Chloride Desk Power Plus 1000 Manual de usuario

www.chloridepower.com

This publication is issued to provide outline

information only and is not deemed to form any

part of any offer and contract.The company has a

policy of continuous product development and

improvement, and we therefore reserve the right

to vary any information without prior notice.

Cert No FM 10144

CHLORIDE

POWER PROTECTION

10H52164PUMC

Desk Power Plus

Operating Manual

CHLORIDE

POWER PROTECTION

Uninterruptible Power System

Operating Manual 5

Unterbrechungsfreie Stromversorgung

Benutzer-Handbuch 17

Sistema de Alimentación Ininterrumpida

Manual de usuario 29

Alimentation Sans Interruption

Manuel Utilisateur 41

Gruppo di continuità

Manuale d’uso 53

Sistema de Alimentação Ininterrupta

Manual do Utilizator 65

410H52164PUMC REV. 1/11-2003

OPERATING MANUAL

SAFETY NOTICES 7

SYSTEM DESCRIPTION

1) Front Panel 9

2) Back Panel 9

INSTALLATION AND OPERATION

3) Inspection 10

4) Placement 10

5) Charging 11

6) Computer Connection 11

7) Modem/Phoneline Connection 12

8) Serial Cable Connection 12

9) DC Start Function 13

10) Green Power Function 13

11) Battery Replacement 13

TROUBLE SHOOTING 14

SPECIFICATION 15

10H52164PUMC REV. 1/11-2003

610H52164PUMC REV. 1/11-2003

IMPORTANT SAFETY INSTRUCTION

SAVE THESE INSTRUCTIONS

This manual contains important instructions for models Desk Power Plus 1000,

Desk Power Plus 1400 that should be followed during installation and maintenance

of the UPS and batteries.

Safety Notices

- This UPS uses voltage that may be hazardous. Do not attempt to disassemble the unit.

The unit contains no user replaceable parts. Only factory service personnel may per

form repairs.

- Connection to any other type of receptacle other than a two-pole, three-wire grounded

receptacle may result in shock hazard as well as violate local electrical codes.

- In the event of an emergency, press the OFF button and disconnect the power cord

from the AC power supply to properly disable the UPS.

- Do not allow any liquids or any foreign object to enter the UPS. Do not place beverages

or any other liquid containing vessels on or near the unit.

- This unit intended for installation in a controlled environment (temperature controlled,

indoor area free of conductive contaminants). Avoid installing the UPS in locations

where there is standing or running water, or excessive humidity.

- Do not plug the UPS input into its own output.

- Do not attach a power strip or surge suppressor to the UPS.

- Do not attach non-computer-related items, such as medical equipment, life-support

equipment, microwave ovens or vacuum cleaners to UPS.

- To reduce the risk of overheating the UPS, do not cover the UPS' cooling vents and

avoid exposing the unit to direct sunlight or installing the unit near heat

emitting appliances such as space heater or furnaces.

- Unplug the UPS prior to cleaning and do not use liquid or spray detergent.

- Do not dispose of batteries in a fire as they may explode.

- Do not open or mutilate the battery or batteries. Release electrolyte is harmful to the

skin and eyes. It may be toxic.

- A battery can present a risk of electrical shock and high short circuit current.

The following precautions should be observed when working on batteries:

1) Remove watches, rings, or other metal objects from the hands.

2) Use tools with insulated handles.

3) Do not lay tools or metal parts on top of batteries.

4) Disconnect charging source prior to connecting or disconnecting batteries terminal.

- Servicing of batteries should be performed or surpervised by Personnel knowledgeable

of batteries and the required precautions. Keep unauthorized personnel away from

batteries

- When replacing batteries , replace with the same number and type of sealed

lead-acid battery.

10H52164PUMC REV. 1/11-2003

810H52164PUMC REV. 1/11-2003
