Cochlear™Nucleus®8

Sound Processor

User Guide

CP1110

DRAFT FOR RADIO LAW COMPLIANCE ONLY

D1950878_1-01_EN_N8_UG_JAPAN.indd 1D1950878_1-01_EN_N8_UG_JAPAN.indd 1 12/05/2022 3:39:50 PM12/05/2022 3:39:50 PM

Symbols used in this document

Note: Important information or advice.

Tip: Time saving hint.

Caution: Special care to be taken to ensure safety

and eectiveness. Could cause damage to

equipment.

Warning: Potential safety hazards and serious

adverse reactions. Could cause harm to person.

D1950878_1-01_EN_N8_UG_JAPAN.indd 2D1950878_1-01_EN_N8_UG_JAPAN.indd 2 12/05/2022 3:39:50 PM12/05/2022 3:39:50 PM

Nucleus 8 Sound Processor User Guide 1

Contents

Symbols used in this document��ii

About this guide �� 4

Nucleus 8 Sound Processor ��5

Power �� 6

Batteries ��6

Battery life ��7

Lock the battery module to the processing unit ��8

Lock the disposable battery module cover��9

Replace the battery module��10

Charge rechargeable batteries��14

Use the Y Battery Charger��16

Use the USB Battery Charger��18

Use��20

Connect the coil�� 20

Pair with remote devices �� 20

Nucleus Smart App �� 22

Control options�� 22

Lock the control button �� 23

Turn on and o �� 23

Change program �� 25

Change volume and sensitivity�� 25

Telecoil �� 26

Wireless accessories�� 27

Use monitor earphones �� 29

Use Phonak’s Roger™ 20 �� 32

D1950878_1-01_EN_N8_UG_JAPAN.indd 1D1950878_1-01_EN_N8_UG_JAPAN.indd 1 12/05/2022 3:39:50 PM12/05/2022 3:39:50 PM

Contents

2Nucleus 8 Sound Processor User Guide

Wear ��33

Wear your sound processor �� 33

People with two implants �� 34

People with CI600 Series implants�� 34

Personalise your sound processor�� 35

Change earhooks �� 37

Retention accessories �� 38

Attach a SoftWear pad �� 49

Sport and exercise �� 50

Travel�� 52

Flight mode �� 53

Care ��54

Regular care�� 54

Battery charger care �� 56

Headband care �� 56

Storage�� 57

Water, sand and dirt �� 58

Change microphone cover �� 60

Change the coil�� 62

Change the coil magnet �� 63

Lights and beeps ��64

Lights �� 64

Beeps�� 67

D1950878_1-01_EN_N8_UG_JAPAN.indd 2D1950878_1-01_EN_N8_UG_JAPAN.indd 2 12/05/2022 3:39:50 PM12/05/2022 3:39:50 PM

Contents

Nucleus 8 Sound Processor User Guide 3

Troubleshoot��70

Sound processor �� 70

Battery�� 77

Cautions��80

Warnings��81

For parents and carers�� 81

Sound processor and parts �� 82

Batteries �� 85

Medical treatments �� 87

Other information ��90

D1950878_1-01_EN_N8_UG_JAPAN.indd 3D1950878_1-01_EN_N8_UG_JAPAN.indd 3 12/05/2022 3:39:50 PM12/05/2022 3:39:50 PM

4Nucleus 8 Sound Processor User Guide

About this guide

This guide is intended for hearing implant recipients and their

carers using the Cochlear™ Nucleus®8 Sound Processor and

accessories. This guide can also be used as a reference by

hearing care professionals.

Note

•Refer to the relevant sections for cautions and warnings

relating to the use of the Nucleus 8 processing unit (Model

number: CP1110), batteries and other devices.

•Please also refer to your Important Information document for

essential advice that applies to Cochlear implant systems.

D1950878_1-01_EN_N8_UG_JAPAN.indd 4D1950878_1-01_EN_N8_UG_JAPAN.indd 4 12/05/2022 3:39:50 PM12/05/2022 3:39:50 PM

About this guide

Nucleus 8 Sound Processor User Guide 5

Nucleus 8 Sound Processor

1� Microphones

2� Coil

3� Magnet

4� Coil cable

5� Processing unit

6� Battery module

7�Serial number

8� Control button

9� Earhook

10� Indicator light

Warning: Sound processors and related accessories contain small

parts that alone or in combination may pose a hazard of

inhalation, choking or ingestion. Swallowing or inhaling small

parts can cause severe or fatal injuries. Use the tamper-resistant

locks to keep small parts attached to the processing unit where

available, including parts that t between the processing unit and

battery module. Always supervise children under 3 years of age

and others who may be at risk of inhalation, choking or ingestion

of small parts when they use the sound processor and related

accessories. When not in use, keep small parts, and combinations

of small parts, out of reach from children. If small parts are

swallowed or inhaled, seek immediate medical attention.

D1950878_1-01_EN_N8_UG_JAPAN.indd 5D1950878_1-01_EN_N8_UG_JAPAN.indd 5 12/05/2022 3:39:51 PM12/05/2022 3:39:51 PM

6Nucleus 8 Sound Processor User Guide

Power

Batteries

You have a choice of three battery types for the Nucleus 8

processing unit:

The disposable battery module consists

of:

ꞏCochlear Battery Cover

ꞏCochlear Battery Holder

It uses two disposable batteries and

has a tamper-resistant lock.

The Cochlear Power Extend Battery

Module, rechargeable

The Cochlear Compact Battery Module,

rechargeable

D1950878_1-01_EN_N8_UG_JAPAN.indd 6D1950878_1-01_EN_N8_UG_JAPAN.indd 6 12/05/2022 3:39:52 PM12/05/2022 3:39:52 PM

Power

Nucleus 8 Sound Processor User Guide 7

Battery life

Batteries should be replaced as needed just as you would with

any other electronic device. Battery life varies according to the

programs used each day, your implant type, the thickness of

skin covering your implant, and the size and type of battery.

A completely empty rechargeable battery will typically take up

to four hours to fully recharge.

To maintain good condition of your rechargeable battery and

extend its lifespan, it is important to know how to charge,

maintain and store your battery:

ꞏCharge battery before storing. The optimum storage

environment is a cool, dry place.

ꞏDo not discharge battery completely before recharging.

ꞏIt is not recommended to store the battery for extended

periods of time without using or charging. If you have

more than one battery, rotate the batteries through

usage.

ꞏAvoid exposure to temperature extremes and humidity

in storage and use, such as direct sunlight or inside a

parked vehicle.

The amount of charge a battery holds naturally diminishes over

time. When a battery reaches its lifespan and can no longer be

charged suciently, the charger will indicate the need for

battery replacement by a ashing orange LED indicator.

To help gain the longest life from your battery, your clinician can

set your sound processor to turn o two minutes after you take

it o your implant.

D1950878_1-01_EN_N8_UG_JAPAN.indd 7D1950878_1-01_EN_N8_UG_JAPAN.indd 7 12/05/2022 3:39:52 PM12/05/2022 3:39:52 PM

8Nucleus 8 Sound Processor User Guide

Power

Lock the battery module to the

processing unit

To increase tamper resistance, the battery module can be

locked to the processing unit.

1� Push the lock to the far left

to lock the battery module.

2� Push the lock to the far

right to unlock the battery

module.
