QUICK START GUIDE

Cisco 526 Wireless Express Mobility Controller

INCLUDING LICENSE AND WARRANTY

1About this Guide

2Overview

3Unpacking and Preparing the Controller for Operation

4Connecting to an SBCS Compatible Switch

5Connecting Access Points

6Mounting the WLC526 Controller

7In Case of Difficulty

8Cisco One Year Limited Hardware Warranty Terms

9Translated Warnings

1 About this Guide

This guide will help you install the Cisco 526 Series Wireless Express Mobility Controller (hereafter

referred to as the WLC526 or the controller) in your Smart Business Communication System network.

FCC Safety Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment off and on.

Try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment to an outlet on a circuit different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio/TV technician for help. (cfr reference 15.105)

Safety Information

Safety warnings appear throughout this guide in procedures that may harm you if performed

incorrectly. A warning symbol precedes each warning statement. The warnings below are general

warnings that are applicable to the entire guide. Translated versions of the safety warnings in this guide

are provided in the “Translated Warnings” section on page 25.

Warning

This warning symbol means danger. You are in a situation that could cause bodily injury.

Before you work on any equipment, be aware of the hazards involved with electrical

circuitry and be familiar with standard practices for preventing accidents. Use the

statement number provided at the end of each warning to locate its translation in the

translated safety warnings that accompanied this device.

Statement 1071

SAVE THESE INSTRUCTIONS

Warning

There is the danger of explosion if the battery is replaced incorrectly. Replace the battery

only with the same or equivalent type recommended by the manufacturer. Dispose of

used batteries according to the manufacturer’s instructions.

Statement 1015

Warning

This equipment must be grounded. Never defeat the ground conductor or operate the

equipment in the absence of a suitably installed ground conductor. Contact the

appropriate electrical inspection authority or an electrician if you are uncertain that

suitable grounding is available.

Statement 1024

Warning

Ultimate disposal of this product should be handled according to all national laws and

regulations.

Statement 1040

Safety Considerations

•Verify that the ambient temperature remains between 32 to 104° F (0 to 40° C), taking into

account the elevated temperatures when installed in a rack or enclosed space.

•When multiple WLC526 controllers are mounted in an equipment rack, be sure that the power

source is sufficiently rated to safely run all the equipment in the rack (input: 100–240VAC, 50/60

Hz, output: 48VDC, 2.08A per controller).

•Verify the integrity of the electrical ground before installing the controller.

2 Overview

The Cisco 526 Wireless Express Mobility Controller is a network appliance designed to optimize the

wireless network of small and medium-sized businesses. The mobility controller can be used with up

to six controller-based access points per controller and up to two controllers per network. The

WLC526 is a component of the Cisco Smart Business Communications System.

A core element of the Cisco Mobility Express Solution, the WLC526 works in concert with Cisco 521

Wireless Express Access Points (hereafter referred to as the AP521) and the Cisco Configuration

Assistant (CCA) to provide you with the visibility and centralized control you need to optimize

network performance. The CCA is GUI-based software that allows you to configure and manage all

the components of the Cisco Smart Business Communications System.

The WLC526 provides:

•A cost-effective solution for small and medium-sized business environments

•Standards-based enterprise-class security

•Simplified network deployment and management with automated radio resource features

•Centralized management with the CCA

•Advanced mobility services readiness to support secure Internet guest access and optimized voice

over Wi-Fi

The Cisco Smart Business Communications System is shown in Figure 1.

Figure 1 Cisco Smart Business Communications System

After performing an initial setup, you configure the WLC526 and its controller-based AP521s using

the CCA.

Related Documentation

This guide assumes that you are installing your WLC526 in the Cisco Smart Business Communications

System. The following documents provide information about system components and include

configuration procedures:

•Cisco Smart Business Communications System Setup—This document, referred to as the “Smart Doc” in some

documents, contains instructions for installing, configuring, and monitoring the Cisco Smart Business

Communications System. You should use this document to configure all the components of the smart business

system.

201608

Cisco 521

Wireless Express

Access Points

Catalyst Express 520 Switch

Cisco 526 Wireless Express

Mobility Contoller

Fax

Cisco

Monitor

Director

Partner

Site

Teleworker

Site

Cisco 870 Series

Router

DSL/Cable

Modem

Internet

Cisco Unified

Communications 500 Series

Cisco

Configuration

Assistant/

Cisco Monitor

Manager

PSTN

•Cisco Unified Communications 500 Series for Small Business Getting Started Guide—Provides basic

installation and setup instructions for the Cisco Unified 500 Series Platform (hereafter referred to as the

UC500).

•Getting Started Guide for the Catalyst Express 520 Switches—Provides basic installation and setup instructions

for the Cisco Catalyst Express 520 switch (hereafter referred to as the CE520).

•User Guide for the Catalyst Express 520 Switches—Provides advanced configuration information for the

CE520 switch.

•Cisco Configuration Assistant Quick Start Guide—Contains basic installation and configuration instructions

for the Cisco Configuration Assistant (CCA).

•Quick Start Guide: Cisco 521 Wireless Express Access Point—Contains mounting instructions for the AP521.

These documents are available on cisco.com. Follow these steps to obtain these documents on cisco.com:

Step 1 Browse to http://www.cisco.com

Step 2 Click Support. A drop-down window appears.

Step 3 In the drop-down window, Click Documentation. The Support Documentation page appears.

Step 4 In the Product and Support section, click Wireless. The Support Wireless page appears.

Step 5 Scroll down to the Cisco Mobility Express section.

Step 6 Select the link for the wireless express component you need. The Introduction page for that

component appears.

Step 7 Download the appropriate document.

3 Unpacking and Preparing the Controller for Operation

Follow these steps to unpack the controller and prepare it for operation:

Step 1 Open the shipping container and carefully remove the contents.

Step 2 Return all packing materials to the shipping container and save it.

Step 3 Ensure that all items listed in the “Package Contents” section are included in the shipment. If

any item is damaged or missing, notify your authorized Cisco sales representative.

Package Contents

Each WLC526 controller package contains the following items:

•One Cisco 526 wireless LAN controller

•One power cord

•One Ethernet cable (RJ45 to RJ45)

•One Console cable (RJ45 to DB9)

•This guide

•Cisco product registration card

Figure 2 shows the front panel of the WLC526 and identifies its components.

Figure 2 WLC526 Front Panel

1AP LED 6Distribution port 1

2Alarm LED 7USB ports (not used)

3Status LED 8Reset button

4Power LED 9Console port

5Distribution port 2

230871

CONSOLE

AP ALARM STATUS POWER

Cisco 520

Series Wireless LAN Controller

91 2 3 4

5 6 7 8

Choosing a Physical Location

You can install the controller on a horizontal or vertical surface. The controller’s bottom plate has two

keyhole slots that permit you to mount it on a vertical surface, such as a wall. For maximum reliability,

mount the controller while following these guidelines:

•Make sure you can reach the controller and all cables attached to it.

•Make sure that water or excessive moisture cannot get into the controller.

•Make sure that airflow through the controller is not obstructed. Leave at least 4 in. (10 cm) clear

on both sides of the controller.

•Verify that the ambient temperature remains between 32 to 104° F (0 to 40° C).

•Make sure that the controller is installed in the same building and is within 328 ft. (100 m) of

equipment connected to the 10/100BASE-T ports.

•Make sure that the power cord can reach a 100 to 240 VAC grounded electrical outlet.

Moving a Controller

If you are staging your system in a lab environment or moving a controller to new location with a

different network domain, you must remember to change the IP addresses for the AP Management,

Management, and all Dynamic interfaces to the customer’s final IP addresses before moving the

controller to the customer site or to a new location. The IP addresses can only be changed using the

controller GUI interface. The console port interface can not be used to change IP addresses.

Using the Startup Wizard

When you power up the WLC526 you must prepare it for operation on your network by using the

controller’s GUI-based startup wizard. You will need to gather some information about your network

before you start the wizard. Table 1 lists the information you need to enter into the startup wizard.

Table 1 Startup Wizard Information

Wizard Setting Action

System Name The name you want to assign to the controller.

You can enter up to 32 ASCII characters.

Administrative user name and password The administrative username and password to be

assigned to this controller. You can enter up to 24

ASCII characters for each.

The default administrative username and

password are both admin and admin.

Management Interface VLAN Identifier The VLAN identifier of the management

interface (a valid VLAN identifier or 0 for an

untagged VLAN).

The VLAN identifier should be set to match the

switch interface configuration.

Management Interface IP Address The management interface is the default interface

for in-band management of the controller and

connectivity to services such as AAA servers.

You can access the controller’s GUI interface

using this address.

Management Interface Netmask Enter the IP address of the management interface

netmask.

Management Interface Default Router Enter the IP address of the default router.

Management Interface Port Number Enter the port number of the access point

manager interface. The default is 1.

Primary DHCP Server IP Address The management interface DHCP server IP

address. The default is 192.168.1.1.

Secondary DHCP server IP Address The IP address of the a secondary DHCP server.

The default is 0.0.0.0.

LWAPP Transport Mode The default is Layer 3.

RF Mobility Domain Name The name of the mobility group/RF group to

which you want the controller to belong.

The default is default.

Configured Country Code The country for which the controller is

configured. This setting is not changeable in the

startup wizard.

Regulatory Domain The domain in which the controller is to be

operated. Selection is made using the appropriate

domain checkbox.

AP Manager Interface Name The name assigned to the access point manager

interface. This setting is not changeable in the

startup wizard.

AP Manager VLAN identifier The VLAN identifier of the access point

management interface (a valid VLAN identifier

or 0 for an untagged VLAN).

AP Manager IP address The IP address of the access point manager

Interface.

AP Manager netmask The Netmask of the access point manager

Interface.

AP Manager Gateway IP address The IP address of the access point manager

interface.

AP Manager port number The port number of the access point manager

interface. The default is 1.

AP Manager Primary DHCP Server IP address The IP address of the access point manager

primary DHCP server interface.

AP Manager Secondary DHCP Server The IP address of the access point manager

secondary DHCP server interface.

Virtual Interface Name The name of the controller’s virtual interface.

This setting is not changeable in the startup

wizard. The default is virtual.

Virtual Interface IP address The IP address for the virtual interface.

Virtual Interface DNS Host Name The name of the controller’s virtual interface

DNS host.

WLAN ID The identification number of the wireless LAN on

which this controller resides. This setting cannot

be changed in the startup wizard. The default is 1.

Profile Name The profile name of the wireless LAN.

Table 1 Startup Wizard Information (continued)

Wizard Setting Action

WLAN SSID The network name, or service set identifier

(SSID). This is the default SSID that the access

points use when they join a controller.

RADIUS Server IP Address The IP address of the RADIUS server if one is

available and you intend to use it. If you are using

a RADIUS server, the following fields must be

completed:

•Shared secret format (ASCII or HEX)

•Shared secret

•Confirm shared secret

•RADIUS server port (default port is 1812)

•Server status (enabled or disabled)

802.11b Network Status Check the checkbox to enable or disable the

802.11b radio network. The default is Enabled.

802.11g Network Status Check the checkbox to enable or disable the

802.11g radio network. The default is enabled.

Auto-RF Check the checkbox to enable or disable

automatic radio resource management. The

default is enabled.

Table 1 Startup Wizard Information (continued)

Wizard Setting Action

Tabla de contenidos

Otros manuales de Enrutador de red de Cisco

Cisco

Cisco CISCO7201 Manual del operador

Cisco

Cisco ASR 9000 Series Manual de usuario

Cisco

Cisco ASR 900 Series Manual de usuario

Cisco

Cisco ASR1006-10G-SEC/K9 - ASR 1006 VPN+FW Bundle... Manual de usuario

Cisco

Cisco ASR 9000 Series Manual de usuario

Cisco

Cisco CVR100W Manual de usuario

Cisco

Cisco 1811W - Integrated Services Router Wireless Manual de usuario

Cisco

Cisco Nexus 1000V Manual de usuario

Cisco

Cisco 2950 - Catalyst Switch Manual de usuario

Cisco

Cisco 2811 - Voice Security Bundle Router Manual de usuario

Cisco

Cisco Linksys WET11 Manual de usuario

Cisco

Cisco 10000 Series Manual de usuario

Cisco

Cisco RV345 Manual de instrucciones

Cisco

Cisco ASR-920-10SZ-PD Manual de instrucciones

Cisco

Cisco 220 Series Smart Plus Manual de instrucciones

Cisco

Cisco 4500-M Manual de instalación

Cisco

Cisco WS-C2960-24LC-S Manual de usuario

Cisco

Cisco RV042 - Small Business Dual WAN VPN Router Instrucciones de uso

Cisco

Cisco Network Registrar none Manual de usuario

Cisco

Cisco SOHO Series Instrucciones originales

Cisco

Cisco 10000-2P2-2DC Manual de usuario

Cisco

Cisco WGA54G Manual de usuario

Cisco

Cisco QuickVPN - PC Manual de instrucciones

Cisco

Cisco ASR1002 - ASR 1002 Router Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

EnGenius

EnGenius ESR-9710 Manual de usuario

LevelOne

LevelOne FBR-1416 Manual de usuario

Dynacord

Dynacord Promatrix 6000 Manual de usuario

Lorex

Lorex F5D8230-4 Manual de usuario
