Clover CDR4450 Manual de usuario

Instruction Manual

Stand-Alone 4 Channel

Digital Video Recorder

Model CDR4450

Contents

１.Unpacking 6

About This Unit 7

２.Features 8

３.Specifications 9

４.Installation 10

４-１. What to do before Installation 10

４-２. InstallationCheckList 11

４-３. Controls and Connectors ontheDVR 12

４-４. System Connection

４-４-１. CameraConnection 16

４-４-２. Video Output Connection / VGAConnection 16

４-４-３. AudioConnection 16

４-４-４. Network Cable Connection 17

４-４-５. MouseConnection 17

４-４-６. SensorConnection 17

４-４-７. AlarmOutputConnection 17

４-５. Step by Step Installation 18

５.HowtoOperate 19

５-１. GeneralOperation 19

５-２. Remote Controller

５-３. PS/2Mouse 22

５-４. Running for the First Time

５-５. Live 25

５-５-１. Quad Split Screen Display 25

５-５-２. FullScreenDisplay 26

５-５-３. AutoSequenceDisplay 27

- 1 -

Contents

５-５-４. PAN / TILT & ZOOM

５-５-４-１. How to Connect PAN / TILT Device

５-５-４-２. HowtousePAN/TILT 29

５-５-４-３. How to use ZOOM / FOCUS 29

５-５-５. Toggle OSD ON/ OFF 30

５-６.Recording 31

５-６-１. ManualRecording 31

５-６-２. AutomaticRecording 31

５-７.Playback 32

５-７-１. SetPlaybackTime 32

５-７-２. SearchbyEvent 35

５-７-３. How to Search through Playback 36

５-８. Copying to USB 37

６.Setup 40

６-１. SetupMenu 40

６-２. CameraSetup 41

６-２-１. Channel 42

６-２-２. Display 43

６-２-３. Camera Color Option 45

６-３. RecordSetup 46

６-３-１. RecordSpeed 47

６-３-２. RecordQuality 49

６-３-３. HoldTime 50

６-３-４. RecordSchedule 51

６-４. Sensor 53

６-４-１. RelayOutput 54

６-４-２. SensorSetup 55

６-５. MotionDetection 57

６-５-１. ChannelSelection 58

６-５-２. Sensitivity Selection 59

６-５-３. RelayOutputSetup 60

６-５-４. MotionAreaSetup 61

６-５-４-１. AreasetupusingDirectionkeys 62

６-５-４-２. AreasetupusingtheMouse 63

- 2 -

Contents

６-６. ScreenSetup 64

６-６-１. BorderSetup 65

６-６-２. VideoAdjustment 65

６-６-３. SequenceSetup 65

６-７. Audio Setup 66

６-７-１. AudioRecordSetup 66

６-７-２. MuteSetup 67

６-７-３. Input / Output Volume Setup 67

６-８. SystemSetup 68

６-８-１. HardDiskSetup 68

６-８-１-１. OverwriteOption 69

６-８-１-２. FormatHDD 69

６-８-１-３. HardDiskDriveInformation 71

６-８-２. PasswordChange 72

６-８-３. TimeSet 76

６-８-３-１. TimeZoneSetup 76

６-８-３-２. TimeSetup 77

６-８-３-３. DaylightSavingOption 78

６-８-３-４. SynchronizewithNTPServer 78

６-８-４.EventList .78

６-８-５. NetworkOption 79

６-８-５-１. NetworkEnableOption 79

６-８-５-２. LocalIPSetup 80

６-８-５-３. PortSetup 83

６-８-５-４. MACAddressSetup 84

６-８-５-５. NetworkPassword 84

６-８-５-６. DDNSServerSetup 84

６-８-５-７. Network Video Quality 84

６-８-６. RS-485 Setup 85

６-８-７.PAN/TILTDeviceSetup 86

６-８-７-１. Channel/IDSetup 86

６-８-７-２. ModelOption 86

６-８-７-３. PAN/TILTTest 86

６-８-８. FirmwareUpgrade 87

６-９. Search 89

６-１０. Language 89

- 3 -

Contents

６-１１. Exit 89

７.Viewer 90

７-１. Installing / Running the Viewer 91

７-２. Player 92

７-２-１. Menu 93

７-２-２. Icons 94

７-２-３. HowtoOpenaVideoFile 95

７-２-４. HowtoSaveasAVIfile 96

７-２-５. HowtoCaptureaScreen 98

７-３. NetworkViewer 99

７-３-１. HowtoConnecttotheDVR 99

７-３-２. Menu 102

７-３-３. Icons 103

Warranty Information / How to obtain Factory Service 104

- 4 -

Contents

About this manual

This is the instruction manual for the Stand-Alone type DVR, CDR4450

This manual describes how to install and operate the CDR4450 and

provides information regarding specifications and features of this product.

Please be sure to read this manual and follow the instructions when

installing the CDR4450.

If you have any questions or problems installing, please contact

Clover Electronics at 877-327-5000.

- 5 -

Contents

.Unpacking

When unpacking the DVR Unit, please be cautious not to drop, throw or

hit with force. This may cause damage to the product that could lead to

malfunctions.

Before Installation please check if the following objects are included.

Stand-Alone DVR unit

Remote Controller & battery

Instruction manual

NetViewer CD

Adapter and screws (usage for installing HDD)

RJ-45 Cable

PS/2 Mouse

DVR CD-ROM

Remote

Adapter Manual Screws Battery

RJ-45 Cable

PS/2 Mouse

ÚIf any of the above items are missing please contact Clover Electronics

- 6 -

Contents

About This Unit

You have just purchased a state-of-the-art 4 CH Stand Alone DVR with

network connection.

The most interesting feature of this system is the USB Firmware

updating option, which enables software upgrading and software

management to be done at home with a computer and a USB drive, instead

of sending the DVR.

To enhance the user friendliness of this DVR system, the user can

operate with both the remote controller and a PS2 mouse.

We hope you have a great experience with our CDR4450. Thank you.

- 7 -

Contents

.Features

Triplex (Record / Playback / Live)

Real Time Full, Quad and Auto sequence Display mode

High Quality, Low Cost and Full Option System

StandAlone Type (Non-PC, Non-OS)

Programming MENU in OSD (On Screen Display)

Built-in Time / Date Generator

Event list of 127

Motion / Alarm detection and Schedule recording

Quick Search : Date & Time / Event

Hard Disk Drive Overwrite

RS-485 Interface for PT Camera control (Option)

Multi-user network monitoring and remote DVR controlling

(up to 2 users)

Copy and Firmware Update by USB

VGA connection

MJPEG Compression

Remote Control

- 8 -

Contents

.Specifications

Items Specifications

System Type NTSC PAL

Input 1Vp-p 75Ohm, Input BNC ¯8

VGA VGA Output ¯1

Video

Signal Output 1Vp-p 75Ohm, Input BNC ¯2

Input / Output 2 ¯RCA (1CH Input, 1CH Output)

Audio Recording Mode Mono PCM

Display Frame 60 Field per sec

(each) 50 Field per sec

(each)

Display

Display Resolution 640 ¯448 640 ¯544

Video Compression Real-Time full triplex

M-JPEG codec core

Video Resolution 640¯224 640¯272

Recording Method Continuous, Event

(Motion & Alarm detection)

Recording Field 60 Field per sec 50 Field per sec

Recording

Image File Size 3 ~ 25KB 4 ~ 27KB

Resolution 640 ¯224, 320 ¯112

Feature Real time Transmit, Remote Control

Network

Connection TCP/IP, UDP, DHCP, PPPoE

Playback Mode Live, Playback

Playback Screen

Mode Full, Quad, 9 split mode

Playback

Search Search by Date / Time, Event List

External Alarm Input Alarm Input : Terminal Block 8

Alarm

Control Alarm Output Relay Out : Terminal Block 1
