COBHAM Explorer 710 Manual de usuario

EXPLORER 710

User manual

98-140012-H ii

Document number: 98-140012-H

Release date: 11 February 2021

Disclaimer

Any responsibility or liability for loss or damage in connection with the use of this product and the

accompanying documentation is disclaimed by Thrane & Thrane A/S. The information in this manual is

provided for information purposes only, is subject to change without notice and may contain errors or

inaccuracies. Manuals issued by Thrane & Thrane A/S are periodically revised and updated. Anyone

relying on this information should acquire the most current version e.g. from www.cobhamsatcom.com,

Cobham SYNC Partner Portal, or from the distributor.Thrane & Thrane A/S is not responsible for the

content or accuracy of any translations or reproductions, in whole or in part, of this manual from any

other source. In the event of any discrepancies, the English version shall be the governing text.

Thrane & Thrane A/S is trading as Cobham SATCOM.

Manufacturer address

Thrane & Thrane A/S, Lundtoftegaardsvej 93 D, DK-2800, Kgs. Lyngby, Denmark

Trademark acknowledgments

•Inmarsat is a registered trademark of the International Maritime Satellite Organisation (IMSO) and is

licensed by IMSO to Inmarsat Limited and Inmarsat Ventures plc.

• Other product and company names mentioned in this manual may be trademarks or trade names of

their respective owners.

98-140012-H iii

Safety summary 1

The following general safety precautions must be observed during all phases of operation, service

and repair of this equipment. Failure to comply with these precautions or with specific warnings

elsewhere in this manual violates safety standards of design, manufacture and intended use of the

equipment. Thrane & Thrane A/S assumes no liability for the customer's failure to comply with

these requirements.

Do not operate in an explosive atmosphere

Do not operate the equipment in the presence of flammable gases or fumes. Operation of any

electrical equipment in such an environment constitutes a definite safety hazard.

Keep away from live circuits

Operating personnel must not remove equipment covers. Component replacement and internal

adjustment must be made by qualified maintenance personnel. Do not replace components with

the power cable connected. Under certain conditions, dangerous voltages may exist even with the

power cable removed. To avoid injuries, always disconnect power and discharge circuits before

touching them.

Do not service alone

Do not attempt internal service or adjustments unless another person, capable of rendering first aid

resuscitation, is present.

Do not substitute parts or modify equipment

Because of the danger of introducing additional hazards, do not substitute parts or perform any

unauthorized modification to the equipment.

Keep away from antenna front

This device emits radio frequency energy when switched on. To avoid

injury, keep a minimum safety distance of 1 m from the antenna front

when the EXPLORER 710 is on.

For information on the safety distance from the transceiver (WLAN), see

the FCC/IC Radiation Exposure statement on the next page.

Garder à l'écart de l'avant de l'antenne

Le présent appareil émet des radiofréquences lors de son utilisation. Afin d'éviter tout risque pour la

santé, une distance minimale de 1 m est nécessaire entre l'utilisateur et l'avant de l'EXPLORER 710.

Pour plus d'informations à propos de la distance de sécurité avec l'appareil (WLAN), veuillez

consulter Déclaration de l’IC sur l'exposition aux radiations sur la page suivante.

Only use approved batteries from Cobham SATCOM

Use of non approved batteries may result in explosion, fire, electrical shock or injury.

Observe marked areas

Under extreme heat conditions do not touch areas of the EXPLORER 710

that are marked with this symbol, as it may result in injury.

The terminal has been designed for full usability meaning that there are

no restrictions to which interfaces can be used simultaneously. This

means that you can use all the interfaces at once at any temperature

within -25 to 55 °C. Be aware that the terminal will get very hot when it is operated at 55 °C with all

interfaces active and it is therefore marked with a heating label.

98-140012-H iv

FCC/IC Radiation Exposure statement

WLAN: Transceiver Unit (when separated from the Antenna Unit):

This equipment complies with FCC and IC radiation exposure limits for an uncontrolled environment. This

equipment should be installed and operated at a distance greater than 20 centimeters (8 inches) between

the transceiver unit and yourself or any bystander to comply with the Radiation Exposure Requirements.

Déclaration de l’IC sur l'exposition aux radiations

WLAN: L'émetteur-récepteur (quand séparé de l'antenne) :

Le présent appareil est conforme aux limites de l’IC sur l'exposition aux rayonnements établies pour un

environnement non-contrôlé. Le présent appareil doit être installé et utilisé à une distance minimum de

20 centimètres (8 pouces) entre l'émetteur-récepteur et l'utilisateur ou tout autre individu pour être

conforme à la réglementation en matière d'exposition radiologique.

Safety note from battery supplier

Korean text:

전지

경고 : 발열 , 화재 , 폭발등의 위험을 수반할 수 있으니 다음 사항을 지켜주시기 바랍니다 .

• 화기에 가까이 하지 말 것

• 분해 , 압착 , 관통 등의 행위를 하지 말 것

• 높은 곳에서 떨어뜨리는 등 비정상적 충격을 주지 말 것

• 전지 단자에 목걸이 , 동전 , 열쇠 , 시계 등 금속 제품이 닿지 않도록 주의할 것 ( 휴대컴퓨

터용 전지가 아닌 경우 생략 가능 )

• 60°C 이상의 고온에 노출하지 말 것

휴대 기기 , 제조업체가 보증한 리튬 2 차전지 사용할 것

English translation:

Battery

Warning: Hazards such as high temperature, fire or explosion can happen. To avoid such hazards, observe

the following directions and recommendations.

• Keep away from fire.

• Do not disassemble, break or penetrate the battery.

• Do not drop the battery.

• Do not touch the terminals of the battery with conductive materials such as coins, keys, watches etc.

• Do not expose the battery to temperatures above 60 C.

• Only use Li-Ion batteries that are approved by the manufacturer.

98-140012-H v

Antenna safety instructions 2

Use only manufacturer supplied antennas.

Antenna minimum safe distance: 1 m

Antenna gain

Directional, with maximum gain of 14.6 dB with reference to isotropic.

The Federal Communications Commission has adopted a safety standard for human exposure to RF

(Radio Frequency) energy which is below the OSHA (Occupational Safety and Health Act) limits.

Antenna mounting

The antenna supplied by the manufacturer must be located such that during radio transmission, no

person or persons can come closer than the above indicated minimum safe distance to the front face of

the antenna, i.e. 1 m.

L'antenne fournie par le fabricant doit être placée de telle sorte que, durant les transmissions radio,

personne ni aucun groupe de personnes ne puisse s'approcher à une distance inférieur à la distance de

sécurité minimal indiquée ci-dessus, c.-à-d., 1 m.

To comply with current FCC RF Exposure limits, the antenna must be installed at or exceeding the

minimum safe distance shown above, and in accordance with the requirements of the antenna

manufacturer or supplier.

Antenna substitution

Do not use any other antenna than the models supplied or recommended by the manufacturer. You may

be exposing people to excess radio frequency radiation. You may contact the manufacturer for further

instructions.

Radiation warning

You, as the qualified end-user of this radio device, must control the exposure conditions of bystanders to

ensure the minimum separation distance (above) is maintained between the antenna and nearby persons,

for satisfying RF Exposure compliance. The operation of this transmitter must satisfy the requirements of

General Population/ Uncontrolled Environment. Only use the terminal when persons are at least the

minimum distance from the front face of the antenna.

WARNING! Maintain a separation distance of at least 1 m from the front

face of the antenna to a person.

98-140012-H vi

About this manual 3

Intended readers

This manual is a user manual for the EXPLORER 710. The manual is intended for anyone who is using or

intends to use the EXPLORER 710. No specific skills are required to operate the EXPLORER 710. However,

it is important that you observe all safety requirements listed in the Safety summary in the beginning of

this manual, and operate the EXPLORER 710 according to the guidelines in this manual.

Related documents

The following documents are related to this manual and to the EXPLORER 710 system.

Typography

In this manual, typography is used as indicated below:

Bold is used for the following purposes:

• To emphasize words.

Example: “Do not touch the antenna front during pointing”.

• To indicate what the user should select in the user interface.

Example: “Select Control panel > LAN and click Enable”.

Italic is used to emphasize the paragraph title in cross-references.

Example: “For further information, see Connecting Cables on page...”.

Title and description Document

number

EXPLORER 710 Getting Started, English 98-139653

EXPLORER 710 Getting Started, Deutsch (German) 98-140216

EXPLORER 710 Getting Started, Français (French) 98-140217

EXPLORER 710 Getting Started, Español (Spanish) 98-140218

EXPLORER 710 Getting Started, Русский (Russian) 98-140219

EXPLORER 710 Getting Started, 中文 (Chinese) 98-140220

EXPLORER 710 Getting Started, 日本語 (Japanese) 98-140221
