Cobalt Digital Inc 9021 Manual de usuario

Cobalt Digital Inc.

9021

Standard Definition A/D Analog

Composite, Y/C or Component to 10-bit

SDI

Owner’s Manual

9021-OM

Version: 1.1

9021 Owner’s Manual •

••

•(V 1.1) Page 2 of 22

9021 •

••

•Standard Definition A/D Analog Composite, Y/C or Component to 10-bit SDI

Owner’s Manual

•Cobalt Part Number: 9021-OM

•Document Version: 1.1

•Printed in the United States.

•Last Author: CGG

•Printing Date: 1/4/2013

The information contained in this Owner’s Manual is subject to change without notice or obligation.

Contents of this publication may not be reproduced in any form without the written permission of

Cobalt Digital Inc. Reproduction or reverse engineering of copyrighted software is prohibited.

Notice

The material in this manual is furnished for informational use only. It is subject to change without

notice and should not be construed as a commitment by Cobalt Digital Inc. Cobalt Digital Inc assumes

no responsibility or liability for errors or inaccuracies that may appear in this manual.

Trademarks

•is a registered trademark of Ross Video Limited.

•is a registered trademark of Cobalt Digital Inc.

•All other product names and any registered and unregistered trademarks mentioned in this

manual are used for identification purposes only and remain the exclusive property of

their respective owners.

9021 Owner’s Manual •

••

•(V 1.1) Page 3 of 22

Important Regulatory and Safety Notices

Before using this product and any associated equipment, refer to the “Important Safety Instructions”

listed below so as to avoid personnel injury and to prevent product damage.

Products may require specific equipment, and /or installation procedures be carried out to satisfy

certain regulatory compliance requirements. Notices have been included in this publication to call

attention to these specific requirements.

Symbol Meanings

This symbol on the equipment refers you to important operating and maintenance

(servicing) instructions within the Product Manual Documentation. Failure to heed

this information may present a major risk of damage or injury to persons or

equipment.

Warning

The symbol with the word “Warning” within the equipment manual indicates a

potentially hazardous situation, which if not avoided, could result in death or serious

injury.

Caution

The symbol with the word “Caution”within the equipment manual indicates a

potentially hazardous situation, which if not avoided, may result in minor or

moderate injury. It may also be used to alert against unsafe practices.

Notice

The symbol with the word “Notice”within the equipment manual indicates a

situation, which if not avoided, may result in major or minor equipment damage or a

situation which could place the equipment in a non-compliant operating state.

ESD

Susceptibility

This symbol is used to alert the user that an electrical or electronic device or

assembly is susceptible to damage from an ESD event.

Important Safety Instructions

Caution

This product is intended to be a component product of the openGearTM frame. Refer

to the openGearTM frame Owner’s Manual for important safety instructions regarding

the proper installation and safe operation of the frame as well as it’s component

products.

Warning

Certain parts of this equipment namely the power supply area still present a safety

hazard, with the power switch in the OFF position. To avoid electrical shock,

disconnect all A/C power cords from the chassis' rear appliance connectors before

servicing this area.

Warning

Service barriers within this product are intended to protect the operator and service

personnel from hazardous voltages. For continued safety, replace all barriers after

any servicing.

This product contains safety critical parts, which if incorrectly replaced may present

a risk of fire or electrical shock. Components contained within the product’s power

supplies and power supply area, are not intended to be customer serviced and should

be returned to the factory for repair.

To reduce the risk of fire, replacement fuses must be the same type and rating.

Only use attachments/accessories specified by the manufacturer.

9021 Owner’s Manual •

••

•(V 1.1) Page 4 of 22

Environmental Information

The equipment that you purchased required the extraction and use of natural resources for its

production. It may contain hazardous substances that could impact health and the environment.

To avoid the potential release of those substances into the environment and to diminish the need for the

extraction of natural resources, Cobalt Digital encourages you to use the appropriate take-back systems.

These systems will reuse or recycle most of the materials from your end-of-life equipment in an

environmentally friendly and health conscious manner.

The crossed-out wheeled bin symbol invites you to use these systems.

If you need more information on the collection, reuse, and recycling systems, please contact your local

or regional waste administration.

You can also contact Cobalt Digital for more information on the environmental performances of our

products.

9021 Owner’s Manual •

••

•(V 1.1) Page 5 of 22

Contents

Introduction 6

In This Chapter ..........................................................................................................................6

A Word of Thanks .....................................................................................................................6

Overview....................................................................................................................................6

Software Version .......................................................................................................................7

Functional Block Diagram.........................................................................................................8

Supported Video Formats..........................................................................................................8

Input and Output Video...............................................................................................8

Documentation Terms................................................................................................................9

Installation and Setup 10

In This Chapter ........................................................................................................................10

Static Discharge.......................................................................................................................10

Unpacking................................................................................................................................10

Rear Module Installation (Optional)........................................................................................11

Rear Module Available for 9021 .............................................................................................12

Board Installation.....................................................................................................................13

Card Control and Status...........................................................................................................14

Card Control Switches...............................................................................................14

Card Status LEDs ......................................................................................................15

Factory Default Settings ............................................................................................15

Remote Control 16

In This Chapter ........................................................................................................................16

DashBoard Control System Software ......................................................................................16

Technical Specifications 17

Service Information 18

In This Chapter ........................................................................................................................18

Troubleshooting Checklist.......................................................................................................18

Warranty and Repair Policy.....................................................................................................19

Ordering Information 21

9021 and Related Products ......................................................................................................21

Contact Cobalt Digital Inc.......................................................................................................22

Visit us at the Cobalt Digital Inc. website................................................................................22

9021 Owner’s Manual •

••

•(V 2.1) Page 6 of 22

Introduction

In This Chapter

This chapter includes the following sections:

•A Word of Thanks

•Overview

•Functional Block Diagram

•Supported Audio and Video Formats

•Documentation Terms

A Word of Thanks

Congratulations on choosing the openGearTM Standard Definition A/D Analog Composite, Y/C or

Component to 10-bit SDI. The 9021 is part of a full line of modular conversion gear for broadcast TV

environments. The Cobalt Digital openGearTM line includes video decoders and encoders, audio

embedders and de-embedders, distribution amplifiers, format converters, and much more. Cobalt

openGearTM modular conversion gear will meet your signal conversion needs now and well into the

future.

Should you have questions pertaining to the installation or operation of your 9021, please contact us at

the numbers listed on the back cover of this manual. We are happy to help with any questions regarding

this or any other openGearTM card.

Overview

The 9021 is a high quality full 10-bit analog to digital decoder for converting 525 and 625 line, analog

composite, Y/C and component signals (YPbPr) to 270 Mb 4:2:2 SDI (SMPTE 259M compliant)

output with SMPTE EDH. The user can select four different Y-C separation modes (4-line adaptive, 4-

line non-adaptive, 3-line adaptive and notch filter) for composite input and three different YPbPr inputs

(BetaCam™, MII™, or SMPTE/N10) for component inputs.

Features include differential inputs, user configurable 75-ohm input termination, user Proc. gain

controls, de-jitter filter on/off, Color Bars on/off and Pedestal on/off. User Proc adjustments can be

saved and factory defaults can be restored. The configuration controls are mounted on the card edge

for in-frame adjustments.

9021 Owner’s Manual •

••

•(V 1.1) Page 7 of 22

The input and outputs of the 9021 are the following:

Input:

One SD analog video input on three BNCs

Outputs:

Seven SD-SDI video outputs

Software Version

This manual is written for software release number 1.1.

To view the current software release number of your 9021 check the information submenu on the

front edge controls or the card info menu in Dashboard.

To upgrade your 9021 software, go to the download page at www.cobaltdigital.com to download

the latest release, and upload the file through Dashboard™(see Dashboard™user manual, 3-5).

9021 Owner’s Manual •

••

•(V 1.1) Page 8 of 22

Functional Block Diagram

This section diagrams the basic signal flow of your 9021 product.

Figure 1. Simplified Block Diagram of 9021 Functions

Supported Video Formats

Input and Output Video

The 9021 supports both NTSC and PAL formats.

Raster structure Frame Rate

486i129.97

575i125

Notes:

1. All rates displayed as frame rates, interlaced (“i”) field rates are two times the number shown.

Differential Input,

Gain & Termination

Control

10-bit 4-line

Adaptive Decode

Format and Proc

De-

Jitter

4:2:2 270 Mbit

SDI SMPTE

259M with EDH

User

Configuration

Switches

Analog

Composite,

Y/C or

Component

9021 Block Diagram

Serialize

with EDH

Micro-

processor

Bypass

Mux

9021 Owner’s Manual •

••

•(V 1.1) Page 9 of 22

Documentation Terms

The following terms are used throughout this guide:

•“Frame”refers to the HPF-9000 or 8321 20-slot frame that houses the 9021 card.

•“Operator”and “User”both refer to the person who uses the 9021.

•“Board”and “Card”all refer to the 9021 card itself, including all components and

switches.

•“System”and “Video system”refers to the mix of interconnected production and

terminal equipment in which the 9021 operates.

9021 Owner’s Manual •

••

•(V 1.1) Page 10 of 22

Installation and Setup

In This Chapter

This chapter includes the following sections:

•Static Discharge

•Unpacking

•Rear Module Installation (Optional)

•Board Installation

•BNC Connections

•Menu Structure

•Factory Defaults

Static Discharge

Whenever handling the card and other related equipment, please observe all static discharge

precautions as described in the following note:

ESD

Susceptibility

Static discharge can cause serious damage to sensitive

semiconductor devices. Avoid handling circuit boards in high

static environments such as carpeted areas, and when wearing

synthetic fiber clothing. Always exercise proper grounding

precautions when working on circuit boards and related

equipment.

Unpacking

Unpack each card you received from the shipping container, and check the contents against the packing

list to ensure that all items are included. If any items are missing or damaged, contact your sales

representative or Cobalt Digital directly.

Tabla de contenidos

Otros manuales de Convertidor de medios de Cobalt Digital Inc

Cobalt Digital Inc

Cobalt Digital Inc openGear 9015 Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BBG-1090-DEC-MPEG Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9433-EMDE-75 Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc openGear 9033-SD Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9011 Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BBG-1002-2UDX-DI Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9927-2StoH Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 5821-D Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BIDI-2H2S Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BBG-1090-TRX-MPEG Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc HD-8020 Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BBG-1002-DC-4K Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BBG-1002-UDX-DSP Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BBG-1002-UDX Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BBG-1190-DEC-MPEG Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9990-DEC-MPEG Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc HD-8019 Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9903-UDX-ADDA Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BBG-1002-UDX-FS Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BBG-1002-2UDX Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc openGear 9035 Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc opeanGear 9032 Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 6540 Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9082 Manual de usuario

Manuales populares de Convertidor de medios de otras marcas

SoundTraxx

SoundTraxx Blunami BLU-2200 Manual de usuario

SPROLINK

SPROLINK VA1 Manual de usuario

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manual de usuario

Nikon

Nikon AF-S TC-20E III Manual de usuario

Axis

Axis AXIS Q7406 Manual de usuario

Omega

Omega TAC80B-J Manual de usuario

Zoom

Zoom Thunderbolt TAC-2R Manual de usuario

OST

OST iConverter 10/100M Manual de usuario

Vertiv

Vertiv Netsure Manual de usuario

birddog

birddog MINI Manual de usuario

Roland

Roland GI-10 Manual de usuario

Wallenstein

Wallenstein WX310 Manual de usuario

Pace

Pace MSS 200-1 Manual de usuario

Solar Converters

Solar Converters EQ 12/24-50 Manual de usuario

CYP

CYP EL-7400V Manual de usuario

TIE

TIE MIDI 1i1o Manual de usuario

DCS

DCS Vivaldi Upsampler Manual de usuario

Westermo

Westermo MCW-211 SERIES Manual de usuario
