Product Overview
The Catalyst 3850 family of switches are Ethernet switches to which you can connect devices such as Cisco
IP Phones, Cisco Wireless Access Points, workstations, and other network devices such as servers, routers,
and other switches.
The Catalyst 3850 switches support stacking through Cisco StackWise-480 technology and power management
through StackPower. The StackWise technology for the Catalyst 3850 switches is called StackWise-480.
Unless otherwise noted, the term switch refers to a standalone switch and to a switch stack.
This chapter contains these topics:
•Switch Models, on page 1
•Front Panel, on page 6
•Rear Panel, on page 22
•Management Options, on page 31
Switch Models
Table 1: Catalyst 3850 Switch Models and Descriptions
DescriptionSupported Software ImageSwitch Model
Stackable 24 10/100/1000 Ethernet
ports, 1 network module slot, 350
W power supply
LAN BaseWS-C3850-24T-L
Stackable 48 10/100/1000 Ethernet
ports, 1 network module slot, 350
W power supply
LAN BaseWS-C3850-48T-L
Stackable 24 10/100/1000 PoE+2
ports, 1 network module slot, 715
W power supply
LAN BaseWS-C3850-24P-L
Stackable 48 10/100/1000 PoE+
ports, 1 network module slot, 715
W power supply
LAN BaseWS-C3850-48P-L
Product Overview
1
DescriptionSupported Software ImageSwitch Model
Stackable 48 10/100/1000 PoE+
ports, 1 network module slot, 1100
W power supply
LAN BaseWS-C3850-48F-L
Stackable 24 10/100/1000 Cisco
UPOE3ports, 1 network module
slot, 1100 W power supply
LAN BaseWS-C3850-24U-L
Stackable 48 10/100/1000 Cisco
UPOE ports, 1 network module
slot, 1100 W power supply
LAN BaseWS-C3850-48U-L
Stackable 12
100M/1G/2.5G/5G/10G and 36 1G
UPoE ports, 1 network module slot,
1100 W power supply
LAN BaseWS-C3850-12X48U-L
Stackable 24
100M/1G/2.5G/5G/10G UPoE
ports, 1 network module slot,
1100-W power supply
LAN BaseWS-C3850-24XU-L
Stackable 24 10/100/1000 Ethernet
ports, 1 network module slot, 350
W power supply
IP BaseWS-C3850-24T-S
Stackable 48 10/100/1000 Ethernet
ports, 1 network module slot, 350
W power supply
IP BaseWS-C3850-48T-S
Stackable 24 10/100/1000 PoE+
ports, 1 network module slot, 715
W power supply
IP BaseWS-C3850-24P-S
Stackable 48 10/100/1000 PoE+
ports, 1 network module slot, 715
W power supply
IP BaseWS-C3850-48P-S
Stackable 48 10/100/1000 PoE+
ports, 1 network module slot, 1100
W power supply
IP BaseWS-C3850-48F-S
Stackable 24 10/100/1000 Cisco
UPOE ports, 1 network module
slot, 1100 W power supply
IP BaseWS-C3850-24U-S
Stackable 48 10/100/1000 Cisco
UPOE ports, 1 network module
slot, 1100 W power supply
IP BaseWS-C3850-48U-S
Catalyst 3850 24-port PoE IP Base
with 5 access points license
IP BaseWS-C3850-24PW-S
Product Overview
2
Product Overview
Switch Models
DescriptionSupported Software ImageSwitch Model
Catalyst 3850 48-port PoE IP Base
with 5 access points license
IP BaseWS-C3850-48PW-S
Stackable 12 SFP module slots, 1
network module slot, 350 W power
supply
IP BaseWS-C3850-12S-S
Stackable 24 SFP module slots, 1
network module slot, 350 W power
supply
IP BaseWS-C3850-24S-S
Catalyst 3850 12-port SFP+
transceiver, 1 network module slot,
support for up to 10 G SFP+, 350
W power supply
IP BaseWS-C3850-12XS-S
Catalyst 3850 16-port SFP+
transceiver, 1 network module slot,
support for up to 10 G SFP+, 350
W power supply.
16 ports are available when the
C3850-NM-4-10G network module
is plugged into the
WS-C3850-12XS-S switch.
IP BaseWS-C3850-16XS-S
Catalyst 3850 24-port SFP+
transceiver, 1 network module slot,
support for up to 10 G SFP+, 715
W power supply.
IP BaseWS-C3850-24XS-S
Catalyst 3850 32-port SFP+
transceiver, 1 network module slot,
support for up to 10 G SFP+, 715
W power supply.
32 ports are available when the
C3850-NM-8-10G network module
is plugged into the
WS-C3850-24XS-S switch.
IP BaseWS-C3850-32XS-S
Catalyst 3850 switch with SFP+
transceivers, 48 ports that support
up to 10 G, and 4 QSFP ports that
support up to 40 G. 750 W power
supply.4
The airflow direction for this switch
is from the front panel to the rear
panel.
IP BaseWS-C3850-48XS-S
Product Overview
3
Product Overview
Switch Models
DescriptionSupported Software ImageSwitch Model
Catalyst 3850 switch with SFP+
transceivers, 48 ports that support
up to 10 G, and 4 QSFP ports that
support up to 40 G. 750 W power
supply.
The airflow direction for this switch
is from the rear panel to the front
panel.
IP BaseWS-C3850-48XS-F-S
Stackable 12
100M/1G/2.5G/5G/10G and 36 1
G UPoE ports, 1 network module
slot, 1100 W power supply
IP BaseWS-C3850-12X48U-S
Stackable 12
100M/1G/2.5G/5G/10G and 36 1
G UPoE ports, 1 network module
slot, 1100 W power supply
IP BaseWS-C3850-12X48UW-S
Stackable 24
100M/1G/2.5G/5G/10G UPoE
ports, 1 network module slot,
1100-W power supply
IP BaseWS-C3850-24XU-S
Stackable 24
100M/1G/2.5G/5G/10G UPoE
ports, 1 network module slot,
1100-W power supply
IP BaseWS-C3850-24XUW-S
Stackable 24 10/100/1000 Ethernet
ports, 1 network module slot, 350
W power supply
IP ServicesWS-C3850-24T-E
Stackable 48 10/100/1000 Ethernet
ports, 1 network module slot, 350
W power supply
IP ServicesWS-C3850-48T-E
Stackable 24 10/100/1000 PoE+
ports, 1 network module slot, 715
W power supply
IP ServicesWS-C3850-24P-E
Stackable 48 10/100/1000 PoE+
ports, 1 network module slot, 715
W power supply
IP ServicesWS-C3850-48P-E
Stackable 48 10/100/1000 PoE+
ports, 1 network module slot, 1100
W power supply
IP ServicesWS-C3850-48F-E
Product Overview
4
Product Overview
Switch Models
DescriptionSupported Software ImageSwitch Model
Stackable 24 10/100/1000 Cisco
UPOE ports, 1 network module
slot, 1100 W power supply
IP ServicesWS-C3850-24U-E
Stackable 48 10/100/1000 Cisco
UPOE ports, 1 network module
slot, 1100 W power supply
IP ServicesWS-C3850-48U-E
Stackable 12 SFP module slots, 1
network module slot, 350 W power
supply
IP ServicesWS-C3850-12S-E
Stackable 24 SFP module slots, 1
network module slot, 350 W power
supply
IP ServicesWS-C3850-24S-E
Catalyst 3850 12-port SFP+
transceiver, 1 network module slot,
support for up to 10 G SFP+, 350
-W power supply.
IP ServicesWS-C3850-12XS-E
Catalyst 3850 16-port SFP+
transceiver, 1 network module slot,
support for up to 10 G SFP+, 350
W power supply.
16 ports are available when the
C3850-NM-4-10G network module
is plugged into the
WS-C3850-12XS-E switch.
IP ServicesWS-C3850-16XS-E
Catalyst 3850 24-port SFP+
transceiver, 1 network module slot,
support for up to 10 G SFP+, 715
W power supply.
IP ServicesWS-C3850-24XS-E
Catalyst 3850 32-port SFP+
transceiver, 1 network module slot,
support for up to 10 G SFP+, 715
W power supply.
32 ports are available when the
C3850-NM-8-10G network module
is plugged into the
WS-C3850-24XS-E switch.
IP ServicesWS-C3850-32XS-E
Product Overview
5
Product Overview
Switch Models
DescriptionSupported Software ImageSwitch Model
Catalyst 3850 switch with SFP+
transceivers, 48 ports that support
up to 10 G, and 4 QSFP ports that
support up to 40 G. 750 W power
supply.
The airflow direction for this switch
is from the front panel to the rear
panel.
IP ServicesWS-C3850-48XS-E
Catalyst 3850 switch with SFP+
transceivers, 48 ports that support
up to 10 G, and 4 QSFP ports that
support up to 40 G. 750 W power
supply.
The airflow direction for this switch
is from the rear panel to the front
panel.
IP ServicesWS-C3850-48XS-F-E
Stackable 12
100M/1G/2.5G/5G/10G and 36 1
G UPoE ports, 1 network module
slot, 1100 W power supply
IP ServicesWS-C3850-12X48U-E
Stackable 24
100M/1G/2.5G/5G/10G UPoE
ports, 1 network module slot,
1100-W power supply
IP ServicesWS-C3850-24XU-E
1For supported network modules, see Network Modules, on page 11 .
2PoE+ = Power over Ethernet plus (provides up to 30 W per port).
3UPOE = Universal Power Over Ethernet (provides up to 60 W Cisco UPOE per port)
4The WS-C3850-48XS switches do not support StackWise-480
Front Panel
This section describes the front panel components:
• 24 or 48 downlink ports of one of these types:
• 10/100/1000
• 10/100/1000 PoE+
• 10/100/1000 Cisco UPoE
• 10 G SFP+
• 12 or 24 SFP or SFP+ module downlink slots
• Uplink network modules slot
• USB Type A connector
• USB mini-Type B (console) port
Product Overview
6
Product Overview
Front Panel
• LEDs
• Mode button
All of the switches have similar components. See the following illustrations for examples.
The Catalyst 3850 switches might have slight cosmetic differences on the bezels.
Note
Figure 1: WS-C3850-48P-L Switch Front Panel
USB mini-Type B
(console) port
4Mode button1
10/100/1000 PoE+ ports5Status LEDs2
Network module6USB Type A storage port3
Figure 2: WS-C3850-24S Switch Front Panel
The WS-C3850-12S switches have similar front panels.
Note
USB Type A storage port5UID button1
SFP module slots
(downlink)
6Mode button2
Network module7Status LEDs3
Product Overview
7
Product Overview
Front Panel
USB mini-Type B
(console) port
4
Figure 3: WS-C3850-24XS-E Switch Front Panel
The WS-C3850-24XS-E switches have the following components.
Note
USB mini-Type B
(console) port
4Mode button1
10 G SFP+ ports5Status LEDs2
Network module6USB Type A storage port3
10/100/1000 Ports
The 10/100/1000 ports use RJ-45 connectors with Ethernet pinouts. The 10BASE-T, 100BASE-TX,
1000BASE-T traffic requires Category 5 or Category 5e twisted pair (UTP) cable. The 10BASE-T traffic can
use Category 3 or Category 4 UTP cable.
PoE, PoE+, and Cisco UPoE Ports
The PoE+ and Cisco Universal Power Over Ethernet (Cisco UPoE) ports use the same connectors as described
in 10/100/1000/Multigigabit Ethernet Port Connections. They provide:
• PoE+ ports: Support for IEEE 802.3af-compliant powered devices (up to 15.4 W PoE per port) and
support for IEEE 802.3at-compliant powered devices (up to 30 W PoE+ per port). The maximum total
PoE power in a 1RU switch is 1800 W.
• Support for Cisco-enhanced PoE.
• Support for prestandard Cisco powered devices.
• Configuration for StackPower. When the switch internal power supply module(s) cannot support the
total load, StackPower configurations allow the switch to leverage power available from other switches.
• Configurable support for Cisco intelligent power management, including enhanced power negotiation,
power reservation, and per-port power policing.
Product Overview
8
Product Overview
10/100/1000 Ports
Depending on the installed power supply modules, each port can deliver up to 60 W of Cisco UPOE. See the
Power Supply Modules, on page 25 for the power supply matrix that defines the available PoE, PoE+, and
Cisco UPOE power per port. The output of the PoE+ circuit has been evaluated as a Limited Power Source
(LPS) per IEC 60950-1.
Restrictions for the WS-C3850-12X48U-L, WS-C3850-12X48U-S and WS-C3850-12X48U-E switch models:
• A maximum of 28 ports are available for UPoE connections. This is because some power from the power
supplies is diverted to the switch, and only the remaining power is transmitted to the ports.
Note
SFP and QSFP Module Slots
The uplink and downlink ports for the Catalyst WS-C3850 switch models are as follows.
• The downlink ports on the Catalyst WS-C3850-12S and WS-C3850-24S switch models support standard
SFP modules.
• The downlink ports on the Catalyst WS-C3850-12XS and WS-C3850-24XS switch models support
standard SFP+ modules.
•The 10G downlink ports on the Catalyst WS-C3850-48XS-S, WS-C3850-48XS-F-S, WS-C3850-48XS-E
and WS-C3850-48XS-F-E switch models support standard SFP+ modules.
•The 40G downlink ports on the Catalyst WS-C3850-48XS-S, WS-C3850-48XS-F-S, WS-C3850-48XS-E
and WS-C3850-48XS-F-E switch models support standard QSFP modules.
For supported SFP modules, refer to the Cisco Transceiver Modules Compatibility Information at
http://www.cisco.com/en/US/products/hw/modules/ps5455/products_device_support_tables_list.html
For information about the (uplink) SFP module slots on the network modules, see Network Modules, on page
11.
Note
Management Ports
The management ports connect the switch to a PC running Microsoft Windows or to a terminal server.
• Ethernet management port. See Ethernet Management Port, on page 30.
• RJ-45 console port (EIA/TIA-232). See RJ-45 Console Port, on page 31.
• USB mini-Type B console port (5-pin connector).
The 10/100/1000 Ethernet management port connection uses a standard RJ-45 crossover or straight-through
cable. The RJ-45 console port connection uses the supplied RJ-45-to-DB-9 female cable. The USB console
port connection uses a USB Type A to 5-pin mini-Type B cable. The USB console interface speeds are the
same as the RJ-45 console interface speeds.
Product Overview
9
Product Overview
SFP and QSFP Module Slots
If you use the USB mini-Type B console port, the Cisco Windows USB device driver must be installed on
any PC connected to the console port (for operation with Microsoft Windows). Mac OS X or Linux do not
require special drivers.
The 4-pin mini-Type B connector resembles the 5-pin mini-Type B connectors. They are not compatible. Use
only the 5-pin mini-Type B.
Figure 4: USB Mini-Type B Port
This illustration shows a 5-pin mini-Type B USB port.
With the Cisco Windows USB device driver, you can connect and disconnect the USB cable from the console
port without affecting Windows HyperTerminal operations.
The console output always goes to both the RJ-45 and the USB console connectors, but the console input is
active on only one of the console connectors at any one time. The USB console takes precedence over the
RJ-45 console. When a cable is connected into the USB console port, the RJ-45 console port becomes inactive.
Conversely, when the USB cable is disconnected from the USB console port, the RJ-45 port becomes active.
You can use the command-line interface (CLI) to configure an inactivity timeout which reactivates the RJ-45
console if the USB console has been activated and no input activity has occurred on the USB console for a
specified time.
After the USB console deactivates due to inactivity, you cannot use the CLI to reactivate it. Disconnect and
reconnect the USB cable to reactivate the USB console. For information on using the CLI to configure the
USB console interface, see the software guide.
USB Type A Port
The USB Type A port provides access to external USB flash devices (also known as thumb drives or USB
keys) and to specific Cisco USB Bluetooth devices.
The port supports Cisco USB flash drives with capacities from 128 MB to 8 GB (USB devices with port
densities of 128 MB, 256 MB, 1 GB, 4 GB, and 8 GB are supported). When combined with stacking, you can
upgrade other switches in the stack from an USB key inserted in any switch within the stack. Cisco IOS
software provides standard file system access to the flash device: read, write, erase, and copy, as well as the
ability to format the flash device with a FAT file system.
It provides you with the ability to automatically upgrade the internal flash with the USB drive's configuration
and image for emergency switch recovery using USB auto-upgrade. This feature checks the internal flash for
a bootable image and configuration and if either image or the configuration is not available, then the USB
drive is checked for boot images and configuration. If the boot image and configuration are available, these
are copied to flash for the reboot.
The port supports Cisco USB Bluetooth devices. The USB Bluetooth device acts as a Bluetooth host and
serves as either a serial port or a management port connection. You can pair it with your Bluetooth smart
phone, laptop, or tablet. If you configure the serial profile on the Bluetooth device, the switch turns the USB
port into a serial port. If you configure the Personal Area Network (PAN) profile on the Bluetooth device, the
switch turns the USB port into a management interface.
Product Overview
10
Product Overview
USB Type A Port
Este manual sirve para los siguientes modelos
47
Tabla de contenidos
Manuales populares de Hardware de red de otras marcas
Matrix Switch Corporation
Matrix Switch Corporation MSC-HD161DEL Manual de usuario
B&B Electronics
B&B Electronics ZXT9-IO-222R2 Manual de usuario
Yudor
Yudor YDS-16 Manual de usuario
D-Link
D-Link ShareCenter DNS-320L Manual de usuario
Samsung
Samsung ES1642dc Instrucciones de uso
Honeywell Home
Honeywell Home LTEM-PV Instrucciones de montaje
