CIRCLE M6 DC Manual de usuario

Document: Service Manual

Description: Treadmill

Model: M6 DC

Approved Date: 2017.05.09

Page: 2 of 22

TABLE OF CONTENTS

PREFACE......................................................................................................................................... 3

1. Information for Components & System

1.1 System wiring diagram ....................................................................................................................4

1.2 Motor Driver ......................................................................................................................................5

1.3 Console PCB .....................................................................................................................................7

2. ERROR MESSAGES AND SOLUTIONS .......................................................................................... 9

3. OTHER INFORMATION

3.1 No Any Display on Console (No Power) .......................................................................................11

3.2 Key Function Loss ..........................................................................................................................11

4. ENGINEERING MODE

4.1 How to enter the Engineering Mode .............................................................................................12

4.2 Function Descriptions of Engineering Mode................................................................................12

5. INITIALIZING............................................................................................................................. 14

6. BLUETOOTH BURNING MODEL

6.1 Bluetooth burning procedures of iOS system ..............................................................................15

6.2 Bluetooth burning procedures of Android system.......................................................................18

7. MAINTENANCE

7.1 General Maintenance .....................................................................................................................20

7.2 Running belt and running deck lubrication...................................................................................21

7.3 How to spray silicone on deck ......................................................................................................21

7.4 Care & Maintenance Schedule ......................................................................................................22

Document: Service Manual

Description: Treadmill

Model: M6 DC

Approved Date: 2017.05.09

Page: 3 of 22

PREFACE

WARNING! Only qualified service technicians should install and service the treadmill.

WARNING! No service should be undertaken until the technician has thoroughly read this Service

Manual.

CIRCLE FITNESS®provides this manual primarily to assist qualified service technicians in the service

of the appliance.

Should the reader have any questions or concerns which have not been satisfactorily addressed,

please call, send an e-mail message, or write to the CIRCLE FITNESS® Technical Support Department

for assistance.

Tel: +886-4-2359-1000#259

Fax: +886-4-3505-5801

Email: [email protected]

CIRCLE FITNESS®

P &F Brother Ind., Corp.

No.12, 6th Road, Industrial Park, 40755 Taichung Taiwan

Document: Service Manual

Description: Treadmill

Model: M6 DC

Approved Date: 2017.05.09

Page: 4 of 22

1. INFORMATION FOR COMPONENTS & SYSTEM

1.1 System wiring diagram

Document: Service Manual

Description: Treadmill

Model: M6 DC

Approved Date: 2017.05.09

Page: 5 of 22

1.2 Motor Driver

1.2.1 Definition of AC/DC input (J7 / J5)

Terminal name

Terminal type

Terminal remark

Terminal description

I/O

AC input

PCH250 Terminal

ACL

ACN

AC input

DC input

PCH250 Terminal

M+

DC motor ”+”

M-

DC motor “ -“

1.2.2 Definition of Electronic cable port (J2)

Terminal name

Terminal type

Terminal

remark

Terminal description

I/O

Electronic

cable port

XH 7P

2.5mm 180°M

FDC +V

FDC –V

RS485+

(Communications transmission

terminal)

I/O

RRS485-

(Communications transmission

terminal)

I/O

IP5V

(5V power)

SAFE KEY

(Emergency stop input terminal)

WAKE UP

J5 (DC input -)

J7 (AC input)

J3 (X)

J1(X)

：PIN 1

Document: Service Manual

Description: Treadmill

Model: M6 DC

Approved Date: 2017.05.09

Page: 6 of 22

1.2.3 Definition of RPM speed (J6)

Terminal name

Terminal type

Terminal remark

Terminal description

I/O

RPM speed

XH 2P

2.5mm 180°M

RPM Signal input

GND

1.2.4 Definition of Incline motor connector (J8)

Terminal name

Terminal type

Terminal remark

Terminal description

I/O

Incline motor

connector

PCH250

Terminal

Incline motor COM terminal

Incline motor UP terminal

Incline motor DOWN terminal

1.2.5 Definition of Incline motor position feedback (J4)

Terminal name

Terminal type

Terminal remark

Terminal description

I/O

Incline motor

position feedback

XH 3P 2.5mm

180°M

GND

Incline VR signal input terminal

DC 3.3V

Document: Service Manual

Description: Treadmill

Model: M6 DC

Approved Date: 2017.05.09

Page: 7 of 22

1.3 Console PCB

1.3.1 Definition of J1 (MAIN / Console wire) Connector

Define

FDC +

FDC -

RS485+

RS485-

SWVIN +

1.3.2 Definition of J3 (Incline & Speed) Connector

Define

COM

SLOW

FAST

DOWN

Define

PROGRAM

ENTER

STOP

START

1.3.3 Definition of J9 (Heart rate, Hand Pulse) Connector

Define

VCC

GND

Output

12V

1.3.4 Definition of J11 (Heart rate, Wireless) Connector

Define

VCC

GND

Output

1.3.5 Definition of J2 (Membrane key) Connector

(speed

)

(speed)

(Incline)

Display

FAN

Document: Service Manual

Description: Treadmill

Model: M6 DC

Approved Date: 2017.05.09

Page: 8 of 22

1.3.6 Definition of J5 (Emergency pull out device) Connector

Define

+5V

Control

1.3.7 Definition of J23 (FAN) Connector

Define

PWM 0~12V

GND

1.3.8 Definition of J25 ( To USB charger module) Connector

Define

DC12V

GND

Document: Service Manual

Description: Treadmill

Model: M6 DC

Approved Date: 2017.05.09

Page: 9 of 22

2. ERROR MESSAGES AND SOLUTIONS

Item

Error Message

Descriptions

UART

CAUSE: Communication timeout.

SOLUTION:

a. Check if PIN3 and PIN4 of the upper board are connected properly or

the loose contact.

b. Restart the treadmill to re-establish communication. If the error

message occurs again, please replace the upper board or the lower

board.

U-01

CAUSE: Lower board model is not matched.

SOLUTION: Restart the treadmill to re-establish communication. If the

error message occurs again, please replace the upper board or the

lower board.

U-02

CAUSE: Upper board and lower board are not matched.

SOLUTION: Check if the version of lower board is correct. Restart the

treadmill to re-establish communication. If the error message occurs

again, please replace the upper board or the lower board.

U-03

U-04

CAUSE: Lower board writing fault.

SOLUTION: Restart the treadmill and re-write the parameter to lower

board. If the error message occurs again, please replace the lower

board.

U-05

CAUSE: Lower board reading fault.

SOLUTION: Restart the treadmill and re-establish communication. If the

error message occurs again, please replace the lower board.

DC-1

CAUSE: The input voltage is too low.

SOLUTION: Restart the treadmill to clear this error message. If the error

message still pops out, please measure and improve the input voltage.

DC-2

CAUSE: Electric voltage is overload.

SOLUTION: Restart the treadmill to clear this error message.

DC-3

CAUSE: The input voltage is too high.

SOLUTION: Restart the treadmill to clear this error message. If the error

message is still pop out, please measure and improve the input voltage.

DC-4

CAUSE: Current overload.

SOLUTION: Restart the treadmill.

Document: Service Manual

Description: Treadmill

Model: M6 DC

Approved Date: 2017.05.09

Page: 10 of 22

Item

Error Message

Descriptions

10.

DC-5

CAUSE: Over current failure.

SOLUTION: Restart the treadmill.

11.

DC-6

CAUSE: Lower board failure.

SOLUTION: Replace the lower board.

12.

DC-7

CAUSE: During the operation, IGBT short circuit to protect lower board.

SOLUTION: Restart the treadmill and the error message “DC-6” pops

out. (It means the lower board needs to be replaced.)

13.

DC-8

CAUSE: The emergency stop button of the treadmill is loose contact.

Therefore the display of the upper board is normal but the operation of

lower board is interrupted.

SOLUTION: Check the wiring of emergency stop button. Make sure the

wiring between upper board and lower board is normal. If wiring is

normal, please replace the upper board or the lower board.

14.

CAUSE: Motor sensor failure.

SOLUTION:

Check if the motor is running normally.

- If not, please replace lower board or motor.

- If the motor runs normally, please check if the position of RPM sensor

and magnetic induction are correct.

15.

CAUSE: Incline motor doesn't reach the assigned position in limited

time within the mechanism safe range.

SOLUTION:

1. The variable resistor power supply (+) of incline motor is

disconnected.

2. The incline ADC circuit is damaged.

3. The incline motor movement is malfunction (stop or turn to wrong

side).

16.

CAUSE: The ADC value of incline motor is incorrect, and out of the

mechanism safe range.

SOLUTION:

1. The variable resistor power supply (－) of incline motor is

disconnected.

2. The incline motor movement is out of the mechanism safe range (too

high or too low).
