3S-16S LiFePO4 battery Monitor and Saver BM16LF V3.0
www. hargery. om
page 5 total 7
Program setup
Before driving your e-bike or e-s ooter et ., you an
set up many important parameters prevent your
battery from over harge, over dis harge, over
differen e of ell voltage, under battery gauge or
over temperature.
1. Conne t your battery to BM16LF
2. Press SET button for 3 se onds enter into
Program Setup menu.
3. Press UP or DOWN button sele t the item, press
SET shortly make the value flash, and press UP or
DOWN hange the value. Press SET button
shortly onfirm the hange. After finish all setup,
press SET for 3 se onds quit the setup menu.
4. When quit setup mode, the devi e will remember
all parameters till next hange.
NOTE:
Please keep the default setup unless for special purpose.
Program etup
OVER CHG. VOL.
OVER DHG. VOL.
OVER DIFF. VOL.
WHEN ALARM
OVER TEMP.
SOC
BACK-LIGHT TIME
Set up over charge warning voltage range 3.40~3.90V per ell, step
0.05V, default 3.70V. During harge, when any ell voltage over the value,
the unit will alarm.
Set up maximal cell voltage difference range 0.010~0.500V, step
0.005V, default 0.050V. When ell voltage differen e between any two
ells is larger than the value, the unit will alarm.
Set up over discharge warning voltage range 2.00~3.50V per ell,
step 0.05V, default 3.00V. During driving, when any ell voltage under the
value, the unit will alarm.
Set up Battery temperature range 30~80℃
℃℃
℃ step 1℃, default 50℃.
During driving, when battery temperature over the value, the unit will
alarm.
SOC (State of Charge) range is 5~90% step 1%, default 30%. During
driving, when SOC under the value, the unit will alarm.
Set up LCD ba k-light time range 1, 5, 10,20min and always ON,
default 5 min. when LCD ba k-light ON time rea h setup value, it will turn
off, and press any button to resume.
Set up how to output on
Alarm port when any warning events happen.
“ON” means the Alarm port will output logi LOW, and “OFF” means HIGH.
