SEBRING SEDAN

Information is current as of September 1, 2009

www.media.chrysler.com

Note: Information shown is based on data available at time of publication (September 1, 2009).

Specifications are valid for Europe and may vary in other international markets. Vehicle model availability

may change per individual markets.

Chrysler Sebring Sedan

SPECIFICATIONS

Dimensions are in millimeters (inches) unless otherwise noted.

GENERAL INFORMATION

Body Style

Four-door sedan

Assembly Plant

Sterling Heights Assembly, Mich.

Vehicle Class

D-Segment

ENGINE: 2.0-LITER TURBO DIESEL DOHC 16-VALVE

Availability

Available on all Sebring models

Type and Description

Four cylinders in-line, turbocharged, high-pressure, direct injection

Displacement

1968 cu. cm (120.1 cu. in.)

Bore x Stroke

81 x 95.5 mm (3.19 x 3.76)

Valve System

Belt-driven DOHC, 16-valve

Fuel Injection

Electronically controlled, high-pressure direct injection

Construction

Cast-iron block, cast aluminum cylinder head, cast aluminum ladder

frame, forged steel crankshaft

Compression Ratio

18.0:1

Power

103 kW (140 hp DIN) @ 4000 rpm (70.0 hp DIN/L)

Torque

310 N•m (229 lb.-ft.) @ 1750 – 2500 rpm

Max. Engine Speed

5000 rpm (electronically limited)

Fuel Requirement

49 cetane diesel, DIN EN590

Oil Capacity

4.2 L (4.4 qt.) with dry filter

Coolant Capacity

4.0 L (4.2 qt.)

Emission Controls

Oxy-catalyst with integrated Diesel-particulate Filter (DPF) and cooled

Exhaust-gas Recirculation (EGR)

Emission Class

Euro IV

Fuel Consumption

Urban Cycle

8.2 L/100 km (6-mtx); 8.7 L/100 km (DCT)

Ex-urban Cycle

5.1 L/100 km (6-mtx); 5.6 L/100 km (DCT)

Combined Cycle

6.2 L/100 km (6-mtx); 6.8 L/100 km (DCT)

CO2 Emissions

164 g/km (6-mtx); 178 g/km (DCT)

SEBRING SEDAN

Information is current as of September 1, 2009

www.media.chrysler.com

ENGINE: 2.4-LITER, GASOLINE, DOHC, 16-VALVE, VVT, SMPI I-4

Availability

Available on all Sebring models

Type and Description

Four-cylinders inline, tuned intake manifold with Electronic

Active Charge Motion Control valves, dual counter-rotating balance

shafts dual Variable-valve Timing (VVT)

Displacement

2360 cu. cm (144 cu. in.)

Bore x Stroke

3.46 x 3.82 (88 x 97)

Valve System

Chain-driven DOHC, 16 valves, electronically controlled dual

Variable-valve Timing (VVT), direct-acting shimless mechanical

bucket tappets

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

High-pressure die cast-aluminum block with dry iron liners,

cast-aluminum cylinder heads, cast-aluminum ladder frame,

forged steel crankshaft

Compression Ratio

10.5:1

Power

124 kW (170 hp DIN) @ 6000 rpm (70.8 hp DIN/L)

Torque

220 N•m (162 lb.-ft.) @ 4400 rpm

Max. Engine Speed

6500 rpm (electronically limited)

Fuel Requirement

91 RON unleaded petrol

Oil Capacity

4.7 L (5.0 qt.)

Coolant Capacity

6.8 L (7.2 qt.)

Emission Controls

Single catalytic converter, dual heated oxygen sensors and

engine features

Emission Class

Euro IV

Fuel Consumption

Urban Cycle

12.2 L/100 km

Ex-urban Cycle

6.8 L/100 km

Combined Cycle

8.8 L/100 km

CO2 Emissions

208 g/km (4-atx)

ENGINE: 2.7-LITER, GASOLINE, DOHC, 24-VALVE, SMPI V-6

Availability

Available on all Sebring Touring and Limited models

Type and Description

60-degree, liquid-cooled, dual-tuned intake manifold with electronically

controlled manifold tuning valve

Displacement

2736 cu. cm (167 cu. in.)

Bore x Stroke

86 x 78.5 (3.38 x 3.09)

Valve System

DOHC, 24 valves, hydraulic end-pivot roller followers

Fuel Injection

Sequential, multi-port, electronic

Construction

Semi-permanent mold aluminum block with cast-in iron liners,

cast-aluminum heads

Compression Ratio

9.9:1

Power

137 kW (186 hp DIN) @ 5500 rpm (68.8 hp DIN/L)

Torque

256 N•m (191 lb.-ft.) @ 4000 rpm

Max. Engine Speed

6464 rpm (electronically limited)

Fuel Requirement

91 RON unleaded petrol, or E85

Oil Capacity

5.7 L (6 qt.) with dry filter

Coolant Capacity

9.0 L (9.5 qt.)

Emission Controls

Dual close-coupled three-way catalytic converters, quad-heated oxygen

sensors and internal engine features

SEBRING SEDAN

Information is current as of September 1, 2009

www.media.chrysler.com

Emission Class

Euro IV

Fuel Consumption

Urban Cycle

14.6 L/100 km

Ex-urban Cycle

7.2 L/100 km

Combined Cycle

9.9 L/100 km

CO2 Emissions

236 g/km (6-atx)

TRANSAXLE: 40TES, AUTOMATIC FOUR-SPEED OVERDRIVE

Availability

Available with 2.4 L engine

Description

4-speed overdrive, adaptive electronic control, electronically modulated

converter clutch

Gear Ratios

1st

2.842

2nd

1.57

3rd

4th

0.69

Reverse

2.21

Final-drive Ratio

3.91

Overall Top-gear

2.7

TRANSAXLE: 62TE, AUTOMATIC SIX-SPEED OVERDRIVE

Availability

Available with 2.7 L engine

Description

Six-speed, adaptive electronic control or Auto Stick driver-interactive

manual control and electronically modulated torque converter clutch

Gear Ratios

1st

4.127

2nd

2.842

3rd

2.283

4th

Upshift—1.452, WOT kickdown—1.570

5th

6th

0.69

Reverse

3.214

Transfer Ratio

0.95

Final-drive Ratio

3.43

Overall Top-gear

2.24

SEBRING SEDAN

Information is current as of September 1, 2009

www.media.chrysler.com

TRANSAXLE: AISIN BG6 SIX-SPEED MANUAL

Availability

Available with 2.0 L turbo-diesel engine

Description

Six-speed, overdrive, synchronized in all forward ratios,

cable-operated, 3-plane shifter

Gear Ratios

1st

3.59

2nd

2.05

3rd

1.37

4th

0.97

5th

0.90

6th

0.79

Reverse

3.83

Final-drive Ratio

4.06

Overall Top-gear

2.73

TRANSAXLE: GETRAG MPS6 SIX-SPEED DUAL-CLUTCH AUTOMATIC

Availability

Available with 2.0 L turbo-diesel engine

Description

Six-speed, overdrive, automated dual-clutch system with lay-shift

style gearsets, Auto Stick

Gear Ratios

1st

3.58

2nd

2.05

3rd

1.32

4th

0.97

5th

1.10

6th

0.91

Reverse

4.84

Final-drive Ratio

4.53 with gears 1-4; 3.24 with gears 5-6 and Reverse

Overall Top-gear

2.95

DRIVETRAIN

Front-wheel Drive

Standard with all engines

DIMENSIONS AND CAPACITIES

General

Wheelbase

2765 (108.9)

Track, Front

1570 (61.8)

Track, Rear

1570 (61.8)

Overall Length

4850 (190.6)

Overall Width

1808.4 (71.2)

Overall Height

1497 (59.0)

Fuel Tank Capacity, L (gal.)

64.0 (16.9)

Curb Weight, kg (lbs.)

2.0-liter Turbo-Diesel Engine: 1560 (3432)

2.0-liter Turbo-Diesel Engine (DCT): 1595 (3509)

2.4-liter V-6 Engine: 1480 (3256)

2.7-liter V-6 Engine: 1520 (3344)

SEBRING SEDAN

Information is current as of September 1, 2009

www.media.chrysler.com

Gross Vehicle Weight, kg (lbs.)

2.0-liter Turbo-Diesel Engine: 2085 (4587)

2.0-liter Turbo-Diesel Engine (DCT): 2085 (4587)

2.4-liter V-6 Engine: 2040 (4488)

2.7-liter V-6 Engine: 2040 (4488)

Maximum Trailer Mass (braked),

kg (lbs.)

2.0-liter Turbo-Diesel Engine: 1500 (3300)

2.0-liter Turbo-Diesel Engine (DCT): 1500 (3300)

2.4-liter V-6 Engine: 1000 (2200)

2.7-liter V-6 Engine: 1000 (2200)

Maximum Trailer Mass (unbraked),

kg (lbs.)

2.0-liter Turbo-Diesel Engine: 450 (990)

2.0-liter Turbo-Diesel Engine (DCT): 450 (990)

2.4-liter V-6 Engine: 450 (990)

2.7-liter V-6 Engine: 450 (990)

Maximum Tounge Load, kg (lbs.)

2.0-liter Turbo-Diesel Engine: 150 (330)

2.0-liter Turbo-Diesel Engine (DCT): 150 (330)

2.4-liter V-6 Engine: 100 (220)

2.7-liter V-6 Engine: 100 (220)

(d) All dimensions measured at curb weight with standard tires.

ACCOMMODATIONS

Seating Capacity - F/R

2/3

Total Interior Passenger Volume,

cu. m (cu. m)

2.9 (102.5)

Front

Head Room w/o Sun Roof

1000.1 (39.3)

Head Room w/Sun Roof

946.7 (37.3)

Leg Room

1078 (42.4)

Shoulder Room

1432.9 (56.4)

Hip Room

1357.8 (53.5)

Seat Travel

260 (10.2)

Rear

Head Room

975.6 (38.4)

Leg Room

919.2 (36.1)

Shoulder Room

1431.6 (56.4)

Hip Room

1351.0 (53.2)

Knee Clearance

49.4 (1.9)

Cargo

DIN Trunk Volume, cu. m (cu. ft.)

0.441 (15.57)

BODY/CHASSIS

Layout

Transverse front engine with front-wheel drive

Construction

Steel unibody

SUSPENSION

Front

Independent MacPherson strut, coil spring over gas-charged shock

absorbers, stabilizer bar

Rear

Multi-link independent with coil springs, link-type stabilizer bar,

gas-charged shock absorbers and isolated rear suspension cradle
