Chicco KeyFit Zip Manual de usuario

PARTS LIST:

A. Infant Insert

B. Headrest

C. Canopy Front

D. Shoulder Pads

E. Crotch Strap Pad

F. Boot Bottom

AB C

D E F

WARNING: Avoid serious injury or death to your child. Never use

your KeyFit car seat without seat padding in place. You must read and

understand the KeyFit Zip Softgoods Removal instructions AND the

instructions in the User Guide. Keep these instructions. Fold instructions

and store with the booklet in the KeyFit Base. If you do not understand

these instructions, DO NOT attempt to remove the Softgoods, STOP and

call Chicco at 1-877-424-4226.

INSTRUCTIONS:KeyFit Zip Softgoods Removal

IMPORTANT: Please also refer to the instructions that came with your product.

TO REMOVE THE SEAT PAD:

Unzip the back Canopy zipper (as shown) and refer to User Guide to remove the Canopy. Remove the Boot

(See Steps 6a-6c). Remove Shoulder Pads (See Step 7). Remove the Crotch Strap Pad (See Step 8).

Remove the Headrest and Newborn Insert.

See Steps 1-5 to ﬁnish removing the Seat Pad.

SHOULDER PADS: To remove the Shoulder

Pads undo the Velcro as shown.

IMPORTANT! If the Crotch Strap Pad prevents the

harness from properly ﬁtting a small Infant, remove

immediately and store for future use.

CROTCH STRAP PAD: Unbuckle the Harness and

remove Crotch Strap Pad by locating the Tab and

pushing it through the Harness Buckle. Pull the Tab out

through the front of the Harness Buckle and remove.

4 1

Fabrics may be spot-cleaned with mild soap and water, or machine washed in cold water on delicate cycle using

mild detergent. Hang to dry. DO NOT BLEACH.

Please consult your product manual for instructions on additional care and maintenance instructions.

CLEANING INSTRUCTIONS:

IS0117.E

Pull out the Tab located on the back of the

Seat Pad.

2Pull Seat Pad away from the Adjuster Cover as

shown.

Pull the side of the Seat Pad up and slide the

Harness Strap behind the Seat Pad at the shoulder and

the waist, repeat for the other Harness Strap.

4Make sure the Harness Straps are completely tucked

behind the back of the Seat Pad and remove the Seat Pad.

Make sure back piece of the Seat Pad is properly

tucked into the softgoods when re-attaching the

Seat Pad.

BOOT: To remove, pull out the Tab located on

the side of Boot. Repeat for other side.

6a Unhook the Velcro on the Tab on both sides of the

car seat as shown.

Remove the boot. Undo the hooks on both sides of the Boot and unzip to remove the top section.

INSTALLATION OF THE KEYFIT ZIP WITHOUT A BASE:

To access the Lap Belt guides unsnap the Seat Pad covering the Lap Belt guide and tuck the padding under the

softgoods, behind the Lap Belt guide as shown. Repeat for the other side.

Refer to page 37 in the KeyFit 30 user guide for installation instructions.

2 3

REMOVING COMPONENTS:

Unhook the elastic band attached around handle

pivot, repeat for the other side.

1a Pull out plastic tabs located on both sides of the

seat pad.
