Circutor Genion One Manual de usuario

INSTRUCTION MANUAL

Home manager for EV charging with self-supply

(M386B01-03-23B)

Genion One

Instruction Manual

Genion One

SAFETY PRECAUTIONS

DISCLAIMER

DANGER

Warns of a risk, which could result in personal injury or material damage.

ATTENTION

Indicates that special attention should be paid to a specific point.

Follow the warnings described in this manual with the symbols shown below.

If you must handle the unit for its installation, start-up or maintenance, the following should be

taken into consideration:

Incorrect handling or installation of the device may result in injury to personnel as well as damage to

the device. In particular, handling with voltages applied may result in electric shock, which may cause

death or serious injury to personnel. Defective installation or maintenance may also lead to the risk of

fire.

Read the manual carefully prior to connecting the device. Follow all installation and maintenance in-

structions throughout the device’s working life. Pay special attention to the installation standards of

the National Electrical Code.

Refer to the instruction manual before using the device

In this manual, if the instructions marked with this symbol are not respected or carried out correctly, it can result

in injury or damage to the device and/or installations.

CIRCUTOR S.A.U. reserves the right to modify features or the product manual without prior notification.

CIRCUTOR S.A.U. reserves the right to make modifications to the device or the unit specifications set

out in this instruction manual without prior notice.

CIRCUTOR S.A.U. on its web site, supplies its customers with the latest versions of the device specifi-

cations and the most updated manuals.

www.circutor.com

CIRCUTOR S.A.U. recommends using the original cables and accessories that are sup-

plied with the device.

Genion One

Instruction Manual

CONTENTS

SAFETY PRECAUTIONS .........................................................................................................................................................3

DISCLAIMER ..........................................................................................................................................................................3

CONTENTS.............................................................................................................................................................................4

REVISION LOG .......................................................................................................................................................................5

SYMBOLS...............................................................................................................................................................................5

1. VERIFICATION UPON RECEPTION....................................................................................................................................6

2. DEVICE DESCRIPTION......................................................................................................................................................6

3. DEVICE INSTALLATION.....................................................................................................................................................7

3.1.- PRIOR RECOMMENDATIONS.................................................................................................................................... 7

3.2.- INSTALLATION.........................................................................................................................................................7

3.3.- DEVICE TERMINALS ................................................................................................................................................8

3.3.1.- VERSI0N 1..........................................................................................................................................................8

3.3.2.- VERSI0N 2.........................................................................................................................................................9

3.4.- CONNECTION DIAGRAM ........................................................................................................................................ 10

3.4.1.- VERSI0N 1........................................................................................................................................................ 10

3.4.2.- VERSI0N 2........................................................................................................................................................11

3.4.3.- CONNECTING THE CURRENT INPUT TO MC1 TRANSFORMERS .................................................................... 12

4. OPERATION ................................................................................................................................................................... 13

4.1.- PRINCIPLE OF OPERATION .................................................................................................................................... 13

4.2.- LED INDICATORS ................................................................................................................................................... 13

4.3.- RESET.................................................................................................................................................................... 15

5. COMMUNICATIONS ....................................................................................................................................................... 16

5.1.- RS-485 COMMUNICATIONS .................................................................................................................................. 16

5.1.1.- CONNECTION .................................................................................................................................................. 16

5.2- Wi-Fi COMMUNICATIONS ....................................................................................................................................... 17

5.2.1.- USAGE ENVIRONMENT AND HEALTH ............................................................................................................. 17

5.2.2.- Wi-Fi COMMUNICATIONS ................................................................................................................................ 17

5.3- ETHERNET COMMUNICATIONS............................................................................................................................... 17

6. CONFIGURATION WEBSITE ........................................................................................................................................... 18

6.1- CONNECTION........................................................................................................................................................... 18

6.2- DASHBOARD...........................................................................................................................................................20

6.2.1.-GLOBAL CONSUMPTION ..................................................................................................................................20

6.2.2.- SOLAR PRODUCTION ..................................................................................................................................... 21

6.2.3.- CONSUMPTION DISTRIBUTION ...................................................................................................................... 21

6.2.4.- CURRENT POWER .......................................................................................................................................... 21

6.2.5.- EV CHARGER ..................................................................................................................................................22

6.3- SCHEDULE..............................................................................................................................................................23

6.4- CONFIGURATION.....................................................................................................................................................25

6.5- SYSTEM INFORMATION ..........................................................................................................................................25

6.6- COMMUNICATIONS .................................................................................................................................................26

6.7- INSTALLATION ........................................................................................................................................................28

6.8- CHARGER RECOVERY ............................................................................................................................................. 31

7. TECHNICAL FEATURES ..................................................................................................................................................32

8. MAINTENANCE AND TECHNICAL SERVICE ...................................................................................................................34

9. WARRANTY....................................................................................................................................................................34

10. EU DECLARATION OF CONFORMITY............................................................................................................................35

Instruction Manual

Genion One

REVISION LOG

Table 1: Revision log.

Date Revision Description

05/23 M386B01-03-23B Initial Version

Note: The images of the devices are for illustrative purposes only and may differ from the original

device.

SYMBOLS

Table 2: Symbols.

Symbol Description

In accordance with the relevant European directive.

Device covered by European Directive 2012/19/EC. At the end of its useful life, do not discard of

the device in a household refuse bin. Follow local regulations on electronic equipment recycling.

Direct current.

~Alternating current.

Genion One

Instruction Manual

1.- VERIFICATION UPON RECEPTION

Check the following points upon receiving the device:

a) The device meets the specifications described in your order.

b) The device has not suffered any damage during transport.

c) Perform an external visual inspection of the device prior to switching it on.

d) Check that it has been delivered with the following:

- An installation guide

If any problem is noticed upon reception, immediately contact the transport com-

pany and/or CIRCUTOR’s after-sales service.

2.- DEVICE DESCRIPTION

Genion One is an energy flow manager for home installations with electric vehicle chargers and

self-supply. It also features a 4-quadrant power analyzer to collect all the information on the electricity

being supplied from or to the electrical grid, the solar cells and the electric vehicle charger.

The device features Wi-Fi, Ethernet and RS-485. Genion One incorporates a web app that can be used

to configure and display all the parameters of the home installation via Wi-Fi or Ethernet in real time.

The device features:

- RS-485, Ethernet and Wi-Fi communications.

- 6indicating LEDs.

- A web app that can be used to configure and display all the parameters of the home instal-

lation via Wi-Fi or Ethernet in real time.

Instruction Manual

Genion One

3.- DEVICE INSTALLATION

3.1.- PRIOR RECOMMENDATIONS

In order to use the device safely, it is critical that individuals who handle it follow the

safety measures set out in the standards of the country where it is being used, use the

personal protective equipment necessary, and pay attention to the various warnings

indicated in this instruction manual.

The Genion One gateway must be installed by authorised and qualified staff.

The power supply must be disconnected before handling, altering the connections or replacing the

device. It is dangerous to handle the device while it is powered.

Also, it is critical to keep the cables in perfect condition to avoid accidents, personal injury and damage

to installations.

The manufacturer of the device is not responsible for any damage resulting from failure by the user

or installer to heed the warnings and/or recommendations set out in this manual, nor for damage

resulting from the use of products or accessories that did not come with the device or that were made

by other manufacturers.

If an anomaly or malfunction is detected in the device, do not use it to perform any operation.

Inspect the work area before making any connections. Do not make connections in dangerous areas or

where there is a risk of explosion.

The device must be disconnected from any power supply before carrying out any main-

tenance or repairs, or handling any of the device’s connections.

Please contact the after-sales service if you suspect that there is an operational fault

in the device.

3.2.- INSTALLATION

The Genion One has been designed for assembly on DIN rail.

Take into account that when the device is connected, the terminals may be hazardous

to the touch, and opening the covers or removing elements may provide access to parts

that are dangerous to the touch. Do not use the device until it is fully installed.

The device must be connected to a power circuit that is protected with gL (IEC 60269) or M class fuses

with a rating of 0.5 to 2 A. It must be fitted with a circuit breaker or equivalent device, in order to be

able to disconnect the device from the power supply network.

Genion One

Instruction Manual

3.3.- DEVICE TERMINALS

3.3.1.- VERSI0N 1

Genion One

Figure 1:Genion One terminals Version 1.

Table 3:List of Genion One Version 1 terminals.

Genion One terminals

1: V1, Power supply 8: V3, Voltage input

2: N, Power supply 9: N, Neutral voltage input

3: B-, RS-485 connection 10: N1, Neutral current input

4: A+, RS-485 connection 11: I3, EV Charger current input

5: GND, RS-485 connection 12: I2, Photovoltaic Generation current input

6: V1, Voltage input 13: I1, Mains current input

7: V2, Voltage input 14: Ethernet, Ethernet Connection

Instruction Manual

Genion One

3.3.2.- VERSI0N 2

Genion One

Figure 2: Genion One terminals Version 2.

Table 4:List of Genion One Version 2 terminals.

Genion One terminals

1: A1, Power supply 9: V3, Voltage input

2: A2, Power supply 10: N, Neutral voltage input

3: , Ground 11: N1, Neutral current input

4: B-, RS-485 connection 12: I3, EV Charger current input

5: A+, RS-485 connection 13: I2, Photovoltaic Generation current input

6: GND, RS-485 connection 14: I1, Mains current input

7: V1, Voltage input 15: Ethernet, Ethernet Connection

8: V2, Voltage input

Genion One

Instruction Manual

3.4.- CONNECTION DIAGRAM

3.4.1.- VERSI0N 1

eHome Link

Genion One

Generación Fotovoltaica

Photovoltaic Generation Red Eléctrica

Mains Cargador VE

EV charger

B-

A+

GND

A+B- SA+B- S

Figure 3: Genion One Version 1 connection diagram.
