CU-50

Item ref: 173.633UK

USB Recording Microphone & Stand

User Manual

Setting up

Mount the CU-50 to the supplied angle-adjustable holder by

rotating it onto the Mounting Thread at the base of the

microphone, surrounding the USB socket.

This holder can be screwed onto to the supplied mini tripod

stand for tabletop use or attached to a standard microphone

stand or boom arm

(remove the 3/8”thread adaptor for 5/8”threads)

Connect the supplied USB lead to the type B Socket at the

base of the microphone housing and the other end to an

available USB port on a PC or Mac computer.

The computer will recognise the CU-50 as a “USB Audio Device”in the sound or audio settings.

Operation

Selecting the CU-50 (“USB Audio Device”) as the input device within the recording or streaming software

will set the microphone as the input source.

Pressing the MUTE button will cause this button to illuminate and will mute the microphone.

Pressing MUTE again will un-mute the microphone.

If an echo effect is required, this can be introduced by pressing the ECHO button, which will be

illuminated when the echo effect is active. Pressing ECHO again will switch off the echo effect.

The CU-50 can be disconnected and re-connected to USB as a hot-swappable device.

Disconnect from USB after use to preserve the computer battery or power supply.

173.633UK User Manual

Specifications

Capsule

14mmØ back electret

Polar pattern

Cardioid

Connection

USB type B (power & digital audio)

Lead length

1.5m

Frequency response

20Hz - 20kHz

Sampling format

16-bit

Sample rate

44.1kHz or 48kHz

Controls

Echo on/off, Mute on/off

S/N ratio

78dB

Sensitivity

-40dB (±2dB)

Dimensions

147 x 50mmØ (microphone only)

Weight

272g (microphone only)

Disposal: The “Crossed Wheelie Bin” symbol on the product means that the product is classed as

Electrical or Electronic equipment and should not be disposed with other household or commercial waste

at the end of its useful life. The goods must be disposed of according to your local council guidelines.

Unit 2-4 Bridgewater Park, Taylor Rd. Manchester. M41 7JQ

AVSL (EUROPE) Ltd, Unit 3D North Point House, North Point Business Park, New Mallow Road, Cork, Ireland
