Clarke CHT718 Manual de usuario

USER INSTRUCTIONS

GC06/12

UNIVERSAL HUB/BEARING

PULLER

Model No: CHT718

Part No: 1801718

2

Parts & Service: 020 8988 7400/E-mail:[email protected] or [email protected]

INTRODUCTION

Thank you for purchasing this CLARKE product. The kit may be used for

installing seals and bearings into the hubs of most vehicles. It may also be

used for pulling hubs where the wheel flange is drilled and tapped so that the

road wheel is secured with bolts.

Please read and follow the instructions carefully. In doing so you will ensure

the safety of yourself and others around you, and you can look forward to

the product giving you long & satisfactory service.

Please keep these instructions in a safe place for future reference

KIT CONTENTS

A Sleeve 76mm (3”) HTCHT71810

B1 Cup- 86mm (3-13/32”) HTCHT71811

B2 Cup- 91mm (3-19/32”) HTCHT71812

C1 Bolt M14 x 90 HTCHT71813

D Flat Washer HTCHT71814

E Sleeve 36mm (1-7/16”) HTCHT71815

F Centre Bolt HTCHT71816

G Thrust Washers HTCHT71817

H Long Nut HTCHT71818

C2 Bolt M12 x 90 HTCHT71819

1 Disc - 55.5mm (2-3/16”)HTCHT71801

2 Disc - 59mm (2-11/32”) HTCHT71802

3 Disc - 62mm (2-7/16”) HTCHT71803

4 Disc - 65mm (2-9/16”) HTCHT71804

5 Disc - 66mm (2-19/32”) HTCHT71805

6 Disc -71.5mm (2-13/16”)HTCHT71806

7 Disc - 73mm (2-7/8”) HTCHT71807

8 Disc - 78mm (3-3/32”) HTCHT71808

9 Disc - 84mm (3-5/16”) HTCHT71809

3

Parts & Service: 020 8988 7400/E-mail:Part[email protected] or [email protected]

METHOD OF USE

WARNING: THE VEHICLE MUST BE PROPERLY PREPARED, AND

ADEQUATELY SUPPORTED ON AXLE STANDS, ON FIRM LEVEL GROUND,

BEFORE ANY OPERATION USING THIS TOOL IS PERFORMED.

INSTALLING SEALS & BEARINGS

Assemble the parts as shown in the example, selecting the components

which fit the job in hand. Ensure the large nut (H) is screwed fully on to the

bolt (F), and all components are entirely square before tightening.

HUB PULLING

It is possible to remove a hub from the swivel joint,

using the bolts (C) supplied.

The appropriate size bolts are screwed into the holes

in the wheel flange, so that they bear up against

the surface of the swivel joint.

Screw in the bolts progressively to pull off the hub.

For hubs where the wheel is mounted on studs, a

slide hammer type puller must be used.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for its intended purpose. Faulty goods

should be returned to their place of purchase. No product can be returned

to us without prior permission. This guarantee does not effect your statutory

rights.
