Clarke PHS8B Manual de usuario

USER INSTRUCTIONS

ORIGINAL INSTRUCTIONS GC1216

8LITRE HAND SPRAYER

MODEL NO: PHS8B

PART NO: 3402268

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for purchasing this CLARKE Sprayer, designed for use with

insecticides or other water-based products only.

Before attempting to use this product, please read this manual thoroughly and

follow the instructions carefully. In doing so you will ensure the safety of yourself

and that of others around you, and you can look forward to your purchase

giving you long and satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission. This guarantee does not effect your

statutory rights.

GENERAL SAFETY PRECAUTIONS

1. Always thoroughly familiarise yourself with this product & its operation, and

always read and understand the instructions and warnings in this manual

before use.

2. Never use this sprayer to store or spray flammable solvent-based

chemicals.

3. Empty the contents if the sprayer is not to be used for long periods.

4. If insecticide is being sprayed, always wear a protective mask and gloves

to protect the skin and face. Never spray chemical products facing into

the wind.

5. Never spray pesticide in the direction of other people, animals or

foodstuffs.

6. Never use the sprayer for handling hot liquids and avoid operating in

excessively hot environments.

7. Always comply with any applicable insecticide manufacturers safety

instructions/directives before use.

8. Stop using the sprayer if the container or hose is found to be damaged.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

OVERVIEW

SPECIFICATION

Please note that the details and specifications contained herein, are correct

at the time of going to print. However, CLARKE International reserve the right

to change specifications at any time without prior notice.

Dimensions D x H 184 x 550 mm

Weight 1.25 kg

Volume 8 Litres

Lance Length 515 mm

Hose Length 1.19 m

Piston Material Metal/polymer

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ASSEMBLY

1. If not already fitted, clip the

shoulder strap to the attachment

points. Adjust the strap length as

required using the buckles.

2. Screw the lance assembly onto

the trigger/handle assembly.

• The other end of the hose

should already be connected

to the container.

3. Make sure that all connections

are fully hand tightened to

prevent leaks and loss of pressure.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

OPERATION

1. Unscrew the handle and cap

assembly complete in order to fill

the container with the desired

liquid.

2. Screw the cap and handle back

on firmly.

3. Release the carrying lugs from the

pump body by twisting the handle

anticlockwise.

4. Pressurise the container by

pumping the handle.

5. Squeeze the trigger to begin

spraying. When the spray

weakens, pump the handle to

maintain container pressure.

6. Push the trigger forward to lock in

position to maintain a constant

spray without needing to hold the

trigger. Slide the trigger lock back

to release.

7. Adjust the width of the spray by

twisting the tip of the nozzle.

8. If leaks or poor delivery are experienced, always check the connections.

9. Push the pump handle downward and twist to engage the carrying lugs in

the cap when lifting the unit.

AFTER USE

After use, the sprayer should be flushed thoroughly with clean water to avoid

the possibility of blockages from product residue, or any cross-contamination

between different products. Store in a cool place out of reach of children.

If not used for long periods or used continuously for several days, add a light

smear of vaseline to the sealing washers and moving parts to reduce wear

and assist free movement.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

COMPONENT PARTS

No Description No Description

1 Handle Cap 11 Inner Hose

2Handle 12Hose

3 Aluminium Shaft 13 Tank

4 Pump Cap 14 Trigger

5 O-Ring Base 15 Lance

6 Inner O-Ring 16 Nozzle

7 Pin 17 Strainer

8 Pump 18 Safety Valve

9 Pump O-Ring 19 Safety Valve Gasket

10 Valve
