Christie DHD700 Manual de usuario

DHD700/DHD800 Lamp/Filter Replacement Instruction Sheet 1 of 4

020-000207-02 Rev. 1 (10-2010)

DHD700/800 Lamp/Filter Replacement

Instruction Sheet

INTRODUCTION

These instructions outline the details for Lamp and Filter replacement in the DHD700 (Model No. 103-

022105-01) and DHD800 (Model No. 103-029102-01) projectors. NOTICE: Use only a Christie

approved Lamp and Filter Kit for your specific projector model.

KITS REQUIRED

DHD700

003-120504-01 (Replacement Lamp)

003-001726-01 (Replacement Air Filter)

DHD800

003-120577-01 (Replacement Lamp)

003-003378-01 (Replacement Air Filter)

INSTRUCTIONS

LAMP REPLACEMENT

When the projection lamp reaches its end of life, the Lamp

Replacement icon appears on the screen and the LAMP 1/2

REPLACE indicator lights orange. Replace the lamp with a

new one promptly. The timing when the LAMP 1/2

REPLACE indicators should light depends on the lamp mode.

NOTES: 1) The Lamp replacement icon will not appear when

the Display function is set to “Off”, or during “Freeze”. 2) It

is recommended that both lamps be changed at the same time

in order to maintain picture quality (better color balance and

brightness). Figure 1 Lamp Replacement Icon

2 of 4 DHD700/DHD800 Lamp/Filter Replacement Instruction Sheet

020-000207-02 Rev. 1 (10-2010)

Always power down and disconnect/disengage all power sources to the

projector before servicing or cleaning.

Allow the projector to cool for at least 45 minutes before the lamp cover is

opened. The inside of the projector can become very hot and may cause injury.

Do Not operate the projector while any of the lamps are removed. This may

result in malfunctions, fire hazard, or other possible accidents.

NOTICES: 1) For continued safety, replace with a lamp assembly of the same type. 2) Do not drop

the lamp assembly or touch a glass bulb! The glass can shatter and may cause injury.

Use the Lamp Status Display to verify which lamp needs to be

replaced.

1. Loosen the lamp cover screw (Figure 1-Top) and lift the

cover.

2. Loosen the 2 screws (Figure 1-Bottom) that attach the

lamp unit to the projector.

3. Use the handles to remove the lamp unit from the

projector (Figure 1-Bottom).

4. Set the new lamp unit into place and tighten the 2 screws

that attach it to the projector.

5. Slide the lamp cover back into place, and tighten the lamp

cover screw.

Figure 2 Lamp Replacement

DHD700/DHD800 Lamp/Filter Replacement Instruction Sheet 3 of 4

020-000207-02 Rev. 1 (10-2010)

REPLACING THE FILTER CARTRIDGE

Always power down and disconnect/disengage all power sources to the

projector before servicing or cleaning.

Allow the projector to cool for at least 45 minutes before the lamp cover is

opened. The inside of the projector can become very hot and may cause injury.

NOTE: To maintain normal internal ventilation replace the filter unit periodically.

1. Use a vacuum cleaner to remove dust on and around the filter

cover (Figure 3-Top-Left).

2. Lift and pull the bottom clips to remove the filter cover

(Figure 3-Top-Right).

3. Pinch and pull the filter clips to remove the filter unit (Figure

3-Bottom-Left).

4. Use a vacuum cleaner to remove dust on and around the

intake vents of the projector (Figure 3-Bottom-Right).

5. Install the new filter unit into the place.

6. Install the filter cover.

NOTICES: 1) Make sure the filter cartridge is correctly inserted

into the projector otherwise, the projector cannot be turned on. 2)

Do not block the air vents. Doing so may result in malfunction of

the projector. 3) When using the projector under dusty or smoky

conditions, dust may accumulate on a lens, liquid crystal panels,

or optical elements inside the projector. Such conditions may

degrade the quality of the projected image. When the symptoms

above are noticed, contact your authorized dealer or service

station for proper cleaning.

Figure 3 Filter Replacement

4 of 4 DHD700/DHD800 Lamp/Filter Replacement Instruction Sheet

020-000207-02 Rev. 1 (10-2010)

RESETTING THE FILTER COUNTER

1. Switch the power button to ON.

2. Press the MENU button to display the On-Screen

Menu. Use the cursor buttons to move the red

frame pointer to the Setting Menu icon (Figure 3).

3. Use the Point buttons to move the red frame

pointer to Filter counter and then press the SELECT

button. A dialog box appears showing the Used time

option and the Scrolls remaining option. Use the Point

buttons to select Used time.

4. Used time shows the total accumulated time of the filter

use, a timer setting option, and the Reset option. Select

Reset and the “Filter counter Reset?” appears. Select

[Yes] to continue.

5. Another confirmation dialog box appears, select [Yes]

to reset the Filter counter.

NOTES: 1) The FILTER TIME value shown on the EASY

menu is the use time since the last time the FILTER TIME

was reset. Refer to the value for proper maintenance. 2) Do

not reset the FILTER TIME without replacing a filter.

RESETTING THE FILTER COUNTER

1. Switch the power button to ON.

2. Press the MENU button to display the On-Screen

Menu. Use the Point buttons to move the red frame

pointer to the Setting Menu icon.

3. Use the Point buttons to move the red frame pointer

to Filter counter and then press the SELECT button. A

dialog box appears showing the Used time option and

the Scrolls remaining option. Use the Point buttons

to select Scroll(s) remaining.

4. Scroll(s) remaining shows the number of the remaining

scrolls and the Reset option. Select Reset and the “Scroll

counter Reset?” appears. Select [Yes] to continue.

5. Another confirmation dialog box appears, select [Yes]

to reset the Scroll counter.

Figure 4 Filter Counter

Figure 5 Scroll Counter
