Chauvet FXarray Q5 Manual de usuario

Quick Reference Guide

FXArray Q5

QUICK REFERENCE GUIDE

FXArray Q5 QRG Rev. 1

About This Guide

The FXArray Q5 Quick Reference Guide (QRG) has basic product information such as mounting, menu options, and

DMX values. Download the User Manual from www.chauvetdj.com for more details.

Disclaimer

The information and specifications contained in this QRG are subject to change without notice.

Safety Notes

These Safety Notes include important information about installation, use, and maintenance.

Contact

Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux, contact your distributor to request support or return a

product. Visit www.chauvetdj.com for contact information.

What is Included

• FXArray Q5

• Power Cord

• Warranty Card

• Quick Reference Guide

To Begin

Unpack your FXArray Q5 and make sure you have received all parts in good condition. If the box or contents appear

damaged, notify the carrier immediately, not Chauvet.

• This product is not intended for permanent installation.

• ONLY connect this product to a grounded and protected circuit.

• DISCONNECT from power before cleaning or replacing the fuse.

• DO NOT look at the light source when the product is on.

• Make sure the power cord is not crimped or damaged.

• Never disconnect this product from power by pulling on the cord.

• When mounting this product overhead, ALWAYS use a safety cable.

• DO NOT allow flammable materials close to the product when it is operating.

• DO NOT touch the product’s housing when it is on because it will be hot.

• The voltage of the outlet to which you are connecting this product must be within the range stated

on the decal or rear panel of the product.

• This product is for indoor use only! (IP20) To prevent risk of fire or shock, do not expose this

product to rain or moisture.

• Always mount this product in a location with adequate ventilation, at least 20 in (50 cm) from

adjacent surfaces.

• Be sure that no ventilation slots on the unit’s housing are blocked.

• Never connect this product to a dimmer or rheostat.

• Replace the fuse with the same type and rating.

• Never carry the product by the power cord. Use only the handle to carry this product.

• The maximum ambient temperature is 104 °F (40 °C). Do not operate this product at higher

temperatures.

• In the event of a serious operating problem, stop using immediately.

• DO NOT open this product. It contains no user-serviceable parts.

• To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely

disconnect the product from power via breaker or by unplugging it.

FXArray Q5 QRG Rev. 1

QUICK REFERENCE GUIDE

Product Description

The FXArray Q5 is a versatile quad-color LED wash light, that features brilliant SMD eye candy effects. Powered by five

quad-color LEDs, this fixture blankets the entire room in an array of RGB+UV effects and can emit up to 3 different colors

simultaneously. Create customized looks in stand-alone mode without the need for DMX control using the digital display,

automated or sound-active programs. IRC-6 sold separately.

Overview

Power In /

Fuse Holder

DMX

Out

Digital

Display

Power Out

DMX In

Manual sound

Sensitivity Knob

Buttons

Fan Safety

Loop

Microphone

QUICK REFERENCE GUIDE

FXArray Q5 QRG Rev. 1

AC Power

This product has an auto-ranging power supply that works with an input voltage range of 100 to 240 VAC, 50/60 Hz.

Power Linking

For the maximum number of FXArray Q5 products that you can power link at each voltage, see the User Manual or the

specification sticker on the product.

Fuse Replacement

1. Disconnect the product from power.

2. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.

3. Pry the safety cap out of the housing.

4. Remove the blown fuse from the clip on the front of the safety cap and replace with a fuse of the exact same

type and rating.

5. Re-insert the fuse holder and reconnect power.

Mounting

Before mounting this product, read the Safety Notes.

Mounting Diagram

To eliminate wear and improve its lifespan, during periods of non-use completely disconnect the

product from power via breaker or by unplugging it.

Safety Cable

(such as CH-05 from

Chauvet)

Mounting Clamp

(such as CLP-15 from Chauvet)

Mounting Bracket

(Included)

Chauvet does not recommend

floor mounting this product

FXArray Q5 QRG Rev. 1

QUICK REFERENCE GUIDE

Control Panel Description

Menu Map

BUTTON FUNCTION

<MENU> Exits from the current menu or function

<UP> Navigates upwards through the menu list and increases the numeric value when in a function

<DOWN> Navigates downwards through the menu list and decreases the numeric value when in a function

<ENTER> Enables the currently displayed menu or sets the currently selected value into the selected

function

MODE PROGRAMMING LEVELS DESCRIPTION

DMX Mode 3Ch d001–510 3-channel DMX mode

10Ch d001–503 10-channel DMX mode

30CH d001–483 30-channel DMX mode

Static Colors C-- C001–022 Static colors

Automatic

Programs P-- P 1–7 Automatic programs

Auto Speed S-- S001–100 Program speed for P 1–7

Dimmer DIN L001–255 Adjust the dimmer on auto and sound programs (P1-5)

Sound-Active

Mode Snd Snd1–5 Sound-active programs

Custom Color

Mixing u--

r000–255 Custom static colors

Combine red, green, blue, and white

Note: Only three can be used at once

g000–255

b000–255

u000–255

S000–100 SMD strobe speed

Infrared Mode SEt on Turns infrared on or off

oFF

QUICK REFERENCE GUIDE

FXArray Q5 QRG Rev. 1

DMX Linking

The FXArray Q5 can work with a DMX controller. Instructions for connecting and configuring this product for DMX

operation are in the User Manual. If you are not familiar with DMX, download the DMX Primer from www.chauvetdj.com.

Starting Address

To ensure full access to all channels available in each DMX mode, the highest recommended DMX address is 483.

Master/Slave Connection

The FXArray Q5 uses the DMX data connection for its Master/Slave mode. Information about configuring the FXArray Q5

for Master/Slave operation is in the User Manual, which is available from the Chauvet website.

IRC-6 (Infrared Remote Control)

The FXArray Q5 can be operated with the CHAUVET IRC-6. For more information about the IRC-6, download

instructions for the IRC-6 or the FXArray Q5 User Manual from www.chauvetdj.com.

DMX Values

30Ch

CHANNEL FUNCTION VALUE PERCENT/SETTING

1 Auto and Sound Active Programs

000 005 Blackout

006 040 Program 1 / Sound 1

041 075 Program 2 / Sound 2

076 110 Program 3 / Sound 3

111 145 Program 4 / Sound 4

146 180 Program 5 / Sound 5

181 215 Program 6 / Sound 6

216 255 Program 7 / Sound 7

2 Program speed 000 250 Speed, slow to fast

251 255 Sound Active Mode

3 Dimmer (All PAR) 000 255 0–100%

PAR 1

Manual color

control

000 005 Red, 0–100%

5 006 250 Green, 0–100%

6 251 255 Blue, 0–100%

7 000 255 UV, 0–100%

8Strobe 000 005 No Strobe

006 250 Strobe, slow to fast

Sound 251 255 Sound-active strobe

PAR 2

Manual color

control

000 005 Red, 0–100%

10 006 250 Green, 0–100%

11 251 255 Blue, 0–100%

12 000 255 UV, 0–100%

13 Strobe 000 005 No Strobe

006 250 Strobe, slow to fast

Sound 251 255 Sound-active strobe

PAR 3

Manual color

control

000 005 Red, 0–100%

15 006 250 Green, 0–100%

16 251 255 Blue, 0–100%

17 000 255 UV, 0–100%

18 Strobe 000 005 No Strobe

006 250 Strobe, slow to fast

Sound 251 255 Sound-active strobe

FXArray Q5 QRG Rev. 1

QUICK REFERENCE GUIDE

30Ch (cont.)

CHANNEL FUNCTION VALUE PERCENT/SETTING

PAR 4

Manual color

control

000 005 Red, 0–100%

20 006 250 Green, 0–100%

21 251 255 Blue, 0–100%

22 000 255 UV, 0–100%

23 Strobe 000 005 No Strobe

006 250 Strobe, slow to fast

Sound 251 255 Sound-active strobe

PAR 5

Manual color

control

000 005 Red, 0–100%

25 006 250 Green, 0–100%

26 251 255 Blue, 0–100%

27 000 255 UV, 0–100%

28 Strobe 000 005 No Strobe

006 250 Strobe, slow to fast

Sound 251 255 Sound-active strobe

29 SMD Control

Manual color

000 005 Blackout

006 021 R

022 037 G

038 053 B

054 069 GB

070 101 RB

102 117 RG

118 133 RGB

Auto and Sound

Active programs

134 149 Program 1 / Sound 1

150 165 Program 2 / Sound 2

166 181 Program 3 / Sound 3

182 197 Program 4 / Sound 4

198 213 Program 5 / Sound 5

214 229 Program 6 / Sound 6

230 245 Program 7 / Sound 7

246 255 Program 8 / Sound 8

30 Strobe control 000 250 Strobe, slow to fast

251 255 Sound-active strobe

QUICK REFERENCE GUIDE

FXArray Q5 QRG Rev. 1

10Ch

CHANNEL FUNCTION VALUE PERCENT/SETTING

1 Auto and Sound Active Programs

000 005 Blackout

006 040 Program 1 / Sound 1

041 075 Program 2 / Sound 2

076 110 Program 3 / Sound 3

111 145 Program 4 / Sound 4

146 180 Program 5 / Sound 5

181 215 Program 6 / Sound 6

216 255 Program 7 / Sound 7

2 Program speed 000 250 Speed, slow to fast

251 255 Sound Active Mode

3 Dimmer (All PAR) 000 255 0–100%

PAR 1

Manual color

control

000 005 Red, 0–100%

5 006 250 Green, 0–100%

6 251 255 Blue, 0–100%

7 000 255 UV, 0–100%

8Strobe 000 005 No Strobe

006 250 Strobe, slow to fast

Sound 251 255 Sound-active strobe

9SMD Control

Manual color

000 005 Blackout

006 021 R

022 037 G

038 053 B

054 069 GB

070 101 RB

102 117 RG

118 133 RGB

Auto and Sound

Active programs

134 149 Program 1 / Sound 1

150 165 Program 2 / Sound 2

166 181 Program 3 / Sound 3

182 197 Program 4 / Sound 4

198 213 Program 5 / Sound 5

214 229 Program 6 / Sound 6

230 245 Program 7 / Sound 7

246 255 Program 8 / Sound 8

10 Strobe control 000 250 Strobe, slow to fast

251 255 Sound-active strobe

FXArray Q5 QRG Rev. 1

QUICK REFERENCE GUIDE

3Ch

CHANNEL FUNCTION VALUE PERCENT/SETTING

1 Auto and Sound Active Programs

000 005 Blackout

006 040 Program 1 / Sound 1

041 075 Program 2 / Sound 2

076 110 Program 3 / Sound 3

111 145 Program 4 / Sound 4

146 180 Program 5 / Sound 5

181 215 Program 6 / Sound 6

216 255 Program 7 / Sound 7

2 Program speed 000 250 Speed, slow to fast

251 255 Sound Active Mode

3 Dimmer (All) 000 255 0–100%

GUÍA DE REFERENCIA RÁPIDA

FXArray Q5 GRR Rev. 1

Acerca de esta guía

La Guía de referencia rápida (GRR) del FXArray Q5 contiene información básica sobre el producto, como montaje,

opciones de menú y valores DMX. Descargue el manual de usuario de www.chauvetdj.com para una información más

detallada.

Exención de responsabilidad

La información y especificaciones contenidas en esta GRR están sujetas a cambio sin previo aviso.

Notas de seguridad

Estas notas de seguridad incluyen información importante sobre el montaje, uso y mantenimiento.

Contacto

Fuera de EE. UU., Reino Unido, Irlanda, México o Benelux póngase en contacto con su distribuidor para solicitar

asistencia o devolver un producto. Visite www.chauvetdj.com para información de contacto.

Qué va incluido

• FXArray Q5

• Cable de alimentación

• Tarjeta de garantía

• Guía de referencia rápida

Para empezar

Desembale su FXArray Q5 y asegúrese de que ha recibido todas las partes en buen estado. Si la caja o los

componentes parecen dañados, notifíqueselo inmediatamente al transportista, no a Chauvet.

• Este producto no está concebido para una instalación permanente.

• Conecte este producto SOLO a un circuito con toma de tierra y protegido.

• Desconecte siempre de la alimentación antes de la limpieza o sustitución del fusible.

• NO mire a la fuente de luz cuando el producto esté encendido.

• Asegúrese de que el cable de alimentación no está retorcido ni estropeado.

• Nunca desconecte este producto de la alimentación tirando del cable.

• Cuando monte este producto en alto, use un cable de seguridad.

• NO permita la presencia de materiales inflamables cerca de la unidad cuando esté en

funcionamiento.

• NO toque este producto cuando esté en funcionamiento, pues podría estar caliente.

• La tensión del enchufe al que conecte este producto ha de estar en el rango establecido en el

grabado o en el panel posterior del producto.

• ¡Este producto es para uso en interiores solamente! (IP20) Para evitar riesgos de incendio o

descarga, no exponga este producto a la lluvia o la humedad.

• Monte siempre este producto en una ubicación con ventilación adecuada, al menos a 20 in (50

cm) de superficies adyacentes.

• Asegúrese de que ninguna ranura de ventilación en la carcasa de la unidad queda bloqueada.

• Nunca conecte este producto a un atenuador o reostato.

• Sustituya el fusible con uno del mismo tipo y categoría.

• Use SOLAMENTE los soportes de colgar/montar o las asas para mover este producto.

• La temperatura ambiente máxima es de 104 °F (40 °C). No haga funcionar este producto a

temperaturas más altas.

• En caso de un problema grave de funcionamiento, deje de usarlo inmediatamente.

• NO abra este producto. No contiene piezas reparables por el usuario.

• Para evitar un desgaste innecesario y alargar su vida útil, desconecte completamente el producto

mediante el interruptor o desenchufándolo durante periodos en que no se use.

Otros manuales para FXarray Q5

Tabla de contenidos

Idiomas:

Otros manuales de Equipo de DJ de Chauvet

Chauvet

Chauvet Rogue R1 FX-B Manual de usuario

Chauvet

Chauvet EPIX Drive 2000 IP Manual de usuario

Chauvet

Chauvet Mini Kinta Manual de usuario

Chauvet

Chauvet COLORado 1 VW Manual de usuario

Chauvet

Chauvet Mini Strobe Led Manual de usuario

Chauvet

Chauvet MotionFacade LED Manual de usuario

Chauvet

Chauvet Maverick Silens 2 Profile Manual de usuario

Chauvet

Chauvet Precision ZX-20LQ Manual de usuario

Chauvet

Chauvet colorband PiX IP Manual de usuario

Chauvet

Chauvet SlimPACK 56 Manual de usuario

Chauvet

Chauvet Ovation P-56WW Manual de usuario

Chauvet

Chauvet OVATION F-265WW Manual de usuario

Chauvet

Chauvet Nexus Aq 5x5 Manual de usuario

Chauvet

Chauvet CH-31 Manual de usuario

Chauvet

Chauvet Obey 4 D-Fi 2.4 Manual de usuario

Chauvet

Chauvet COREpar 40 USB Manual de usuario

Chauvet

Chauvet LEGEND 250RX Manual del producto

Chauvet

Chauvet Ovation F-415VW Manual de usuario

Chauvet

Chauvet LX 5 Manual de usuario

Chauvet

Chauvet EZ par 64 RGBA Manual de usuario

Chauvet

Chauvet Intimidator SPOT 355Z IRC Manual de usuario

Chauvet

Chauvet FOLLOWSPOT 1200D Manual de usuario

Chauvet

Chauvet Freedom Par Quad-4 IP Manual de usuario

Chauvet

Chauvet Ovation E-910FC Manual de usuario

Manuales populares de Equipo de DJ de otras marcas

ALPHA LITE

ALPHA LITE ALPHA 1500 Manual del propietario

Zumtobel

Zumtobel APHRODITE Home Manual de usuario

Snow Masters

Snow Masters Zig Oscillator Manual de usuario

EuroLite

EuroLite 50530554 Manual de usuario

Beamz

Beamz BUV243 Manual de usuario

thomann

thomann Stairville DJ Lase 40-G MK-III Manual de usuario

Eagletone

Eagletone 6 Eyes Flower Manual de usuario

EuroLite

EuroLite FLD-1508 Manual de usuario

Technical Pro

Technical Pro LG8xSEA Manual de usuario

JB Systems

JB Systems Lounge Laser DMX Manual de usuario

Lightmaxx

Lightmaxx Vega Halo 90 Manual de usuario

Elation

Elation FUZE WASH Z350 Manual de usuario

Maverick

Maverick MK3 WASH Manual de usuario

Infinity

Infinity TF-260C7 Fresnel Manual de usuario

Eliminator Lighting

Eliminator Lighting E 138 Manual de usuario

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manual de usuario

KAM

KAM DMX Laser80 FScan Manual de usuario

Eurotherm

Eurotherm LED TMH-X18 Manual de usuario
