Chamberlain KLIK3U-BK2 Manual de usuario

MODEL KLIK3U-BK2

MODEL KLIK3U-SS

MODEL KLIK5U-BK2

MODEL KLIK5U-SS

UNIVERSAL REMOTE CONTROL

Your remote control can be programmed to operate

up to two devices, such as a garage door opener,

gate operator, or commercial door operator and has

a SMART/ LEARN button. Each button on the

remote control works independently of the other

and must be programmed separately. The images

throughout this manual are for reference only and

your product may look different.

STOP

Read instructions thoroughly

BEFORE beginning. If you are using

this product with residential door

openers, this product must be used

only with door openers manufactured

starting January 1, 1993 that use photoelectric

sensors located near the bottom of the door track.

IMPORTANT: The remote will activate your door or

gate during programming. Be sure the door is clear

of ALL obstructions. Start with the garage door

closed. Make sure the garage door opener has a

working light because it is a programming indicator.

WARNING: This product can expose you

to chemicals including lead, which are

known to the State of California to cause

cancer or birth defects or other reproductive harm.

For more information go to

www.P65Warnings.ca.gov

GETTING STARTED

Determine if the product you are programming the

remote control to has a SMART/LEARN button or

DIP Switches. The SMART/ LEARN button or DIP

Switches are located either on the product or in an

external receiver on or near the product. The

following instructions are for a garage door opener

with a SMART/LEARN Button. For DIP Switch

programming instructions or additional help, see

support.chamberlaingroup.com.

SMART/

LEARN Button

DIP Switch

NOTE: DIP Switch is only available in KLIK3U

models.

PROGRAM TO GARAGE DOOR OPENERS

WITH A YELLOW LEARN BUTTON

If your remote was previously programmed to

another type of opener, follow the programming

instructions on the next page to reprogram to a

yellow LEARN button.

Yellow

LEARN

Button

LED

1. Start with the garage door closed.

2. Press and immediately release the yellow

LEARN button. The Learn LED glows steady

for 30 seconds. Within 30 seconds...

3. Press and hold the button on the remote

control you wish to use.

4. Release the button when the garage door

opener lights blink or two clicks are heard.

5. Test by pressing the button you just

programmed. The opener activates.

To program the remote to Chamberlain accessories,

refer to the manual provided with the accessory.

PROGRAM TO COMPATIBLE GARAGE

DOOR OPENERS

LED

Program

Button

Cover

SMART/

LEARN

Button

1. Start with the garage door closed.

2. Remove the remote control cover. Press and

hold the program button until the LED turns

on.

3. Press and release the SMART/ LEARN button

on your garage door opener.

4. Select a button to program on the remote

control. Press and release the button the

specified number of times according to the

following chart. NOTE: Make sure the LED

stops flashing between each press of the

button. The garage door opener will respond

by clicking, blinking or activating.

Garage Door

Opener Brand

Type/Color of

SMART/LEARN

button

Year Times to

press

remote

button

Linear®Mega-Code '97-

Current 1

Chamberlain®* Orange/Red '97-'03 2

Chamberlain®* Purple '05-

Current 3

Chamberlain®* Green '93-'96 4

Genie®**

Overhead Door®Intellicode '05-

Current 5

Genie®

Overhead Door®Intellicode '95-

Current 6

Stanley®Secure Code '98 7

Chamberlain®* Yellow '11-

Current 8

Wayne Dalton®Rolling Code '99 9

Xtreme

Garage®***

Guardian®*** Black '05-

Current 10

Sommer*** Black '98-

Current 11

*LiftMaster, Do-It Master Mechanic, Raynor, True Value

and Sears Craftsman are compatible with Chamberlain

technology.

** Find Genie Intellicode II instructions at

support.chamberlaingroup.com.

*** Compatible with KLIK5U-BK2 and KLIK5U-SS only.

5. Press the program button on the remote

control to save.

6. Test by pressing the button you just

programmed. The opener activates.

To program the remote to Chamberlain accessories,

refer to the manual provided with the accessory.

BATTERY

To prevent possible SERIOUS INJURY or

DEATH:

• NEVER allow small children near batteries.

• If battery is swallowed, immediately notify

doctor.

To reduce risk of fire, explosion or chemical

burn:

• Replace ONLY with 3V CR2032 coin

batteries.

• DO NOT recharge, disassemble, heat above

212°F (100°C) or incinerate.

Dispose of batteries properly.

Replace ONLY with 3V CR2032 coin batteries.

NEED HELP?

Go to support.chamberlaingroup.com for more

information.

NOTICE: This device complies with part 15 of

the FCC rules and Innovation, Science and

Economic Development Canada license-exempt

RSSs. Operation is subject to the following two

conditions: (1) This device may not cause

harmful interference, and (2) this device must

accept any interference received, including

interference that may cause undesired

operation. Any changes or modification not

expressly approved by the party responsible for

compliance could void the user's authority to

operate the equipment.

All trade names used herein are trademarks of

respective manufacturers listed.

114-5461-000C

MODÈLE KLIK3U-BK2

MODÈLE KLIK3U-SS

MODÈLE KLIK5U-BK2

MODÈLE KLIK5U-SS

TÉLÉCOMMANDE UNIVERSELLE

Votre télécommande peut être programmée pour

activer jusqu’à deux dispositifs, comme un ouvre-

porte de garage, et est dotée d’un bouton

INTELLIGENT/D’APPRENTISSAGE. Chaque

bouton sur la télécommande fonctionne

indépendamment l’un de l’autre et doit être

programmé séparément. Les illustrations de ce

manuel ne sont fournies qu’à titre de référence;

votre produit peut avoir une apparence différente.

ARRÊT

Lire attentivement les instructions

AVANT de commencer. Si ce produit

est utilisé avec des ouvre-portes de

garage résidentiels, il ne peut l’être

qu’avec des ouvre-portes fabriqués à

partir du 1erjanvier 1993 qui utilisent des capteurs

photoélectriques situés près du bas du rail de la

porte.

IMPORTANT: La télécommande activera la porte

ou barrière pendant sa programmation. S’assurer

que la porte est libre de TOUTE obstruction.

Commencer alors que la porte du garage est fermée

Vérifier que l’ouvre-porte de garage est muni d’une

ampoule en bon état, parce qu’elle sert d’indicateur

de programmation.

AVERTISSEMENT : Ce produit peut

vous exposer à des produits chimiques

comme le plomb, reconnu par l’État de la

Californie comme cause de cancers, d’anomalies

congénitales et d’autres problèmes liés à la

reproduction. Pour plus d’information, visitez

www.P65Warnings.ca.gov

POUR COMMENCER

Déterminer si le produit qui sera programmé à la

télécommande est doté d’un bouton

intelligent/d’apprentissage (SMART/LEARN) ou de

commutateurs DIP. Le bouton

INTELLIGENT/D’APPRENTISSAGE ou les

COMMUTATEURS DIP sont situés sur le produit ou

dans un récepteur extérieur ou encore, à proximité

du produit. Les instructions suivantes servent à

programmer un ouvre-porte de garage à l’aide d’un

bouton intelligent/d’apprentissage

(SMART/LEARN). Pour les instructions de

programmation de commutateur DIP ou pour

obtenir une assistance supplémentaire, voir

support.chamberlaingroup.com.

Le bouton INTELLIGENT/

D’APPRENTISSAGE

Les COMMUTATEURS DIP

REMARQUE: Le commutateur DIP est offert

uniquement sur les modèles KLIK3U .
