Chevrolet 2005 Tahoe Instrucciones de montaje

INSIDE YOUR VEHICLE

Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . . .2

Instrument Panel Cluster . . . . . . . . . . . . . . . . . . .3

Heated Front Seats . . . . . . . . . . . . . . . . . . . . . . . .4

Power Lumbar Front Seats . . . . . . . . . . . . . . . . .4

Passenger Automatic Locking Restraint (ALR) .4

Driver and Front Passenger

Safety Belt Reminder . . . . . . . . . . . . . . . . . . . . . .4

Automatic Dimming Rearview Mirror with

OnStar®, Compass and Temperature Display . . .5

Automatic Climate Control System . . . . . . . . . . .5

Manual Climate Control System . . . . . . . . . . . . .6

Rear Climate Control System . . . . . . . . . . . . . . . .6

Entertainment Systems — Radio/CD . . . . . . . . .7

Touch Screen Navigation Entertainment

System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Rear Seat Entertainment System . . . . . . . . . . . . .9

HomeLink®Transmitter . . . . . . . . . . . . . . . . . . . . .9

Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Steering Wheel Controls (OnStar®/Radio) . . . . .10

Adjustable Pedals . . . . . . . . . . . . . . . . . . . . . . . .11

Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . .11

OUTSIDE YOUR VEHICLE

Power Folding Mirrors . . . . . . . . . . . . . . . . . . . .12

Power Camper-Type Mirrors . . . . . . . . . . . . . . .12

Automatic Headlamp Controls . . . . . . . . . . . . . .12

Content Theft-Deterrent System . . . . . . . . . . . .13

Daytime Running Lamps (DRL) . . . . . . . . . . . . .13

Tire Pressure Monitor . . . . . . . . . . . . . . . . . . . . .13

PERSONALIZING YOUR VEHICLE

Memory Positions for Driver’s Seat,

Mirrors and Power Adjustable Pedals . . . . . . . .14

Memory Settings for Your Vehicle . . . . . . . . . . .15

Odometer/Trip Settings . . . . . . . . . . . . . . . . . . . .16

Fuel Information . . . . . . . . . . . . . . . . . . . . . . . . .17

VEHICLE SYMBOLS GLOSSARY . . . . . . . . . . . . . . . .18

ROADSIDE ASSISTANCE, My GMLink . . . . . . . . . . .20

Congratulations on your purchase of a Chevrolet Tahoe or Suburban. Please read this information

and your

Owner Manual to ensure an outstanding ownership experience. Note that your vehicle may not include all the

features described in this booklet. Place this booklet in your Owner Manual portfolio for easy reference.

Getting to Know Your Tahoe/Suburban

Instrument Panel

See Section 3 of your Owner Manual.

A. Dome Lamp Override Button

B. Lamp Controls

C. Air Outlets

D. Automatic Transfer Case/

StabiliTrak®Mode Button (AWD

Vehicles)/Traction Assist System

(TAS)

E. Turn Signal/Multifunction Lever

F. Instrument Panel Cluster

G.Shift Lever

H. Tow/Haul Selector Button

I. Audio System

J. Comfort Control System

K. Instrument Panel Fuse Block

L. Hood Release

M.Steering Wheel Control Buttons

(if equipped)

N. Center Instrument Panel Utility Block

O.Tilt Wheel Lever

P. Parking Brake Release

Q.Lighter and Accessory Power Outlet

R. Storage Area (if equipped)

S. Ashtray

T. Traction Control Switch (if equipped)

U. Glove Box

See Section 3 of your Owner Manual.

Instrument Panel Cluster

Your vehicle’s instrument panel is

equipped with this cluster or one

very similar to it. (The U.S. Heavy-

Duty Transmission version is shown

here.)

The instrument panel cluster includes

these key features:

A. Transmission Temperature Gauge

(if equipped)

B. Tachometer

C. Speedometer and Transmission

Gear Selector

D. Oil Pressure Gauge

E. Fuel Gauge

F. Voltmeter

G.Engine Coolant Temperature

Gauge

H. Driver Information Center (DIC)

and Odometer

IMPORTANT: See Section 3 of

your Owner Manual for more infor-

mation about what the lights, gauges

and indicators on your vehicle’s

instrument panel tell you about your

vehicle’s operation.

CDE

Getting to Know Your Tahoe/Suburban

Heated Front Seats (if equipped)

This feature allows you to heat the front

seatbacks and seat cushions simultane-

ously or just the seatbacks. The controls

are located on the driver and front pas-

senger door panels.

Select a heat setting for both the

seatback and seat cushion

• Press and release the horizontal but-

ton (“A” above) until the indicator light

shows the desired setting.

Select a heat setting for the seatback

only

• Press and release the vertical button

(“B” above) until the indicator light

shows the desired setting.

See Section 1 of your Owner Manual.

Adjust lumbar

support

• Press the front

or rear of the

control located

on the side of

the seat cush-

ion near the door. Release at the pre-

ferred setting.

Passenger Automatic Locking

Restraint (ALR)

The safety belt is designed to lock dur-

ing an accident, but it will also lock if it is

pulled out all the way during initial buck-

ling, and you may be unaware that this

has happened. If the safety belt does

lock, unbuckle it and allow it to retract

fully, then pull it out and re-buckle the

belt.

See Section 1 of your Owner Manual.

Power Lumbar Front Seats

(if equipped)

Driver and Front Passenger

Safety Belt Reminder

(if equipped)

Adjust outer portion of lumbar seat-

back area

• Press the top or bottom of the lumbar

control. Release at the preferred

setting.

See Section 1 of your Owner Manual.

A chime will sound and the safety belt

light ( ) will be illuminated and flash

for several seconds when the ignition

key is turned to Run or Start, or at

any time the vehicle is running, and the

driver’s safety belt is not buckled.

If your vehicle is equipped with the pas-

senger sensing system, the chime will

sound and a message will be displayed

on the Driver Information Center for

several seconds if the passenger’s

safety belt is not buckled under the

same conditions.

See Section 3 of your Owner Manual.

Automatic Dimming Rearview

Mirror with OnStar®, Compass

and Temperature Display

(if equipped)

Controls for the dimming feature, as well

as OnStar®(if equipped) and the com-

pass and temperature displays, are

located on the bottom of the mirror.

When on, the automatic interior dimming

rearview mirror automatically dims to the

proper level to minimize glare from lights

behind you when it’s dark outside.

Turn the self-dimming function

on or off

• Press and hold for approximately

eight seconds.

Use the OnStar system

• Press to connect to an OnStar®

Advisor.

• Press or (depending on vehi-

cle equipment) to answer or end a

call from the OnStar®Center or

Personal Calling.

•Press in an emergency to connect

to an OnStar®Advisor who can con-

tact the nearest emergency services

provider.

Automatic Climate Control

System (if equipped)

Adjust settings for automatic

operation

• Push the AUTO button (“A” above)

and adjust the temperature knob (“B”

above) to the desired temperature.

When automatic operation is active,

the system will control the inside

temperature, air delivery, air inlet and

fan speed.

Set same temperature for driver and

front passenger

• Press and hold the AUTO button for

four seconds.

•Turn the passenger-side temperature

knob to select a different temperature

for the passenger.

Turn the outside temperature displays

and compass readings on or off

• Press .

Display temperature

• Press and hold for four seconds

(until the display blinks) to toggle

between °C and °F. Once the desired

°C or °F is displayed, release the

button. Wait four seconds and the

temperature will be displayed.

See Section 2 of your Owner Manual.

Getting to Know Your Tahoe/Suburban

Manual Climate Control System

(if equipped)

Rear Climate Control System

(if equipped)

With this system, the front or rear

passengers can control the air tempera-

Adjust settings for operation

• Adjust air delivery location with mode

control knob (“A” above).

Select air distribution manually

• Press and release the MODE

button (“C” previous page) until the

desired source of air is indicated on

the display.

The MODE feature allows you to select

air delivery to the floor, the instrument

panel outlets, or the windshield outlets.

Manually raise or lower fan speed

•

Press the upper or lower portion of the

FAN control button (“D” previous page).

Additional Climate Control System

Functions

:Recirculates interior air while in

Vent, Bi-Level positions. Use this setting

to get maximum cooling from the air

conditioning system. To prevent

window fogging, Recirculation will not

operate in the Defog, Defrost or Floor

mode.

:Clears windshield and front side

windows of fog/frost.

:Clears rear glass of fog/frost and

activates heated outside rearview mir-

rors (if equipped).

See Section 3 of your Owner Manual.

• Adjust driver/passenger temperatures

with levers (“B” left).

• Set fan speed to desired setting

(“C” left).

Additional Climate Control System

Functions

:Recirculates interior air while in

Vent, Bi-Level positions. Use this setting

to get maximum cooling from the air

conditioning system. To prevent

window fogging, Recirculation will not

operate in the Defog, Defrost or Floor

mode.

:Clears windshield and front side

windows of fog/frost.

:Clears rear glass of fog/frost and

activates heated outside rearview mir-

rors (if equipped).

:Turns the air conditioning

system on and off. The button’s LED

will illuminate when the air conditioning

system is on.

See Section 3 of your Owner Manual.

Note: When the climate control system

is in the OFF position ( ), outside air

will continue to enter the vehicle and will

be directed according to the mode

position selected. This is normal climate

control operation.

Entertainment Systems —

Radio/CD

Set the time on

radios without a

Radio Data

System (RDS)

• Press and hold

the HR or MIN

arrow for two

seconds.

• Press the HR (down) arrow until the

correct hour appears on the display.

• Press and hold the MIN (up) arrow

until the correct minute appears on

the display.

Set the time on radios with a Radio

Data System (RDS)

Your radio may have a button marked

“H” or “HR” to represent hours and an

“M” or “MIN” to represent minutes.

• Press and hold the hour button until

the correct hour appears on the

display.

• Press and hold the minute button

until the correct minute appears on

the display.

Program radio station presets

• Turn the radio on.

• Press BAND to select the band

(AM, FM1/FM2/XM1/XM2).

• Use the seek or tune knob to tune in

the desired station.

• Press AUTO EQ or AUTO TONE (as

applicable to your radio) to select the

equalization that best suits the type of

station selected.

• Press and hold one of the six num-

bered buttons until a beep sounds;

release the button.

• Repeat these steps for each station

preset, using a different numbered

button for each station.

Access one of the two available XM

Satellite Radio bands (if equipped)

• Press the BAND button until XM1 or

XM2 appears on the display. (Note:

Requires subscription to XM Radio.)

Note: The time may be set with the

ignition on or off.

ture, airflow and fan speed for the rear

seat passengers.

To operate the rear climate control sys-

tem from the front seat position, use the

driver overhead controls (shown above).

To use the rear seat controls, the front

fan control knob must be in the AUX

position.

On the rear seat control panel, press the

mode button ( ) and select AUTO if

you want the system to regulate airflow.

Rear Air Conditioning Only Systems

Rear air conditioning only systems have

two fan speed selectors: one in the

overhead console and the other in the

second row seat headliner. To use the

rear seat controls, the front control must

be in the AUX position.

See Section 3 of your Owner Manual.

Getting to Know Your Tahoe/Suburban

Touch Screen Navigation

Entertainment System

(if equipped)

Your vehicle’s Navigation Entertainment

System provides you with detailed maps

of all major highways and roads

throughout the United States. After you

enter a destination, the system provides

turn-by-turn instructions for reaching

your destination. In addition, the system

can help you locate banks, airports,

restaurants, post offices, ATMs and

more.

See your Owner Manual or Navigation

Entertainment System Quick Reference

Guide for operating instructions.

See Section 3 of your Owner Manual.

• When loading more than one but

fewer than six CDs, press the LOAD

button again to signal that loading is

complete.

• When more than one disc is loaded,

a number for each disc is displayed.

• To play a specific CD, press the CD

AUX button and then the number of

the CD you want to hear.

• A small bar appears under the CD

number that is playing, and the track

number appears.

See Section 3 of your Owner Manual.

Six-Disc CD Changer (if equipped)

Load 1 CD

• With the ignition on, press and

release the LOAD side of the LOAD

CD button.

• Wait for the green indicator light at

the right side of the slot to turn green.

• Insert the disc partway into the slot,

label side up; the player will pull the

disc in.

Load multiple CDs

• With the ignition on, press and hold

the LOAD button for two seconds.

The unit beeps and the light to the

right of the slot begins to flash.

• When the light stops flashing and

turns green, insert a disc partway,

label side up.

• The indicator light will begin blinking

and turn steadily green. Load another

disc at this time.

HomeLink®Transmitter

(if equipped)

Rear Seat Entertainment System

(if equipped)

Program HomeLink

1. Determine which of the three chan-

nels (buttons) you want to program:

garage door opener, gate opener,

entry door locks or other.

2. Press and hold the desired HomeLink

button through step 3.

3. When the HomeLink light blinks

slowly (within 30 seconds), hold your

transmitter/opener 1" to 3" away from

the HomeLink buttons. Then hold

your transmitter button on until the

HomeLink light flashes rapidly (up to

90 seconds). The process is now

complete.

See Section 2 of your Owner Manual.

The DVD Rear Seat Entertainment

(RSE) system includes a DVD player

and a video display screen, located in

the overhead console, two sets of wire-

less headphones and a remote control.

To play a DVD:

• The ignition must be in the Run or

Accessory position, or RAP (Retained

Accessory Power, available after the

ignition is turned off) must be active.

• Push forward on the release latch to

fold down the video screen.

• Insert a DVD into the loading slot;

it will automatically start.

• If a DVD is already loaded, press the

Play/Pause button.

• Press the CD/AUX button on the

radio until RSE appears on the radio

display to listen to the DVD through

your vehicle speakers.

• When using the wireless head-

phones, turn the headphones on and

adjust the volume using the volume

knob.

To stop or eject a DVD:

• To stop playing a DVD, press the

Stop button. Press the Play button to

resume viewing. If the Stop button is

pressed twice, the DVD will resume

viewing at the beginning.

• To eject a DVD, press the Eject but-

ton on the DVD player.

See Section 3 of your Owner Manual.

Note: If your transmitter has a “rolling

code” feature, the above process may

not work. Please refer to your Owner

Manual or contact HomeLink at

1-800-355-3515 (www.homelink.com).

Getting to Know Your Tahoe/Suburban

Steering Wheel Controls

(OnStar®/Radio) (if equipped)

(OnStar/Voice Recognition)

(if equipped): This button will activate

OnStar®for use. (Note: If your vehicle is

not equipped with the OnStar® system,

pressing this button will mute the radio.

For additional OnStar®features informa-

tion, including Personal Calling and

Virtual Advisor, see the OnStar®section

of your Owner Manual.)

PROG: This button will cycle through

the radio presets.

:Selects AM, FM, XM Satellite

Radio (if equipped), cassette or CD

:Seeks radio stations

:Adjusts radio volume

See Sections 2 and 3 of your Owner Manual.

Sunroof (if equipped)

The sunroof controls are located in the

overhead console.

Open sunroof to fully opened position

• Press the rear portion of the button

(“A”).

Close the sunroof

• Hold the front portion of the button

(“B”) down until the sunroof motor

stops. The sunroof will tilt up slightly

to seal. This is normal.

Open sunroof to vent position

• Press and hold the front portion of the

button (“B”) when the sunroof is

closed.

See Section 2 of your Owner Manual.

Otros manuales para 2005 Tahoe

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Automóvil de Chevrolet

Chevrolet

Chevrolet Corvette 2016 Manual de usuario

Chevrolet

Chevrolet Kodiak 2006 Manual de usuario

Chevrolet

Chevrolet TAHOE POLICE - 2011 Manual de usuario

Chevrolet

Chevrolet Bolt EV 2022 Manual de usuario

Chevrolet

Chevrolet 2012 Equinox Manual de usuario

Chevrolet

Chevrolet Malibu 2020 Instrucciones de montaje

Chevrolet

Chevrolet CAMARO 1979 Manual de usuario

Chevrolet

Chevrolet 2004 TrailBlazer Manual de usuario

Chevrolet

Chevrolet Corvette 2015 Manual de usuario

Chevrolet

Chevrolet 2010 Malibu Manual de usuario

Chevrolet

Chevrolet 2014 SPARK LS Manual de usuario

Chevrolet

Chevrolet 2014 SPARK LS Manual de usuario

Chevrolet

Chevrolet 2005 Uplander Manual de usuario

Chevrolet

Chevrolet 2011 Aveo Manual de usuario

Chevrolet

Chevrolet 2015 Silverado Manual de usuario

Chevrolet

Chevrolet Camaro 1978 Manual de usuario

Chevrolet

Chevrolet 2013 SONIC Manual de usuario

Chevrolet

Chevrolet VOLT 2012 Manual del propietario

Chevrolet

Chevrolet Pontiac Pursuit 2005 Manual de usuario

Chevrolet

Chevrolet 1978 corvette Manual de programación

Chevrolet

Chevrolet Bolt EUV 2022 Manual de usuario

Chevrolet

Chevrolet 2003 Avalanche Manual de usuario

Chevrolet

Chevrolet 2011 Camaro Manual de usuario

Chevrolet

Chevrolet 1970 Manual de usuario

Manuales populares de Automóvil de otras marcas

Toyota

Toyota 2000 Tundra Manual de usuario

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Cadillac

Cadillac CTS 2008 Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario

Skoda

Skoda FABIA RS - ANNEXE 118 Manual de usuario
