Clarke LOGBUSTER V6 Manual de instrucciones

OPERATION & MAINTENANCE

INSTRUCTIONS

ORIGINAL INSTRUCTIONS LS1218 - ISS 1

LOG SPLITTER

MODEL NO: LOGBUSTER V6

PART NO: 3402150

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for purchasing this CLARKE product.

Before attempting to use this product, please read this manual thoroughly and

follow the instructions carefully. You will find your new log splitter easy and safe

to operate and with proper care, it will give you many years of dependable

service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission.

This guarantee does not effect your statutory rights.

CAUTION: CAREFULLY READ THROUGH THIS ENTIRE OPERATOR'S

MANUAL BEFORE USING YOUR NEW LOG SPLITTER. TAKE SPECIAL CARE

TO HEED THE CAUTIONS AND WARNINGS.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

SAFETY SYMBOLS

The following symbols represent important information about the product or

instructions on its use.

Read these

instructions in full

before using the

machine.

Dispose of any used oil

in an environment-

friendly way.

Wear safety footwear! Do not use in the rain.

Wear protective

gloves!

Danger! Keep clear of

moving parts!

Wear eye protection!

Do not remove

jammed logs with your

hands.

Wear hearing

protection!

Before starting any

repair maintenance or

cleaning, always

disconnect the power.

Keep your work space

tidy! Untidiness may

result in accidents.

Avoid injury from the

movement of the

splitting blade

Do not remove or

tamper with any

protection or safety

device.

Keep bystanders

away from the

working area.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

GENERAL SAFETY RULES

WORK AREA

1. Keep the work area clean and well lit. Cluttered and dark areas invite

accidents.

2. Do not operate log splitters in explosive atmospheres, such as in the

presence of flammable liquids, gases or dust. Log splitters create sparks

which may ignite the dust or fumes.

3. Keep children and bystanders away while operating the log splitter.

Distractions can cause you to lose control.

4. The surface must be perfectly level to prevent the machine from moving

during operation.

ELECTRICAL SAFETY

1. The log splitters plug must match the outlet. Never modify the plug in any

way. Unmodified plugs and matching outlets will reduce risk of electric

shock.

2. Avoid body contact with earthed or grounded surfaces such as pipes,

radiators, ranges and refrigerators. There is an increased risk of electric

shock if your body is earthed or grounded.

3. Do not expose log splitters to rain or wet conditions. Water entering a log

splitter will increase the risk of electric shock.

4. Do not abuse the cord. Never use the cord for carrying, pulling or

unplugging the log splitter. Keep cord away from heat, oil, sharp edges or

moving parts. Damaged or entangled cords increase the risk of electric

shock.

5. When operating the log splitter outdoors, use an extension cord suitable for

outdoor use. Use of a cord suitable for outdoor use reduces the risk of

electric shock.

6. Do not leave the log splitter unattended when plugged in to the mains

supply.

PERSONAL SAFETY

1. Stay alert, watch what you are doing and use common sense when

operating a log splitter. Do not use the log splitter while you are tired or

WARNING: READ ALL OF THESE INSTRUCTIONS. FAILURE TO FOLLOW ALL

INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/

OR SERIOUS INJURY. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

under the influence of drugs, alcohol or medication. A moment of

inattention while operating log splitters may result in serious personal injury.

2. Use safety equipment. Always wear eye protection. Safety equipment such

as non-skid safety shoes, close fitting clothing and suitable work gloves

should always be used.

3. Avoid accidental starting. Ensure the switch is in the off position before

plugging in.

4. Do not overreach. Keep proper footing and balance at all times. This

enables better control of the log splitter in unexpected situations.

5. Dress properly. Do not wear loose clothing or jewellery. Keep your hair,

clothing and gloves away from moving parts. Loose clothes, jewellery or

long hair can be caught in moving parts.

USAGE AND CARE

1. Do not force the log splitter. It will do the job better and safer at the rate for

which it was designed.

2. Disconnect the plug from the power source before making any

adjustments, changing accessories, or storing the log splitter. Such

preventive safety measures reduce the risk of starting the log splitter

accidentally.

3. Store the log splitter out of the reach of children and do not allow persons

unfamiliar with log splitters or these instructions to operate the log splitter.

Log splitters are dangerous in the hands of untrained users.

4. Maintain the log splitter. Check for misalignment or binding of moving

parts, breakage of parts and any other condition that may affect the log

splitters operation. If damaged, have the log splitter repaired before use.

Many accidents are caused by poorly maintained power tools.

5. Keep cutting tools sharp and clean. Properly maintained cutting tools with

sharp cutting edges are less likely to bind and are easier to control.

SERVICE

1. Have your log splitter serviced by a qualified repair person using only

identical replacement parts. This will ensure that the safety of the log splitter

is maintained.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

LOG SPLITTERS SPECIFIC WARNINGS

UNDERSTAND YOUR LOG SPLITTER

• Read and understand the owner's manual and labels affixed to the log

splitter. Learn its limitations as well as the specific potential hazards.

DRUGS, ALCOHOL AND MEDICATION

• Do not operate the log splitter while under the influence of drugs,

alcohol, or any medication that could affect your ability to use it

properly.

AVOID DANGEROUS WORKING CONDITIONS

• Always operate your log splitter on dry, solid, level ground. Never

operate your log splitter on slippery, wet, muddy, or icy surfaces. The

location you choose should be free from any tall grass, brush, or other

interferences.

• There should be plenty of room for handling.

• Keep your work area clean and well lit. Cluttered areas invite injuries. To

avoid tripping, do not leave tools, logs, or other components laying

around the work area.

• Do not use the log splitter in wet or damp areas or expose it to rain.

• Do not use it in areas where fumes from paint, solvents or flammable

liquids pose a potential hazard.

INSPECT YOUR LOG SPLITTER

• Check your log splitter before turning it on. Keep guards in place and in

working order.

• Replace damaged, missing or failed parts before using it.

• Make sure all nuts, bolts, screws, hydraulic fittings etc. are securely

tightened.

• Always check the oil level in the hydraulic oil tank.

• Never operate your log splitter when it is in need of repair or is in poor

mechanical condition.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

DRESS PROPERLY

• Do not wear loose clothing, gloves, neckties or jewelry (rings, wrist

watches). They can be caught in moving parts. Protective electrically

non-conductive gloves and non-skid footwear are recommended when

working. Wear protective hair covering to contain long hair, preventing it

from get caught in machinery.

PROTECT YOUR EYES AND FACE

• Any log splitter may throw foreign objects into the eyes. This can cause

permanent eye damage. Always wear safety goggles. Everyday

eyeglasses have only impact resistant lenses. They are not safety glasses.

EXTENSION CABLES

• Improper use of extension cables may cause inefficient operation of the

log splitter which can result in overheating.

• Be sure the extension cable is no longer than 10m and its section is no

less than 2.5mm2to allow sufficient current flow to the motor.

AVOID ELECTRIC SHOCK

• Check that the electric circuit is adequately protected and that it

corresponds with the power, voltage and frequency of the motor.

• Never open the switch / plug box. Should this be necessary, contact a

qualified electrician.

• Make sure your fingers do not touch the plug’s metal prongs when

plugging or unplugging the log splitter.

• Avoid excessive bending and twisting of the connection between the

power cord of the British plug and the junction box.

PREVENT FIRES

• Do not smoke or have open flames when operating or refilling the log

splitter with oil.

• Never operate the log splitter near a flame or spark. Oil is flammable.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

KEEP BYSTANDERS AWAY

• Allow only one person to load and operate the log splitter.

• Always keep bystanders, including visitors, children and pets away from

the work area, especially when the log splitter is in use.

• Only the operator should stand near the machine during use.

• Children should not be allowed to operate the machine.

• All operators should has the necessary training and skills to perform the

functions properly and safely.

INSPECT YOUR LOG

• Never attempt to split logs containing nails, wire or debris.

• Always make sure that both ends of the log you are splitting are cut as

square as possible. This will prevent the log from sliding out of position

while under pressure. Branches must be cut off flush with the trunk.

DON'T OVERREACH

• Keep proper footing and balance at all times.

• Never stand on the log splitter.

• Serious injury could occur if the machine tips over.

• Do not store anything above or near the log splitter where a person

might stand on the log splitter to reach it.

AVOID INJURY FROM UNEXPECTED ACCIDENT

• Do not straddle or reach across the splitting area when operating the

log splitter.

• Never pile logs to be split in a manner that will cause you to reach across

the log splitter.

• Only use your hands to operate the control levers. Never use your foot,

knee, a rope, or any other extension device.

• Always pay full attention to the movement of the wedge ram.

• Never attempt to load your log splitter while the ram is in motion.

• Keep hands out of the way of all moving parts.

• Never try to split two logs on top of each other. One of them may fly up

and hit you.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

PROTECT YOUR HANDS

• When the ram of the log splitter is in the return mode, keep your hands

off the machine – the log splitter is designed to automatically stop when

the cylinder is fully retracted.

• Keep your hands away from splits and cracks which open in the log.

They may close suddenly and crush or amputate your hands.

• Do not remove jammed logs with you hands.

DON'T FORCE THE TOOL

• It will do a better and safer job at its design rate.

• Don’t use log splitter for a purpose for which it was not intended.

• Do not, under any circumstances, alter your log splitter. This equipment

was designed and engineered to be used in accordance with the

operating instructions. Altering the equipment, or using the equipment in

such a way as to circumvent its design capabilities and capacities,

could result in serious or fatal injury and will void the warranty.

• Never try to split logs larger than those indicated in the specifications

table on page 10. This is dangerous and may damage the machine.

NEVER LEAVE LOG SPLITTER RUNNING UNATTENDED

• Don't leave log splitter until it has come to a complete stop

DISCONNECT POWER

• Unplug when not in use, before making adjustments, cleaning, or

working on the log splitter.

MAINTAIN YOUR LOG SPLITTER WITH CARE

• Always clean the log splitter after each use.

• Keep the log splitter clean and free from debris for best and safest

performance.

• Control levers and the power switch must be kept clean, dry and free

from oil and grease at all times.

PROTECT THE ENVIRONMENT

• Take any used oil to an authorized collection point. Do not discharge

into drains, soil or water.

MAKE THE WORKSHOP CHILDPROOF

• Lock the workshop. Store the log splitter away from children and others

not qualified to use it.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

SPECIAL WARNINGS & INSTRUCTIONS

The splitting operation of the machine is designed to be activated by one

person. While there is the possibility that additional operators could be working

with the machine (e.g. for loading and unloading), only one operator should

perform splitting operations:

• Never attempt to remove a log which has got stuck on the wedge by

hand. Lower the wedge until the log is completely split.

• If a log becomes stuck on the wedge at the bottom position, press the

handle with one hand and turn off the machine with the other hand.

Slightly knock the log by hammer to free it.

SPECIFICATIONS

*This product is designed so that the motor may be run under load for an accumulated period of 4

minutes only and off load for an accumulated period of 6 minutes in any 10 minute period.

Motor 230V @ 50Hz / 1 Ph

Input Wattage 3000W

Duty Cycle S6 40%*

Log Size Capacity Diameter 8-30 cm

Length 10-55 cm

Maximum Force 6000 kg

Hydraulic Pressure 21.6 Mpa

Hydraulic Oil Capacity 3.5 L

Ram Travel 49.5 cm

Speed Forward 3.6 cm/sec

Retract 16.5 cm/sec

Noise Pressure Level (LpA) under no load; 78.8 dbA

under full load 89.8 dbA

Vibration <2.5 m/s²

Dimensions Length 84 cm

Width 91.5 cm

Height 149.5 cm

Weight 98.2 kg

Tabla de contenidos

Otros manuales de Partidor de troncos de Clarke

Clarke

Clarke LOGBUSTER 7 Manual de instrucciones

Clarke

Clarke LOGBUSTER 9 Manual de instrucciones

Clarke

Clarke LOGBUSTER P8 Manual de instrucciones

Clarke

Clarke LOGBUSTER 5 Manual de instrucciones

Clarke

Clarke Log Buster 4 Manual de instrucciones

Clarke

Clarke LOGBUSTER H4 Manual de instrucciones

Clarke

Clarke LOGBUSTER 10 Manual de instrucciones

Clarke

Clarke Log Buster 3 Manual de instrucciones

Clarke

Clarke LOGBUSTER II Manual de instalación y operación

Clarke

Clarke CCLH1 Manual del propietario

Clarke

Clarke LOGBUSTER M Manual de instrucciones

Clarke

Clarke LOGBUSTER 6 Manual de instrucciones

Clarke

Clarke LOGBUSTER 8 Manual de instrucciones

Manuales populares de Partidor de troncos de otras marcas

Bell

Bell Pickpine VS S9 Manual de instrucciones

ATIKA

ATIKA ASP 5 N-UG Instrucciones de operación

Posch

Posch Schälprofi 500 Manual de usuario

Champion

Champion 91520 Manual

Fieldmann

Fieldmann FZLS 1008V-E Manual de usuario

Craftsman

Craftsman 247.28775 Manual de usuario

Scheppach

Scheppach OX 3-1000 Instrucciones de montaje

Swisher

Swisher 21200 Manual de usuario

Elem Garden Technic

Elem Garden Technic FBHT65-22TCH Manual de usuario

Champion Power Equipment

Champion Power Equipment 90720 Manual

Boss Industrial

Boss Industrial ES5T20 Manual de usuario

Villager

Villager LSP 12 T Manual de usuario

MTD

MTD 242-642A Manual de usuario

Rok

Rok 150-51-50255 Manual de usuario

Hakki Pilke

Hakki Pilke Raven Manual de usuario

Swisher

Swisher LSRB11534 Manual de usuario

Hyundai

Hyundai HYLS7TE Manual de usuario

Scheppach

Scheppach HL1500M Guía del usuario
