Clarke OBS-18DC Manual de instalación y funcionamiento

OBS-18DC Orbital Sander

Operation and Safety

Safety Practices:

Sanding dust is flammable!

Empty and clean dust bag

when not in use.

Always wear safety

goggles, protective

clothing, and a dust mask

while sanding.

Keep the dust bag

emptied. Dust generated

from sanding wood floors

can spontaneously ignite

or explode. Promptly

dispose of any sanding

dust in a metal container

clear of any combustibles.

Do not dispose in a fire.

Keep the work area well

ventilated.

Sanding/finishing wood

floors can create an

explosive or combustible

environment. Do not

operate this machine

around solvents, thinners,

fuels, floor finishes, or any

other flammable materials.

Keep hands, feet, and

loose clothing away from

all moving parts on the

machine.

Disconnect the power cord

before replacing the pad or

the abrasive.

Never leave the machine

unattended while it is

connected to a power

source.

www.clarkeus.com/rental

Application: Wood flooring maintenance and light restoration work,

especially small projects that do not require a more aggressive tool.

This tool is well suited for use on parquet floors.

Set-up and operation

Follow the steps listed below to complete a floor sanding project safely.

Step Action

Prepare the room:

Step Action

1 Countersink any nails in the flooring.

2 Tape over electrical outlets.

3 Cover doorways and windows with plastic.

4 Cover all air vents in the room (intake and

output vents).

Attach sandpaper (36 grit)

to the buffing pad. The

adhesive backing on the

sandpaper sticks to the pad.

Be sure the power cord is

unplugged any time you are

changing sandpaper.

Connect the power cord to a 3-prong outlet. Always

make sure the ON/OFF switch (interlock) is in the OFF

position when connecting power.

Position the power cord safely out of the way of the

machine by looping a section of cord through a side belt

loop.

Release the handle by

pressing up on the locking

lever. Bring the handle to a

comfortable position. Do not

lock the handle. Locking

the handle will prevent the

machine from resting easily

on the pad.

OBS-18DC Orbital Sander

Step Action

Start the sander:

Step Action

1 Stand directly behind the sander.

2 Grip one or both of the control levers securely.

3 Press the Interlock button.

4 When the motor starts, release the interlock, but

keep at least one of the control levers pressed

upward.

Slowly move the sander across the surface of the floor.

The pad will rotate quickly, so it is not necessary to move

with the grain of the wood as it is with the drum sander. The

square shape of the pad should allow you to cover the entire

floor, including the edges.

Note: Keep the sander in motion while the motor is

running to avoid damage and swirling.

When finished, release the control levers to stop the

machine.

Note: Empty the filter bag frequently to prevent a fire hazard.

Check the bag periodically to make sure it does not fill

up. Never leave the sander unattended without emptying

the bag first.

Questions or Problems?

Contact Clarke

Technical Service at

800-356-7274.

Need more

information?

The instructions on this

sheet are abbreviated

instructions only and are

provided solely as a

customer service. They

are not meant to replace

the tool’s operation

manual. If you are

unsure of the tool’s safe

and proper operation,

please request an

operator’s manual from

one of our sales

associates.
