Cisco 6050 Manual de usuario

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

Cisco Video Surveillance 6050 IP Camera

Installation Guide

Text Part Number: OL-31413-01

NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED

WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT

SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE

OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.

The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public

NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH

ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT

LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF

DEALING, USAGE, OR TRADE PRACTICE.

IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING,

WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO

OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found at

www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership

relationship between Cisco and any other company. (1005R)

Cisco Video Surveillance 6050 IP Camera Installation Guide



iii

Cisco Video Surveillance 6050 IP Camera Installation Guide

OL-31413-01

CONTENTS

Preface v

Overview v

Organization v

Obtaining Documentation, Obtaining Support, and Security Guidelines v

CHAPTER

Overview 1-1

Introduction 1-1

Package Contents 1-1

IP Camera Physical Details 1-2

M12 Connector Pinouts 1-3

CHAPTER

Camera Installation 2-1

Warnings Before Installation 2-1

Installing the IP Camera 2-2

CHAPTER

Performing the Initial Setup of the IP Camera 3-1

CHAPTER

Camera Management 4-1

Understanding the IP Camera User Interface 4-1

IP Camera Window Links 4-1

IP Camera Windows 4-2

Adjusting the IP Camera Viewing Angle and Focus and Completing the Installation 4-3

Powering the IP Camera On or Off 4-7

Resetting the IP Camera 4-7

Viewing Live Video 4-7

NDEX

Contents

Cisco Video Surveillance 6050 IP Camera Installation Guide

OL-31413-01

Cisco Video Surveillance 6050 IP Camera Installation Guide

OL-31413-01

Preface

Overview

This document, Cisco Video Surveillance 6050 IP Camera Installation Guide, provides information

about installing and deploying the Cisco Video Surveillance 6050 High-Definition IP Camera.

Organization

This manual is organized as follows:

Obtaining Documentation, Obtaining Support, and Security

Guidelines

For information about obtaining documentation, submitting a service request, and gathering additional

information, see the monthly What’s New in Cisco Product Documentation, which also lists all new and

revised Cisco technical documentation, at:

http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html

Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed

and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free

service and Cisco currently supports RSS version 2.0.

Chapter 1, “Overview” Provides an overview of the IP camera and its features.

Chapter 2, “Camera Installation” Provides instructions for physically installing the IP camera.

Chapter 3, “Performing the Initial

Setup of the IP Camera”

Provides instructions for performing the initial network setup of

the IP camera.

Chapter 4, “Camera Management” Provides instructions for accessing and understanding the

IP camera user interface, adjusting its focus and zoom, powering

the IP camera on and off, and resetting the IP camera.

Cisco Video Surveillance 6050 IP Camera Installation Guide

OL-31413-01

Preface

CHAPTER

1-1

Cisco Video Surveillance 6050 IP Camera Installation Guide

OL-31413-01

Overview

This chapter describes the Cisco Video Surveillance 6050 High-Definition IP Camera, and includes the

following topics:

•

Introduction, page 1-1

•

Package Contents, page 1-1

•

IP Camera Physical Details, page 1-2

•

M12 Connector Pinouts, page 1-3

Introduction

The Cisco Video Surveillance 6050 IP camera is a ruggedized, outdoor, high-definition video endpoint

with industry-leading image quality and processing power. This vibration resistant camera is ideal for

use in transportation applications such as buses, trains, and other moving vehicles. The IK10- and

IP67-rated housing combined with a low profile also make this camera suitable for discreet placement

in harsh environments. Video can be streamed at a full 1080p resolution at 30 frames per second (fps)

while optimizing network usage with either H.264 or MJPEG compression. With its open,

standards-based design, the camera provides an ideal platform for integration and operation as an

independent device or as part of a Cisco video surveillance network.

Package Contents

The Cisco Video Surveillance IP Camera package includes the following items:

•

Cisco Video Surveillance 6050 IP Camera (1)

•

Installation template and alignment sticker (1)

•

Waterproof connector for M12 cable (1)

•

Screws (M4 x 25)

•

Screw anchors (3)

•

T10 Screwdriver

•

Ground wire (1)

•

Washer for ground wire (1)

•

Screw for ground wire (1)

1-2

Cisco Video Surveillance 6050 IP Camera Installation Guide

OL-31413-01

Chapter 1 Overview

IP Camera Physical Details

•

Double-sided tape (1)

•

Silica gel (1)

•

Cisco documentation pointer card (1)

•

Cisco RoHS document (1)

•

Extra set of labels (3)

IP Camera Physical Details

Figure 1-1 and the table that follows describe the physical features of the 6050 IP camera.

Figure 1-1 IP Camera Physical Features

1-3

Cisco Video Surveillance 6050 IP Camera Installation Guide

OL-31413-01

Chapter 1 Overview

M12 Connector Pinouts

Figure 1-2 and the table that follows describe the pinouts of the M12 connector. You will need this

information if you use the waterproof connector when you install the IP camera.

Figure 1-2 M12 Connector Pinouts

1Recessed Reset button.

This button reboots the IP camera or resets it to a default state. You can use a pin or paper clip to

depress it. It can be used any time that the IP camera is on and can have various effects, as

described in the “Resetting the IP Camera” section on page 4-7.

2Status LEDs.

The power LED glows red when the IP camera is powered on. The Network LED blinks green

when the IP camera is connected to a network.

3Lens.

4Screw holes.

5SD/SDHC card slot.

Pin Description

1TX+

2TX–

3RX+

4RX–

5V+

6V+

1-4

Cisco Video Surveillance 6050 IP Camera Installation Guide

OL-31413-01

Chapter 1 Overview

M12 Connector Pinouts

7V–

8V–

Pin Description
