Data Sheet

Cisco E1/T1 ISDN PRI Network Modules for Cisco 2610-51XM,

2800, 2691, 3660, 3700 and 3800 Series Routers

The versatility of Cisco®2610-51XM, 2800, 2691, 3660, 3700 and 3800 series routers is demonstrated by their broad support of

E1/T1 connectivity and Integrated Services Digital Network Primary Rate Interfaces (ISDN PRI). Customers continue to deploy

E1 and T1 circuits for Wide Area Network (WAN) connectivity, ISDN dial-backup, and digital modem termination in the Power

Branch Office Environment. Cisco now makes it possible to terminate T1 and E1 PRI connections in a single network module.

Available in single and dual port models, the NM-1CE1T1-PRI and NM-2CE1T1-PRI cards coupled with Cisco 2610-51XM, 2800,

2691, 3660, 3700 and 3800 Series routers, enhance and simplify customers’ WAN connectivity options (Figure 1).

Figure 1. Single-Port E1/T1 ISDN PRI Network Module (NM-1CE1T1-PRI)

The Cisco E1/T1 ISDN PRI Network Module’s integrated channel service unit (CSU) provides direct connection to the Telecommunications

network, thus allowing customers to consolidate customer premises equipment (CPE). This provides multifunction dial access aggregation,

routing functionality, VPN and firewall security, and other capabilities right inside the Cisco router in power branch office environments. Both

the 1-port and 2-port versions offer support for balanced and unbalanced E1 connectivity and conform easily to customers’ specific applications.

The Cisco E1/T1 ISDN PRI network modules also supply connectivity for internal digital modems in the Cisco 3660, 3700 and 3800 series routers,

with connectivity options for PRI, T1 channel associated signaling (T1-CAS), and E1-CAS R2 signaling. This provides for a high concentration of

V.92-compatible modems, while still allowing expandability for other critical services.

FEATURES AT-A-GLANCE

•Cisco IOS®Software configurable for T1 or E1 operation

•Balanced or unbalanced E1 termination in the same module

•Integrated CSU/DSU (channel service unit/data service unit) per port

•Full or fractional E1/T1—can be fully channelized

•Supports PRI for data, T1-CAS, and E1-CAS R2 signaling

•E1 unframed and framed modes (G.703/G.704) available

•Interoperates with NM-xDM digital modem network modules

•Bantam (tty) jacks for easy network monitoring

•V.54 loopback compatible

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com.

Page 2 of 8

•Supported on Cisco 2610-51XM, 2800, 2691, 3660, 3700 and 3800 Series routers

•Online insertion and removal (OIR) supported on Cisco 3660 3745 and 3845 routers

•On-board expansion slot for future technologies

KEY BENEFITS

Enhanced Flexibility

The Cisco E1/T1 ISDN PRI network modules (NM-xCE1T1-PRI) are software configurable between E1 or T1 operation, balanced or unbalanced

E1 termination, and CSU/DSU. Customers no longer need to buy a specific module for T1 support and then another card for E1 connectivity. In

addition, the same modules provide for balanced (120-ohm) and unbalanced (75-ohm) E1 termination. See table 5 for available cable adaptors.

Support for G.703 Unstructured E1 Signaling

International Telecommunications Union (ITU) signaling standard G.703 was previously available only on Cisco midrange routers through the

VWIC-xFT-G703 Voice/WAN interface card, which did not support data PRI. Framed E1 (G.704) is also supported for international customers

without G.703 service.

High-Density PRI Connectivity Options

For midrange, high-density ISDN PRI applications, the Cisco 2610-51XM, 2800, 2691, 3660, 3700 and 3800 Series provide superior performance

and port density. For example, a fully configured Cisco 3745 system can be configured for up to eight ISDN PRI connections in one chassis. These

ports can be fully channelized to provide up to 192 T1 channels at 56/64 Kbps each, or 240 E1 channels at 56/64 Kbps each.

Increased Manageability and Troubleshooting

Critical loopback support makes the 1-port and 2-port Cisco E1/T1 ISDN PRI network modules easy to manage. Both models have the capability to

internally loop back the on-board framer chip towards the interface, thus eliminating the need for an external loopback plug. Local, remote, line, and

payload loopbacks, along with support for V.54 inline loop commands complement the Cisco E1/T1 ISDN PRI Network Modules’ management

features.

Integrated bantam (tty) jacks allow line monitoring equipment to be inserted for circuit troubleshooting. The single set of jacks can be software

selected to monitor port-0 or port-1 without interrupting service.

Blue, yellow, and red alarm detection, as well as a new command to disable yellow alarm detection and generation, gives customers better control

over their WAN connections. This feature, combined with support for the Cisco WAN Access Performance Management System (WAPMS), Cisco

Intelligence Engine 2100, and CiscoWorks makes troubleshooting easy when necessary

Reliability

Integrating the external E1/T1 terminating device (CSU/DSU) increases the overall system reliability. Possible points of failure are reduced by

eliminating the second power supply, additional fans, extra cabling, and other equipment that accompany a “two-box” solution. This increase in

reliability allows Service Providers to more easily and cost effectively meet the requirements of their customers’ Service Level Agreements (SLAs)

and provides enterprises with maximum equipment uptime.

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com.

Page 3 of 8

PLATFORM SUPPORT

Supported Platforms and Minimum Software and Memory Requirements

Memory requirements depend on the selected platform, software feature set, and other installed modules and features. The Cisco E1/T1 ISDN PRI

network modules are supported in the Cisco 2610-51XM, 2800, 2691, 3660, 3700, and 3800 routers. For information about memory planning, refer

to the software release notes, the Cisco IOS Software Upgrade Planner, or ask your local Cisco representative. Table 1 below shows the minimum

Cisco IOS Software requirements for each platform.

Table 1. Supported Platforms and Minimum Software Requirements

Platform Minimum Cisco IOS Software Release

Cisco 2610-51 (Non-XM Models) Not supported

Cisco 2610-51XM Cisco IOS Software Release 12.3 and 12.3T

Cisco 2800 Series Cisco IOS Software Release 12.3(08)T

Cisco 2691 Cisco IOS Software Release 12.3 and 12.3T

Cisco 3620, 3640, 3640A Not supported

Cisco 3660 Cisco IOS Software Release 12.3 and 12.3T

Cisco 3700 Series Cisco IOS Software Release 12.3 and 12.3T

Cisco 3800 Series Cisco IOS Software Release 12.3(11)T

Maximum Cisco NM-xCE1T1-PRI Network Modules per Platform

Table 2 shows the maximum Cisco E1/T1 ISDN Network Module supported in each platform.

Table 2. Maximum Supported NM-xCE1T1-PRI Modules per Platform

Type of Module Cisco 2610-

51XM Cisco 2800 Cisco 2691 Cisco 3660 Cisco 3725 Cisco 3745 Cisco 3825 Cisco 3845

NM-1CE1T1-PRI 1 1 1 6 2 4 2 4

NM-2CE1T1-PRI 1 1 1 6 2 4 2 4

SOFTWARE AND MANAGEMENT FEATURES

Table 3 shows the software and management features for the Cisco E1/T1 ISDN PRI Network Modules.

Table 3. Software and Management Features

Feature Description

Diagnostic Loopback Support E1 loopback modes

•Controller local loopback

•Interface local loopback

T1 loopback modes

•Interface local loopback

•Interface remote loopback

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com.

Page 4 of 8

Feature Description

•Controller local loopback

•Controller remote loopback

CSU loopback modes for T1 CSU

•Data terminal equipment (DTE) loopback

•Network loopback

•Payload loopback

•V.54

Alarm Detection •Yellow Alarm—Receive/Send from/to network

•Blue Alarm—Receive alarm indication signal (AIS) from network

•Red Alarm—Loss of network signal

Relevant Management Information

Base (MIB) Support •RFC1406-MIB

•CISCO-ICSUDSU-MIB

Remote Management •Supported by Cisco WAN Access Performance Management System (WAPMS)

•Cisco Intelligence Engine (IE2100)

•CiscoWorks

Signaling Debugging •CAS debugs

•ISDN Q.921 and Q.931 decode

•All other previously existing applicable Cisco IOS debugs

HARDWARE SPECIFICATIONS

Table 4 shows the hardware specifications for the Cisco E1/T1 ISDN PRI Network Module.

Table 4. Hardware Specifications for the Cisco E1/T1 ISDN PRI Network Module

Feature Description

Dimensions (H x W x D) •1.55 x 7.10 x 7.2 inches

•3.9 x 18.0 x 18.3 centimeters

Operating Temperature 32 to 104°F (0 to 40°C)

Nonoperating Temperature –40 to 185°F (–40 to 85°C)

Relative Humidity 5-95% non-condensing

LEDs LEDs per port

•T1: T1 mode selected

•E1-BAL: E1 balanced mode selected

•E1-UNBAL: E1 unbalanced mode selected

•CD: Carrier detect

•LP: Loop condition present

•RA: Remote alarm detected

•LA: Local alarm detected

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com.

Page 5 of 8

Feature Description

LEDs per module

•C0: Tx/Rx Mon bantam jacks connected to port 0

•C1: Tx/Rx Mon bantam jacks connected to port 1

•EN: Network-module (NM) Enable

•AIM: Integrated Advanced Integration Module (AIM) slot in use (future use—currently disabled)

Ports •1 or 2 E1/T1 ports on RJ-48C connectors

•Tx/Rx Mon bantam (tty) jacks for monitoring network activity (port selectable through Cisco IOS

Command Line Interface (CLI))

Line Bit Rate (Per Port) •E1: (2.048 Mbps)

•T1: (1.544 Mbps)

Line Coding •E1: HDB3

•T1: AMI, B8ZS

Framing Formats •E1: CRC4

•T1: SF and ESF

Output Levels •E1: short-haul/long-haul

•T1 (LBO): - 0, -7.5, or -15 dB

PRODUCT NUMBERS AND ORDERING INFORMATION

Table 5 lists the product numbers of the Cisco E1/T1 ISDN PRI Network Module.

Table 5. Product Numbers of the Cisco E1/T1 ISDN PRI Network Module

Product Number Description

NM-1CE1T1-PRI 1-Port Channelized E1/T1/ISDN-PRI Network Module

NM-2CE1T1-PRI 2-Port Channelized E1/T1/ISDN-PRI Network Module

CAB-E1-RJ45BNC E1 Cable RJ-45 to Dual BNC (Unbalanced)

CAB-E1-RJ45TWIN E1 Cable RJ-45 to Twinax (Balanced)

REGULATORY COMPLIANCE, SAFETY, EMISSIONS, AND EMC/IMMUNITY

Table 6 shows a partial listing of regulatory compliance and safety data.

Table 6. Regulatory Compliance and Safety (Partial Listing*)

Feature Description

Regulatory Compliance •FCC Part 68, TIA-968-A

•CS-03

•Australia (S016, S038)

•JATE (T1)

•TBR4, 12, 13 (and NET5, ETS300156, ETS300 011)

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com.

Page 6 of 8

Feature Description

Telecommunication Interface Industry Standards •CCITT/ITU G.703, G.704, G.706, I.431, G.823

•ANSI T1.403

Safety •US (UL60950)

•Canada (C22.2 No.60950)

•Europe (EN60950)

•Australia/New Zealand (AS/NZS3260, TS001)

•Other Countries (IEC60950)

NEBS GR-63, GR-78, GR-1089-CORE Type 1/3

EMC Emissions/Immunity •EN 300 386 v1.3.1:2001

•AS/NZS3548:1995

•VCCI:V-3/2000.04

•CNS13438:1997

•CFR47 Part 15:2000

•EN61000-6-1:2001

•CISPR22:1997 [EN55022:1998]

•EN55024:1998

•EN50082-1:1992, EN50082-1:1997

•EN61000-4-2:1995 [incl AMD1 + AMD2]

•EN61000-4-3:1996 [Incl AMD 1 & 2]

•EN61000-4-4:1995, EN61000-4-5:1995

•EN61000-4-6:1996 [incl AMD1]

* For more information, visit the Cisco Compliance home page (listed later in this document under Country Support) or consult your local Cisco representative for

further details.

POWER AND ENVIRONMENTAL REQUIREMENTS

The Cisco NM-xCE1T1-PRI network modules, when installed in Cisco routers, do not change the power or environmental requirements and

standards of the router itself. See platform-specific data sheets for more information:

•For information about Cisco 2610-51XM and 2691 routers, visit:

http://www.cisco.com/en/US/prod/collateral/routers/ps259/product_data_sheet0900aecd800fa5be.html

•For information about Cisco 2800 routers, visit: http://www.cisco.com/en/US/products/ps5854/index.html

•For information about Cisco 3660 routers, visit:

http://www.cisco.com/en/US/products/hw/routers/ps274/products_data_sheet09186a0080091ba4.html

•For information about Cisco 3700 Series routers, visit:

http://www.cisco.com/en/US/prod/collateral/routers/ps282/product_data_sheet09186a008009203f.html

•For information about Cisco 3800 Series routers, visit: http://www.cisco.com/en/US/products/ps5855/index.html

COUNTRY SUPPORT

See the following URL or contact your local Cisco representative for country-specific approval status (Cisco.com login required):

http://www.cisco.com/cgi-bin/compliance/approvals_search.pl

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com.

Page 7 of 8

Corporate Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 526-4100

European Headquarters

Cisco Systems International BV

Haarlerbergpark

Haarlerbergweg 13-19

1101 CH Amsterdam

The Netherlands

www-europe.cisco.com

Tel: 31 0 20 357 1000

Fax: 31 0 20 357 1100

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

www.cisco.com

Tel: 408 526-7660

Fax: 408 527-0883

Asia Pacific Headquarters

Cisco Systems, Inc.

168 Robinson Road

#28-01 Capital Tower

Singapore 068912

www.cisco.com

Tel: +65 6317 7777

Fax: +65 6317 7799

Cisco Systems has more than 200 offices in the following countries and regions. Addresses, phone numbers, and fax numbers are listed on

the Cisco Website at www.cisco.com/go/offices.

Argentina • Australia • Austria • Belgium • Brazil • Bulgaria • Canada • Chile • China PRC • Colombia • Costa Rica • Croatia • Cyprus

Czech Republic • Denmark • Dubai, UAE • Finland • France • Germany • Greece • Hong Kong SAR • Hungary • India • Indonesia • Ireland • Israel

Italy • Japan • Korea • Luxembourg • Malaysia • Mexico • The Netherlands • New Zealand • Norway • Peru • Philippines • Poland • Portugal

Puerto Rico • Romania • Russia • Saudi Arabia • Scotland • Singapore • Slovakia • Slovenia • South Africa • Spain • Sweden • Switzerland • Taiwan

Thailand • Turkey • Ukraine • United Kingdom • United States • Venezuela • Vietnam • Zimbabwe

Changing the Way We Work, Live, Play, and Learn, and iQuick Study are service marks of Cisco Systems, Inc.; and Access Registrar, Aironet, ASIST, BPX, Catalyst, CCDA, CCDP,

CCIE, CCIP, CCNA, CCNP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity,

Empowering the Internet Generation, Enterprise/Solver, EtherChannel, EtherFast, EtherSwitch, Fast Step, FormShare, GigaDrive, GigaStack, HomeLink, Internet Quotient, IOS, IP/TV, iQ

Expertise, the iQ logo, iQ Net Readiness Scorecard, LightStream, Linksys, MeetingPlace, MGX, the Networkers logo, Networking Academy, Network Registrar, Packet, PIX, Post-

Routing, Pre-Routing, ProConnect, RateMUX, ScriptShare, SlideCast, SMARTnet, StrataView Plus, TeleRouter, The Fastest Way to Increase Your Internet Quotient, and TransPath are

registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.

All other trademarks mentioned in this document or Website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between

Cisco and any other company. (0502R) 205481.Z_ETMG_CC_11.05

Printed in the USA

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com.

Page 8 of 8

Otros manuales para 2610 - Router - EN

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de red de Cisco

Cisco

Cisco ONS 15454 M12 Manual de usuario

Cisco

Cisco ASR 5000 Manual de instrucciones

Cisco

Cisco ONS 15200 Series Manual de usuario

Cisco

Cisco C8510MSR-SKIT-DC - Catalyst 8510 Multiservice Switch... Manual de usuario

Cisco

Cisco ATM Cable Interface Processor ACIP-SM(=) Manual del operador

Cisco

Cisco ON100 Network Agent Manual de usuario

Cisco

Cisco NCS 2000 series Manual de usuario

Cisco

Cisco Catalyst 8300 Series Manual

Cisco

Cisco Fourth-Generation Versatile Interface Processor... Manual del operador

Cisco

Cisco AIR-WLC2106-K9 - Wireless LAN Controller... Manual de usuario

Cisco

Cisco 220 Series Smart Plus Manual de usuario

Cisco

Cisco VPN 3002 Hardware Client Manager Manual de usuario

Cisco

Cisco DS-X9530-SF1-K9 - Supervisor-1 Module - Control... Manual de usuario

Cisco

Cisco MultiRIP Ethernet Card Manual de usuario

Cisco

Cisco ONS 15454 Manual de usuario

Cisco

Cisco ISA 3000 Guía de inicio rápido

Cisco

Cisco CGR 1000 Series Manual de usuario

Cisco

Cisco FirePOWER 8000 Series Manual de usuario

Cisco

Cisco MX60 Manual de usuario

Cisco

Cisco Secure Firewall Management Center 1700 Manual de usuario

Cisco

Cisco Prisma EtherLinX Manual de usuario

Cisco

Cisco TELEPRESENCE MCU ACCESSING CONFERENCES - Manual de usuario

Cisco

Cisco IDS 4210 - Intrusion Detection Sys 4210... Manual de usuario

Cisco

Cisco Aironet 340 Series Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
