Citizen CT-S300 Manual de usuario

LINE THERMAL PRINTER

MODEL CT-S300

User’s Manual

Mode d’emploi

Benutzerhandbuch

Manuale dell’utente

Manual de Usuario

Manufacturer’s Name : Japan CBM Corporation

Manufacturer’s Address : CBM Bldg., 5-68-10, Nakano, Nakano-ku

Tokyo, 164-0001, Japan

Declare the Product

Product Name Line Thermal Printer

Model Number(s) CT-S300 Series

(S/No.0370001)

Conform to the following Standards

LVD : EN60950-1 : 2001

EMC : EN55022 : 1998 Class A

: EN61000-3-2 : 2000

: EN61000-3-3 : 1995/A1: 2001

: EN55024 : 1998/A1: 2001

: EN61000-4-2 : 1995 ±4KV CD, ±8 KV AD

: EN61000-4-3 :

1995 3 V/m, 80 MHz-1000 MHz AM 1 KHz 80 %

: EN61000-4-4 :

1995 ±1.0 KV (AC Mains), ±0.5 KV (Signal Lines)

: EN61000-4-5 :

1995 1 KV Normal mode, 2 KV Common mode

: EN61000-4-6 :

1996 3 V, 0.15 MHz-80 MHz AM 1 KHz 80 %

: EN61000-4-8 : 1993 50 Hz, 3 A/m (Out of scope)

: EN61000-4-11 :

1994 10ms/95%, 500ms/30%, 5000ms/100%

Supplementary Information

“The product complies with the requirements of the Low Voltage Directive 73/

23/EEC, 93/68/EEC and the EMC Directive 89/336/EEC, 92/31/EEC, 93/68/EEC”

Place Tokyo, Japan Signature

Date July 2003

Full Name : Mikio Moriya

Position : General Manager

R & D Department

European Contact :

CBM Europe GMBH

Narzissenweg 2 a, D-21502 Geesthacht, Germany

Declaration of Conformity

Warning : This is a Class A product. In a domestic environment this product may cause

radio interference in which case the user may be required to take adequate

measures.

This declaration is applied only for 230 V model.

IMPORTANT: This equipment generates, uses, and can radiate radio frequency energy

and if not installed and used in accordance with the instruction manual, may cause

interference to radio communications. It has been tested and found to comply with

the limits for a Class A computing device pursuant to Subpart J of Part 15 of FCC

Rules, which are designed to provide reasonable protection against such interference

when operated in a commercial environment. Operation of this equipment in a

residential area is likely to cause interference, in which case the user at his own

expense will be required to take whatever measures may be necessary to correct

the interference.

CAUTION: Use shielded cable for this equipment.

Sicherheitshinweis

Die Steckdose zum Anschluß dieses Druckers muß nahe dem Grät angebracht und

leicht zugänglich sein.

For Uses in Canada

This digital apparatus does not exceed the class A limits for radio noise emissions

from digital apparatus, as set out in the radio interference regulations of the Canadian

department of communications.

Pour L’utilisateurs Canadiens

Cet appareil numérique ne dépasse pas les limites de carégorie a pour les émissions

de bruit radio émanant d’appareils numériques, tel que prévu dans les réglements

sur l’interférence radio du départment Canadien des communications.

ENGLISH

— 1 —

THE TABLE OF CONTENTS

1. GENERAL OUTLINE ...................................................................8

1.1 Unpacking .......................................................................................8

1.2 Model Classification .......................................................................8

1.3 Basic Specifications .......................................................................9

2. EXPLANATION OF PRINTER PARTS .......................................10

2.1 Printer Appearance ......................................................................10

3. PREPARATION ..........................................................................11

3.1 Connecting the AC Adapter and AC Power Cord ......................11

3.2 Connecting Interface Cables .......................................................12

3.3 Connecting the Cash Drawer ......................................................13

3.4 Installing the Printer .....................................................................14

3.5 Partition for 58-mm Wide Paper Roll ..........................................14

3.6 Setting DIP Switch .......................................................................15

3.7 Adjusting the Paper Near-end Sensor ........................................16

4. MAINTENANCE AND TROUBLESHOOTING ..........................17

4.1 Setting/Replacing Paper Rolls .....................................................17

4.2 Removing Jammed Paper ...........................................................17

4.3 Cleaning the Print Head ...............................................................18

4.4 When the Paper Cover Cannot Be Opened ................................18

4.5 Self-printing ..................................................................................19

4.6 Hexadecimal Dump Printing .......................................................19

4.7 Error Indication .............................................................................20

5. OTHER .......................................................................................21

5.1 External Views and Dimensions .................................................21

5.2 Manual Setting of Memory Switch .............................................22

5.3 Printing Paper ...............................................................................24

— 2 —

GENERAL PRECAUTIONS

●Before using this product, be sure to read through this manual. After having read

this manual, keep it in a safe, readily accessible place for future reference.

●The information contained herein is subject to change without prior notice.

●Reproduction or transfer of part or all of this document in any means is prohibited

without permission from CBM.

●Note that CBM is not responsible for any operation results regardless of missing,

error, or misprinting in this manual.

●Note that CBM is not responsible for any trouble caused as a result of using options

or consumables that are not specified in this manual.

●Except explained elsewhere in this manual, do not attempt to service, disassemble,

or repair this product.

●Note that CBM is not responsible for any damage attributable to incorrect

operation/handling or improper operating environments that are not specified in

this manual.

●Data are basically for temporary use, not stored for a long period or permanently.

Please note that CBM is not responsible for damage or lost profit resulting from

the loss of data caused by accidents, repairs, tests or other occurrence.

●If you find loss of information, error, or uncertain matter, please contact your

CBM dealer.

●If you find any disordered or missing page(s), contact your CBM dealer for

replacement.

Company names and product names in this manual are

trademarks or registered trademarks of relevant companies.

— 3 —

SAFETY PRECAUTIONS ... WHICH SHOULD BE STRICTLY OBSERVED

Before using this product for the first time, carefully read these SAFETY PRECAUTIONS.

Incorrect operation may result in unexpected accidents (fire, shock, or injury).

●After having read this Manual, keep it in a safe, readily accessible place for future

reference.

●Some of the descriptions contained in this manual may not be relevant to some printer

models.

In order to prevent injury hazard to operators, third parties or damage to property, special

warning symbols are used in this user’s manual to indicate important items to be strictly

observed.

The following describes the degree of hazard and damage that could occur if the printer

is improperly operated by ignoring the instructions indicated by the warning symbols.

This symbol is used to alert your attention to important items.

Neglecting precautions indicated by this symbol may result in fatal or serious injury.

WARNING

Neglecting precautions indicated by this symbol may result in injury or damage to

properties.

CAUTION

This symbol is used to alert you to the danger of electric shock or electrostatic

damage.

This symbol denotes a request to unplug the printer from the wall outlet.

This symbol is used to indicate the “information” on the use, or the like.

This symbol is used to indicate prohibited actions.

— 4 —

Do not use or store this product in a place where it will be exposed to:

●Flames or moist air

●Direct sunlight

●Hot airflow or radiation from a heating device

●Salty air or corrosive gases

●Ill-ventilated atmosphere

●Chemical reactions in a laboratory

●Airborne oil, steel particles, or dust

●Static electricity or strong magnetic field

• Neglecting these warnings may result in printer failure, overheating, emission of

smoke, fire, or electric shock.

Do not drop any foreign object nor spill liquid into the printer. Do not place any

object on the printer either.

●Do not drop any metallic object such as paper clip, pin or screw into the printer.

●Do not place a flower vase, pot or cup containing water on the printer.

●Do not spill coffee, soft drinks or any other liquid into the printer.

●Do not spray insecticide or any other chemical liquid over the printer.

• A metallic foreign object, if accidentally dropped into the printer, may cause printer

failure, fire, or electric shock. Should it occur, immediately turn the printer off,

unplug it from the supply outlet, and call your local CBM dealer.

Do not handle the printer in the following ways:

●Do not allow the printer to sustain strong impacts or hard jolts (e.g., trampling,

dropping, striking with a hard edge).

●Never attempt to disassemble or modify the printer.

• Neglecting to handle properly may result in printer failure, overheating,

emission of smoke, fire, or electric shock.

WARNING

Install, use, or store the printer out of the reach of children.

• Electric appliances could cause an unexpected injury or accident if they are

handled or used improperly.

• Keep the power cord and signal cables out of the reach of children. Also

children should not be allowed to gain access to any internal part of the printer.

• The plastic bag the printer came in must be disposed of properly or kept away

from children. Wearing it over the head may lead to suffocation.

— 5 —

Please observe the following precautions for power source and power cord:

●Do not plug or unplug the power cord with a wet hand.

●Use the printer only at the specified supply voltage and frequency.

●Use only the specified AC adapter with the printer.

●Check to make sure that the supply outlet from which the printer is powered has

a sufficient capacity.

●Do not supply the printer from a power strip or current tap shared with other

appliances.

●Do not plug the power cord into a supply outlet with dust or debris left on its

plug.

●Do not use a deformed or damaged power cord.

●Do not move the printer while the printer power is on.

• Neglecting to handle properly may result in printer failure, emission of smoke,

fire, or electric shock.

• An overload may cause the power cord to overheat or fire or the circuit breaker

to trip.

●Do not allow anything to rest on the power cord. Do not place the printer where

the power cord will be trampled on.

●Do not use or carry the printer with its power cord bent, twisted, or pulled.

●Do not attempt to modify the power cord unnecessarily.

●Do not lay the power cord in the neighbor of a heating device.

• Neglecting these cautions may cause wires or insulation to break, which could

result in leakage, electric shock, or printer failure. If a power cord sustains damage

contact your CBM dealer.

●Do not leave things around the supply outlet.

●Supply power to the printer form a convenient wall outlet, readily accessible in

an emergency.

• The printer may not be immediately shut down in an emergency.

●Insert the power plug fully into the outlet.

●If the printer is not to be used for a long time, leave it disconnected from its

supply outlet.

●Hold the plug and connector when plugging or unplugging the power cord or

signal cable after turning off the printer and the appliance connected to it.

WARNING

— 6 —

Place the printer on a flat, stable surface without vibration.

• Otherwise dropping may cause injury.

Do not use the printer under the following conditions.

●A state where the printer ventilation holes are blocked by a nearby wall or

something

●A state where any object is placed on the printer

●A state where the printer is covered or wrapped by a cloth or bed clothing

• Be careful about internal heat buildup, which could cause fire and deform the

case.

●Avoid using the printer near a radio or TV set or from supplying it from the same

outlet as these appliances.

●Avoid using the printer interconnected with a cable or cord that has no protection

against noise. (For interconnections, use shielded or a twisted pair of cables and

ferrite cores, or other anti-noise devices.)

●Avoid using the printer with a device that is a strong source of noise.

• The printer may have an adverse effect on nearby radio or TV transmissions.

There may also be cases when nearby electrical appliances adversely influence

the printer, causing data errors or malfunction.

CAUTION

Use the printer with its grounding post connected to a convenient grounding facility.

• If leakage occurs electric shock may result.

Do not connect the printer’s grounding post onto any of the following facilities.

●Utility gas piping

A gas explosion could result

●Telephone line ground

●Lightning rod

If lightning strikes a large surge of current may cause fire or shock.

●Utility water pipes

Plastic water pipes should not be used for grounding. (Those approved by a

Waterworks Department may be used.)

Before connecting or disconnecting the grounding lead to or from the printer, always

unplug it from supply outlet.

Caution label is attached on the position shown in the following figure.

Carefully read the precautions in handling before using the printer.

THIS LABEL INDICATES THE RISK OF

ANY INJURY DUE TO “HIGH

TEMPERATURE” OF THE PRINT HEAD.

Otros manuales para CT-S300

Tabla de contenidos

Idiomas:

Otros manuales de Impresora de Citizen

Citizen

Citizen CT-S281 Series Manual de usuario

Citizen

Citizen PMU2300III Manual de usuario

Citizen

Citizen MLT-288 Manual de usuario

Citizen

Citizen CT-S601 II Manual de usuario

Citizen

Citizen PD-22 Manual de usuario

Citizen

Citizen CMP-20II series Manual de usuario

Citizen

Citizen CBM-270 Manual de usuario

Citizen

Citizen CD-S500 series Manual de usuario

Citizen

Citizen CT-S4000DC Manual de usuario

Citizen

Citizen CT-P292 Manual de usuario

Citizen

Citizen CBM-820 Manual de usuario

Citizen

Citizen PD-04 Manual de usuario

Citizen

Citizen iDP-3210 Manual de usuario

Citizen

Citizen CLP 6001 CLP-6001 CLP-6001 Manual de usuario

Citizen

Citizen PPU-231 Manual de usuario

Citizen

Citizen iDP-3110 Manual de usuario

Citizen

Citizen PPU-231II Manual de instalación

Citizen

Citizen CT-S851 II Manual de usuario

Citizen

Citizen LINE THERMAL PRINTER CT-S280 Manual de instalación

Citizen

Citizen GSX-190 Manual de usuario

Citizen

Citizen iDP-460 Manual de usuario

Citizen

Citizen CT-S4500 Manual de usuario

Citizen

Citizen CLP-512 Manual de usuario

Citizen

Citizen CT-S2000 Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario
