Checkpoint QUANTUM SMART-1 Manual de usuario

[Classification: Protected]

13 April 2021

QUANTUM SMART-1

600-M/6000-L/6000-XL

APPLIANCES

REPLACING LINE CARDS

Check Point Copyright Notice

under licensing restricting their use, copying, distribution, and decompilation. No part of this product or

related documentation may be reproduced in any form or by any means without prior written authorization

of Check Point. While every precaution has been taken in the preparation of this book, Check Point

assumes no responsibility for errors or omissions. This publication and features described herein are

subject to change without notice.

RESTRICTED RIGHTS LEGEND:

Use, duplication, or disclosure by the government is subject to restrictions as set forth in subparagraph (c)

(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 and FAR

52.227-19.

TRADEMARKS:

Refer to the Copyright page for a list of our trademarks.

Refer to the Third Party copyright notices for a list of relevant copyrights and third-party licenses.

Important Information

Latest Software

We recommend that you install the most recent software release to stay up-to-date with the

latest functional improvements, stability fixes, security enhancements and protection

against new and evolving attacks.

Certifications

For third party independent certification of Check Point products, see the Check Point

Certifications page.

Check Point Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing

Line Cards

For more about this release, see the home page.

Latest Version of this Document in English

Download the latest version of this document in PDF format.

Feedback

Check Point is engaged in a continuous effort to improve its documentation.

Please help us by sending your comments.

Revision History

Date Description

13 April 2021 Updated with Smart-1 600-M models

28 February 2021 First release of this document for Smart-1 6000-L/6000-XL models

Table of Contents

Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|4

Table of Contents

Safety Instructions

Hardware Components

Supported Expansion Line Cards

Procedure for Smart-1 600-M Appliances

Preparing the Appliance

Removing the Riser

Removing an Expansion Line Card from the Riser

Installing an Expansion Line Card into the Riser

Installing the Riser

Reassembling the Appliance

Procedure for Smart-1 6000-L/6000-XL Appliances

Preparing the Appliance

Installing an Expansion Line Card into the Riser

Removing an Expansion Line Card from the Riser

Reassembling the Appliance

Replacing a Transceiver

Safety Instructions

Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|5

Safety Instructions

nLift the appliance with assistance. To avoid injury, do not attempt to lift the appliance by yourself.

nOpening or removing the appliance cover, while the appliance is powered on may expose you to a

risk of electric shock.

nDo not operate the appliance without the cover for more than five minutes. Operating the appliance

without the cover can result in component damage.

nMany repairs may only be done by a certified service technician. Only perform troubleshooting and

simple repairs as authorized in your product documentation, or as directed by the technical support.

nWe recommend that you always use an antistatic mat and antistatic strap on your wrist, while

working on components inside the appliance.

nTo ensure proper operation and cooling, all bays in the appliance and cooling fans must be always

populated with a component or a blank.

For more information, see the

Enterprise Products Safety, Environmental, and Regulatory Information

booklet supplied in the original appliance shipping carton.

Best Practice - We recommend that only experienced personnel install or remove

hardware components. Installing or removing components incorrectly can

permanently damage the Security Management Appliance.

Important - Make sure that you are electromagnetically grounded when working with

hardware components of the appliance. ESD (electrostatic discharge) can damage the

appliance.

Hardware Components

Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|6

Hardware Components

Smart-1 600-M

Item Description

1 Front panel

2 Riser

3 Rear panel

Hardware Components

Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|7

Smart-1 6000-L/6000-XL

Item Description

1 Front panel

2 Riser 1

3 Rear panel

Supported Expansion Line Cards

Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|8

Supported Expansion Line Cards

An expansion line card is an add-on card that can be inserted into an expansion slot on riser card to add

enhanced functionality to the appliance through the expansion bus.

These expansion line cards are available for the Smart-1 600-M and Smart-1 6000-L/6000-XL models:

n1 Gb Ethernet

n10 Gb Ethernet

In the Smart-1 600-M appliance, there is 1 available expansion line card slot.

In the Smart-1 6000-L/6000-XL appliances, there are 3 available expansion line card slots.

For a list of supported line cards, see:

https://www.checkpoint.com/downloads/products/smart-1-security-management-platform-datasheet.pdf

Important - On Smart-1 6000-L/6000-XL appliances, do not move the RAID Controller

from the right-most slot to any other slot.

Procedure for Smart-1 600-M Appliances

Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|9

Procedure for Smart-1 600-M Appliances

Use the relevant install or replace workflow for your appliance. For each step in the workflow, follow the

instructions as described in the subsequent sections of this guide.

To install a new expansion line card :

1. Prepare the appliance.

2. Remove the riser.

3. Install a new expansion line card into the riser.

4. Install the riser.

5. Reassemble the appliance.

6. Install a transceiver.

To replace an existing expansion line card:

1. Prepare the appliance.

2. Remove the riser.

3. Remove the existing expansion line card from the riser.

4. Install a new expansion line card into the riser.

5. Install the riser.

6. Reassemble the appliance.

7. Install a transceiver.

Preparing the Appliance

1. Make sure to follow the

"Safety Instructions" on page5

2. Shut down the appliance:

nIn Gaia Portal:

Go to Maintenance >Shut Down, and click Halt.

nIn Gaia Clish:

Run:

halt

3. Open the retention strap that secures the power cables to the PSUs.

4. Disconnect the power cables from the AC PSUs.

5. Remove the hook-and-loop straps that hold and secure the system cables, if they interfere with the

PSU removal.

6. Remove the appliance from the rack.

See the

Installing the Quantum Smart-1 600-M Telescopic Rails

guide.

Procedure for Smart-1 600-M Appliances

Quantum Smart-1 600-M/6000-L/6000-XL Appliances Replacing Line Cards|10

7. Put the Electrostatic Discharge (ESD) grounding strap on your wrist and attach the other end to a

grounding point.

8. Remove the appliance cover:

a. Use a 1/4 inch flat head or a Phillips #2 screwdriver to turn the lock counter clockwise to the

unlocked position (1).

b. Open the release latch until the system cover slides back (2).

c. Lift the cover from the system (3).

Removing the Riser

1. Open the blue expansion card riser retention latch located on the appliance (1).

2. Holding the blue touch points (2), lift the expansion card riser from the appliance.

Note - The illustration shows a riser with only the onboard NIC installed.
