CHEFOOK LADY 900 Manual de usuario

USE AND MAINTENANCE MANUAL

Translation of the original instructions in Italian

LAVA STONE GRILL

LADY 900

UM500013 - 06/2018

1001

2LAVA STONE GRILL - LADY 900

UM500013 - 06/2018

Dear Customer,

thank you for choosing us. We are certain that this appliance will satisfy your needs and

live up to your expectations.

We kindly ask you to read this Use and Maintenance Manual carefully in order to be able

to use the appliance to its full potential. For any further information regarding use and

maintenance, please do not hesitate to contact us. We will be delighted to answer any

questions you may have.

Introduction

Warning on the ownership of information

-In order to foster its policy of continual development and updating of the product, the Manufacturer

reserves the right to make any modications necessary to improve its basic features without having to

give notice and without being under any obligation to do so. If the modications do not change any safety

aspects, the Manufacturer is not obliged to give notice of them in this document attached to the appliance.

-The Manufacturer also reserves ownership of this document and strictly forbids its reproduction or

disclosure to third parties without prior authorization.

-Any illustrations or drawings in this document are merely simplied representations of the appliance; on

the basis of any improvements and modications made, they may not correspond to the actual appliance.

Updating procedure

-Updating and/or drafting of a new version of the above-mentioned document will only be carried out if the

functional or safety aspects of the appliance are modied.

Original version

-This document was originally issued in Italian. In the event of any controversy arising due to the translation

of the same, even if carried out by the Manufacturer, the reference text will be the Italian version alone.

- Reproduction of this document, either in total or in part, is forbidden without prior written consent by the Manufacturer, who reserves the right to modify it without any obligation

to give notice, unless this represents a safety risk.

- Drafted by: VEGA srl

LAVA STONE GRILL - LADY 900

UM500013 - 06/2018

1 General information..............................................5

1-1 Purpose and description of the manual ...........................................6

1-2 Correct manual storage .......................................................7

1-3 Identication data ............................................................8

1-4 Requests for assistance.......................................................10

2 Technical information ........................................... 11

2-1 General description of the appliance .............................................12

3 Safety information .............................................. 15

3-1 Safety .....................................................................16

4 Information for correct use....................................... 19

4-1 First use ...................................................................20

4-2 Complete map of the controls ..................................................20

4-3 Burner start and turning off.....................................................21

4-4 Recommendations for use .....................................................22

4-5 What to do in the event of long periods of inactivity..................................22

5 Maintenance information ........................................ 23

5-1 Maintenance recommendations .................................................24

5-2 Ordinary cleaning ............................................................24

5-3 Useful tips for stainless steel care ...............................................26

5-4 Troubleshooting .............................................................28

6 Instructions for qualied tters ................................... 29

6-1 General information ..........................................................30

6-2 Storage....................................................................30

6-3 Packaging..................................................................30

6-4 Technical specications .......................................................31

6-5 Positioning and installation.....................................................36

6-6 Gas Connection .............................................................40

6-7 Inspection and start-up........................................................41

6-8 Adjustments ................................................................44

6-9 Adjustment for operation with different gases ......................................45

6-10 Maintenance to be carried out by a tter or qualied technician ........................47

7 Tables and annexes............................................. 49

4LAVA STONE GRILL - LADY 900

UM500013 - 06/2018

This page intentionally left blank

LAVA STONE GRILL - LADY 900

General information

UM500013 - 06/2018

1 GENERAL INFORMATION

6LAVA STONE GRILL - LADY 900

General information

UM500013 - 06/2018

1-1 Purpose and description of the manual

This manual is an integral part of the appliance and aims to provide all the information necessary to:

- make operators fully aware of any safety issues;

- guarantee correct installation;

- ensure full understanding of its operating principles and correct, safe use;

- carry out any maintenance correctly and safely;

- dispose of the appliance safely and in compliance with applicable legislation concerning health and

safety and environmental protection.

Correct operation of the appliance is guaranteed only if these regulations are complied with.

The Manufacturer declines any responsibility for: damage resulting from poor maintenance, incorrect use,

tampering with or any use which does not comply with the terms and conditions indicated in this manual.

The Manufacturer reserves the right to modify any drawings, texts and technical specications without prior

notice or responsibility and without any obligation to update this manual each time.

In the event of problems in understanding this manual, please contact the Manufacturer.

This manual is divided into the following sections:

- Section 1contains information regarding consultation of this manual and the data necessary to correctly

identify the manufacturer and appliance.

- Section 2contains general information, essential for knowing all about the appliance and its main parts,

its permitted uses, its technical specications, etc.

- Section 3is dedicated to user safety.

- Section 4addresses the user and contains instructions for correct use of the appliance.

- Section 5contains information about maintenance, describing operations the user needs to carry out and

those which must be carried out by a tter or authorized technician. It also contains a chapter dedicated

to troubleshooting, identifying the cause of problems and possible solutions.

- Section 6 is intended for qualied tters and concerns correct installation of the appliance.

- Section 7, if present, contains tables and annexes.

LAVA STONE GRILL - LADY 900

General information

UM500013 - 06/2018

1.1.1 Symbol used

During machine use, it is possible to face situations for which special considerations and adequate close

examinations are needed.

The following "graphic safety symbols" are used in this manual. They aim to highlight risks or important

information:

DANGER

Draws attention to actions which, if not correctly carried out, may cause serious injury or death

or may be a health risk for people and the environment.

WARNING

Draws attention to operations, procedures or actions which, if not carefully carried out, may

cause serious damage to the appliance or product.

IMPORTANT

Draws attention to technical information or practical recommendations that ensure efcient and

economical use of the appliance. Failure to comply with this information may void the warranty.

1.1.2 Abbreviations used

Ref. Description

Ann. Annex

Chap. Chapter

Fig. Figure

Max. Maximum

Min. Minimum

Mod. Model

Page Page

Par. Paragraph

Ref. Reference

Tab. Table

U.m. Units of measurement

Tab. 1 Abbreviations used

1-2 Correct manual storage

This manual must be handled with care and clean hands and it should never be placed on dirty surfaces. It

should be stored in a cool, dry place.

No part of the manual should be removed, torn out or arbitrarily changed.

DANGER

This manual is an integral part of the appliance and must be kept until nal disposal of the same.

8LAVA STONE GRILL - LADY 900

General information

UM500013 - 06/2018

1-3 Identication data

Check that the instruction manual corresponds to the appliance being referred to.

In the event of any request for information or technical assistance, it will be necessary to specify the model

and type of appliance, as well as its serial number.

1.3.1 Appliance type and model

The appliance type and model are indicated on the identication plate.

LAVA STONE GRILL - LADY 900

General information

UM500013 - 06/2018

1.3.3 Identication plate

The identication plate shown is applied directly to the appliance.

It includes all appliance and manufacturer identication data and the CE mark of conformity.

Mod:

Art:

Nr:

Tipo/Type

E QnkW

m3/h

kg/h

CAT. G2.350

Pmbar

m3/h

Kg/h

Pmbar

m3/h

Kg/h

Pmbar

m3/h

Kg/h

G20 G30 G31 G110

PREPARED FOR GAS:

Fig. 1 Identication plate

Fig. 2 Plate position

1.3.4 Identication plates of the main components

The plates of all the commercial components not produced by the Manufacturer are applied directly to the

relevant components, where their respective manufacturers originally placed them.

1.3.5 CE mark of conformity

The CE mark applied on the identication plate conrms that the appliance complies with the safety

requirements specied in the following directives:

Directive 2009/142/UE (Gas appliances)

Directive 2014/35/EU (Low voltage)

Directive 2014/30/EU (Electromagnetic compatibility)

Regulation 2004/1935/EC (Materials intended to come into contact with food)

1001

10 LAVA STONE GRILL - LADY 900

General information

UM500013 - 06/2018

1-4 Requests for assistance

- As stated in the sales terms and conditions, the appliance is covered by a warranty. If during the validity

period of the same any faults or breakages covered by the warranty should occur, the Manufacturer will

repair or replace faulty parts after carrying out the necessary checks.

- Any modications carried out by the user without express written authorization by the Manufacturer shall

void the warranty and relieve the Manufacturer of any responsibility for damage caused by the faulty

appliance. This also applies when non-original spare parts are used.

- For all of the above reasons, in the event of an emergency, we recommend contacting the Manufacturer's

Technical Assistance Department directly.

IMPORTANT

For any type of service request it is necessary to specify the data on the identication plate and

the type of fault.
