PROJECTOR KIT SELECTION GUIDE

FEBRUARY 2008

Projector Kit Selection Guide

Flat ceilinGS

Kit Mount coluMn ceilinG adaPter acceSSorieS

KITPF006009™

RPAU™, CMS006009™, CMA101™

KITPF012018™

RPAU™, CMS012018™, CMA101™

KITPF018024™

RPAU™, CMS018024™, CMA101™

KITPD003™

RPAU™, CMS003™, CMS115™

KITPD012018™

RPAU™, CMS012018™, CMS115™

KITPD0203™

RPAU™, CMS0203™, CMS115™

KITPD0305™

RPAU™, CMS0305™, CMS115™

6–9”

12–18”

12–24”

3”

12–18”

2–3’

3–5’

order with eaSe

Everything you need to complete your installation – in one simple part number.

Chief®now offers Projector Ceiling Kits, everything you need to

complete an installation in one simple part number. These kits

offer quality products and accessories from the full line, packaged

together in popular conﬁgurations. Chief kits make ordering a

snap, and ensure you have everything you need to complete your

installation fast.

To Order:

1) Determine Ceiling type

2) Choose mount based on need for security

3) Calculate drop distance and choose column length

RPAU™

KITPF006009™

RPAU™, CMS006009™, CMA101™

KITPF012018™

RPAU™, CMS012018™, CMA101™

KITPF018024™

RPAU™, CMS018024™, CMA101™

KITPD003™

RPAU™, CMS003™, CMS115™

KITPD012018™

RPAU™, CMS012018™, CMS115™

KITPD0203™

RPAU™, CMS0203™, CMS115™

KITPD0305™

RPAU™, CMS0305™, CMS115™

6–9”

12–18”

12–24”

3”

12–18”

2–3’

3–5’

SuSPended ceilinGS

KITPS003™

RPAU™, CMS003™, CMS440™

KITPS012C™

RPAU™, CMS012™, CMS440™, CMA170™

KITES003™

RPMU™, CMS003™, CMS440™

KITES003P™

RPMU™, CMS003™, CMS440™, CMA470™

KITQS012C™

RPMAU™, CMS012™, CMS440™, CMA170™

KITLS003™

RPMA1™, CMS003™, CMS440™

KITLS012018P™

RPMA1™, CMS012018™, CMS440™

3”

12”

3”

12”

3”

12–18”

anGled ceilinGS

KITPA018024™

RPAU™, CMS018024™, CMA395™

18–24”

RPMU™

RPMAU™

RPMA1™

end-user focused faster installation superior service proven quality

NOTE: Extension column photos are representative of ﬁxed and adjustable styles and do not accurately depict length.

CHIEF MANUFACTURING n A DIVISION OF MILESTONE AV TECHNOLOGIES n www.chiefmfg.com

USA/INTERNATIONAL nP 800.582.6480/952.894.6280 n F 877.894.6918/952.894.6918 n [email protected]

CHIEF MOUNTS CANADA nP 877.345.4329 n F 888.377.5314 n [email protected]

MILESTONE EUROPE B.V. nP 31 (0)40 2668620n F 31 (0)40 2668615 n [email protected]

MILESTONE ASIA PACIFIC LTD nP 86 755 8996 9226 n F 86 755 8996 9217 n [email protected]

used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations. Other patents pending.

Security cableS

end-user focused faster installation superior service proven quality

NEED ADDITIONAL SECURITY?

Projector GuardS

PMSC™Security Cable Lock

For use with RPA(A/B/C)1 and

RPM(A/B/C)1 Series

HC1™Heavy Duty Cable System SA1™Security Anchor SSC4™Security Screw

Cover Kits

PG1™Series Projector Guards PG2™Series Projector Guards

Chief mounts are supported by a full line of security accessories, ranging from

Basic to Advanced, protecting projectors against theft and damage. Choose the

level of security that best ﬁts the environment of the installation.
