Blue)
2. Power/Mode Switch
3. Wi-Fi Button/Menu
Button
4. Wi-Fi Indicator (Red)
5. LCD Display
6. Shutter Indicator (Red)
7. Shutter Button/Select
Button
8. Reset Button
9. Tripod Mount
1. Mode Indicator
2. Recording Time
3. Date
4. Battery Indicator
5. Time
1.3 Virtual Reality 360º Camera Top and Bottom View
1.4 LCD Display
9
After Sales Support
1300 663 907 Model Number HE161512 09/2016
customercare@winplus.com.au
Operation
IMPORTANT NOTE: You must insert a Micro SD Card (not included) in order to use this
product. Class 6 or Class 10 Recommended (Up to 64GB).
2.1 Charging your Camera
a. Plug one end of the Charging Cable into the Micro USB Port on the Camera
b. Plug the other end of the Charging Cable to your PC’s USB Port
NOTE: Power indicator will turn blue when camera is charging
c. Once the indicator has turned o, your camera is fully charged
NOTE: Please charge camera for 5 hours before rst use
2.2 Using your Camera
Insert Micro SD Card (not included):
a. Insert a Micro SD card into the Micro SD Card Slot on the
Camera
NOTE: Always ensure your Camera is switched off before inserting or
ejecting a Micro SD Card
Turning on your Camera
a. Press and hold the Power Button for 3 Seconds. The LCD Screen will turn on and
the Camera will beep once indicating it is powered on
NOTE: To turn off your camera, hold the Power Button for 3 Seconds; ‘Goodbye’ will
appear on the LCD Screen and Camera will then switch off
Photo Mode
a. Quickly press the Power Button to switch between Photo and Video Modes
b. Push the Shutter Button to take a photo. The camera will beep and indicator will
ash indicating a photo was taken
Video Mode
a. Quickly press the Power Button to switch between Photo and Video Modes
b. Push the Shutter Button to start recording a video.
NOTE: The red indicator will blink whist recording
c. Push the Shutter Button again to stop recording. The red indicator will stop
blinking and the timer on the LCD display will pause.
NOTE: The arrow above the LCD screen indicates the direction of the front lens
10
After Sales Support
1300 663 907 Model Number HE161512 09/2016
customercare@winplus.com.au
Operation
2.3 Camera Menu Settings
a. To enter into Menu Settings, press and hold the Wi-Fi Button/Menu Button for 3
seconds.
b. Press to navigate the Menu Settings
c. Press to select
NOTE: To return back to previous page, or exit the Menu Settings, hold the Wi-Fi Button/
Menu Button for 3 seconds
Power Save: You may set your Camera to enter into Power Save Mode after a certain
period of time has lapsed. Camera default is set to ‘OFF’.
Date & Time: Set system time for the camera manually. Camera default is set to
‘DD/MM/YY’
Language: Set system language for your Camera. Camera default is set to ‘English’
Factory Reset: Resets all Camera Settings to Default Settings
System: Check Camera System and Micro SD Card Information and memory status
Format: Format Micro SD Card
IMPORTANT NOTE: You will lose all data on your Micro SD Card if you select format.
Ensure you have downloaded the les from the Camera onto your Smartphone if you wish
to proceed with formatting. Refer to page 17 for more information on downloading photos
and images onto your Smartphone
3.1 Using your Camera with your Smartphone
Download the ‘Cocoon360’ APP:
By installing the ‘Cocoon360’ APP, you can record videos and take photos on
your smartphone via the APP, view the footage on the go and download the
les directly onto your device.
a. Download the ‘Cocoon360’ APP in your app store or scan the QR
Codes to install the APP.
Insert Micro SD Card (not included):
a. Insert a Micro SD card into the Micro SD Card Slot on the Camera
IMPORTANT NOTE: You must insert a Micro SD Card (up to 64GB
maximum - not included) in order to use this product. Class 6 or Class
10 Recommended.
