WPart NamesW

* The illustrations shown in this manual may differ from the actual watch you have purchased.

The description that follows will refer to the figure of the model with a second hand.

Hour hand

Second hand

Minute hand

Crown

Date

Hour hand

Minute hand

Crown

Date

Depending on the watch, some models have a second hand and some do not.

English

Table of Contents

Your Watch

1. Features ....................................................................................................... 6

2. Operating the Crown ................................................................................. 7

Time and Date Correction

3. Setting the Time and Date ......................................................................... 8

Solar Power

4. Solar Power Function ............................................................................... 10

5. Characteristics of the Solar Powered Watch .......................................... 12

A. Overcharging Prevention Function ........................................................ 13

B. Insufficient Charge Warning Function

(models with a second hand only)....

C. Quick Start (models with a second hand only) ...................................... 14

D. Guide to Charging Time......................................................................... 14

E. Handling Your Watch ............................................................................. 18

Precautions ......................................................................................................... 20

6. Specifications ............................................................................................ 26

iEco-Drive function

This solar powered Eco-Drive watch is powered by photo energy

converted into electrical energy.

Your Watch

1. Features

2. Operating the Crown

There are two models available for the crown: normal and screw lock.

In the case of normal crown watch, the crown has simply to be pulled out.

Turn to the left

1. Turn the crown to the left.

2. When the screw lock is released, the

crown pops out a little and stops in the

normal position.

3. After using the crown, push it in gently

while turning it to the right to lock it.

The date and time can be corrected by changing the position of the crown. Correct

by turning the crown while in the given mode.

* Nothing happens if you turn the crown when it is in the normal position.

Time and Date Correction

3. Setting the Time and Date

1. Pull out the crown to position 2.

(The second hand stops at this time for models with a second hand.)

2. Turn the crown to set the time.

* When the date changes, it is 0:00 a.m. (midnight). Take care to observe

whether it is a.m. or p.m.

3. Return the crown to the normal position to complete the correction.

(The second hand starts moving at this time for models with a second hand.)

* For models with a second hand, refer to a time report to adjust the seconds.

1. Pull out the crown to position 1.

(The second hand continues moving at this time for models with a second hand.)

2. Turn the crown to the left to change the date.

* Nothing happens if the crown is turned to the right.

3. Return the crown to the normal position to complete the correction.

Date correction position

(Crown in position 1)

Time correction position

(Crown in position 2)

This watch uses a secondary battery to store electrical energy. When the watch is

fully charged, it will maintain its accuracy for about 9 months.

To receive the greatest pleasure from your watch, always store it in a

sunlit location.

jPlacing the watch near a window where its face can

receive sunlight or near another source of light when

you are not wearing it will ensure that the watch is

regularly charged, allowing it to maintain its accuracy.

Solar Power

4. Solar Power Function

jWearing clothes with long sleeves makes it difficult

for the watch to get the necessary light, resulting in

insufficient charging.

It is recommended to charge your watch by

exposing to direct sunlight for a long time once a

month.

[NOTE]

Do not charge on surfaces that can easily

become hot, such as a car dashboard.

1312

5. Characteristics of the Solar Powered Watch

When the watch is insufficiently charged, the indication will be changed as follows:

Charge the watch sufficiently, as indicated in “Guide to Charging Time”.

At this time, be sure to charge the watch with sunlight rather than under fluorescent

light.

[Normal indication]

The watch will stop

due to an insufficient

charging.

[Operation stops]

The second hand

starts moving at 2-

second intervals.

[Insufficient charge warning]

(Models with a second hand only)

The watch has been insufficiently

charged because the watch face

has not received sufficient light.

The insufficient charge

warning (a 2-second interval

movement) continues for

more than 7 days.

The watch has been insufficiently

charged because the watch face

has not received sufficient light.

A. Overcharging Prevention Function

No matter how much the watch is charged, it will not affect the secondary battery,

timekeeping, functions or performance of the watch. When the secondary battery

becomes fully charged by exposing the watch face to light, the overcharging

prevention function is automatically activated to prevent the battery from being

charged further.

B. Insufficient Charge Warning Function

(models with a second hand only)

The second hand’s movement changes from 1-second

intervals to 2-second intervals to show that the watch

is insufficiently charged.

The watch will stop due to insufficient charging

about 7 days after starting the 2-second interval

movement if kept in a place with no light.

2-second

interval

movement

1514

C. Quick Start (models with a second hand only)

If the watch stops due to insufficient charge, the second hand will start moving at

2-second intervals if the watch face is exposed to light (approx. 500 lx) for approx.

10 seconds. (The time required for the hand to begin moving varies depending on

the model.) Note, however, that the battery is not yet fully charged.

D. Guide to Charging Time

The charging time varies according to the model (including the color of the watch

face). The following data should only be used as a guideline.

* The charging time is based on continuous exposure.

For a 1-day movement charging time......

The charging time to run the watch for one day with normal movement.

Time for full charging......

The time for full charging after the watch has stopped due to an insufficient

charging.

Illuminance

(lx) Environment

Charging time (approximate)

Time from

stopping to

resuming the

1-second

interval

movement

Time for full

charging

3,000 20 cm (8 in.) beneath a 30 W

florescent light 40 minutes 35 hours --------

10,000 Cloudy sky 12 minutes 9.5 hours 70 hours

100,000 Under direct midsummer

sunlight 2 minutes 1 hour 10 hours

For a 1-day

movement

charging time

1716

Illuminance

(lx) Environment

Charging time (approximate)

Time from

stopping to

resuming the

1-second

interval

movement

Time for full

charging

3,000 20 cm (8 in.) beneath a 30 W

florescent light 40 minutes 14 hours --------

10,000 Cloudy sky 12 minutes 4.5 hours 60 hours

100,000 Under direct midsummer

sunlight 2 minutes 25 minutes 11 hours

For a 1-day

movement

charging time

[NOTE]

A fully charged battery will run the watch for about 9 months without further

charging.

If the watch stops due to insufficient charge, take care to charge it daily.

Furthermore, it is recommended to charge your watch by exposing to direct sunlight

for a long time once a month.

1918

E. Handling Your Watch

WARNING Handling the secondary battery

jDo not remove the secondary battery from the watch yourself, unless

unavoidable.

If you must remove the battery, store it out of reach of children to avoid

accidental ingestion. If the secondary battery is ingested, consult a doctor

immediately.

jDo not throw away with regular trash.

Doing so could cause a fire or environmental damage. Follow the collection

procedures as specified by your local authority.

WARNING

Do not use anything other than the specified secondary battery

jThe watch will not operate if incorrect battery types are inserted.

Never use a regular silver battery. The battery could overcharge during the

charging process and burst, causing damage to the watch or injuries to the

wearer.

CAUTION Charging precautions

jDo not charge the watch in a high-temperature environment (about 60°C/140°F

or more).

Overheating while charging can cause the watch exterior to become discolored,

the watch to deform or the movement to be damaged.

Example:

• Charging close to incandescent lighting, halogen lamps, or other lighting

sources that easily become hot.

• Charging on surfaces that can easily become hot, such as a car dashboard.

jWhen charging with incandescent lighting, halogen lamps, or other lighting

sources that easily become hot, place the watch at least 50 cm (20 in.) away

from the source to avoid overheating.
