Chamberlain MC100AML Manual de usuario

The Universal Garage Door Opener Remote

Control can be programmed to operate up to two

motors. Each button on the remote control works

independently of the other and must be

programmed separately.

The images throughout this manual are for

reference only and your product may differ from

the images shown.

MC100AML

UNIVERSAL GARAGE DOOR OPENER

REMOTE CONTROL

To prevent possible SERIOUS INJURY or DEATH from a

moving door:

ALWAYS keep remote controls out of reach of children. NEVER permit

children to operate or play with remote control transmitters.

•

Activate a door ONLY when it can be seen clearly, is properly adjusted

and there are no obstructions.

•

ALWAYS keep a door in sight until completely closed. NEVER permit

anyone to cross the path of a moving door or gate.

•

To prevent possible SERIOUS INJURY or DEATH:

NEVER allow small children near batteries.•

If a battery is swallowed, immediately notify a Doctor.•

To reduce the risk of fire, explosion or chemical burn:

Replace ONLY with 3V CR2032 coin batteries.•

DO NOT recharge, disassemble, heat above 100 C or incinerate.•

Dispose of batteries properly.

BATTERY

CR2032 Battery

Screw

•

Replacing the battery:

Visit chamberlaindiy.com.au/universal or chamberlaindiy.co.nz/universal

for up to date information on the models that the universal remote is

compatible with.

The Universal Garage Door Opener Remote Control is compatible

with:

Brand Code Type Frequency

HomEntry Rolling 433.30/433.92/434.54MHz

Chamberlain

433.92MHz

Chamberlain Security+ 433.92MHz

Chamberlain

ATA

ATA TrioCode 433.47/433.92/434.37MHz

B&D TriTran 433.47/433.92/434.37MHz

Avanti Rolling 433.92MHz

Boss Fixed 433.92MHz

Merlin Security+2.0

Merlin Security+

B&D TriTran+ 433.47/433.92/434.37MHz

ATA

Merlin Legacy 433.92MHz

Security+2.0

Billion

433.30/433.92/434.54MHz

433.92MHz

SecuraCode

TrioCode128

433.92MHz

433.47/433.92/434.37MHz

COMPATIBILTY TABLE

Australia 1800 638 234 or chamberlaindiy.com.au/universal

New Zealand 0800 653 667 or chamberlaindiy.co.nz/universal

CUSTOMER SERVICE

TEST

Test the remote control by pressing the button you programmed to control

the door. If the garage door opener does not activate, repeat the

programming steps or visit chamberlaindiy.com.au/universal or

chamberlaindiy.co.nz/universal for additional instructions.

PROGRAMMING THE REMOTE

Start with your garage door closed. Ensure that the door is clear of all

obstructions.

Press and hold the bottom button on

the remote control until the blue LED

on the remote stays solid (approximately

15 seconds), then release the button.

Press and hold the LEARN button on your garage door opener for 2-3

seconds before releasing it (refer to the diagram on page 4 for

where the LEARN button may be located).

On the remote control, press and release the remote button you would

like to program. The blue LED will blink for up to 60 seconds. Once the

LED changes to solid blue press and release the button on the remote

that you are programming.

The remote will begin flashing once every three seconds. Once the door

begins moving press the remote button again. Your remote is now

programmed to the garage door opener.

You can repeat this process using the other remote button to program

another garage door opener.

LED

Bottom

Button

These are generic instructions for most garage door openers, however you

may need to refer to the instructions for your opener if your remote does

not program.

Note: Please read through all steps before programming the remote.

For ATA branded openers, please refer to the instructions on page 5.

LOCATING THE LEARN BUTTON

Australia 1800 638 234 or chamberlaindiy.com.au/universal

New Zealand 0800 653 667 or chamberlaindiy.co.nz/universal

CUSTOMER SERVICE

Learn Button

Indicator LED

DN UP PS

123

Learn Button

Examples of where the LEARN button may be located on the opener:

The LEARN button may also be labelled as PROGRAM, CODE SET,

DOOR CODE, RADIO SET, ‘S’ or similar on your garage door opener.

Sectional & Tilt Door Openers

Roller Door Openers

Start with your garage door closed. Ensure that the door is clear of all

obstructions

Press and hold the bottom button on the

remote until the blue LED stays

solid (after approximately 15 seconds),

then release the button.

Press and hold the CODE SET button on the opener until the completion

of this step.

On the remote, press and release the remote button that you would like

to program. The blue LED on the remote will blink for up to 60 seconds.

Once the remote LED changes to solid blue release the CODE SET

button on the opener and press and release the remote button you are

programming.

The remote will begin flashing once every three seconds. Once the door

begins moving press the remote button again. Your remote is now

programmed to the garage door opener.

You can repeat this process using the other remote button to program

another garage door opener.

ATA BRANDED OPENERS

These programming instructions are for ATA branded garage door openers.

Note: Please read through all steps before programming the remote.

LED

Bottom

Button

TEST

Test the remote control by pressing the button you programmed to control

the door. If the garage door opener does not activate, repeat the

programming steps or visit chamberlaindiy.com.au/universal or

chamberlaindiy.co.nz/universal for additional instructions.

How do I program the other button on the Universal Remote Control?

After pressing the LEARN button on the motor, go through the same

programming method using the other button. This process will not over

write the first button. The initial 15 second press to put the remote into

learn mode must be performed using the bottom button.

How do I erase previous codes and start fresh?

Codes cannot be erased, only overwritten. A newly programmed code

will take the place of a previous code.

The remote control is not working, the LED is not illuminating.

The LED is also a power indicator, pressing a button on the remote should

cause the LED to illuminate. If the LED does not illuminate after you press

the button, replace the battery using a CR2032 battery.

How can I stop one button from operating two doors?

If one remote control button is operating two doors, you must clear the

memory of the garage door opener that you do not want the button to

activate.

Where is the LEARN button located on my opener?

The LEARN button can either be found on the garage door opener or on an

external receiver. To locate the receiver look for an antenna, some receivers

will require a cover be removed to gain access to the LEARN button.

The LEARN button is often a different colour to the other buttons, and may

be labelled as PROGRAM, CODE, SET, DOOR CODE, RADIO SET or

similar. Refer to your garage door opener manual for information on its

location.

Is my garage door opener compatible with the Universal Remote

Control?

Check the compatability table located on page 2 or for the most up to date

table visit chamberlaindiy.com.au/universal or chamberlaindiy.co.nz/universal.

If I change the battery in the remote control, will I have to reprogram it?

The remote control should retain its memory. If it does not, you will need to

reprogram it.

FREQUENTLY ASKED QUESTIONS

Chamberlain Australia Pty Limited / Chamberlain New Zealand

(Chamberlain), warrants to the original consumer purchaser of this product

that it is free from defect in materials and/or workmanship for a period of 1

year from the date of purchase.

The benefits given to you under this Chamberlain Limited Warranty are in

addition to any rights and remedies that you may have under Australian or

New Zealand consumer protection laws. Our goods come with guarantees

that cannot be excluded under the Australian Consumer Law, or New

Zealand Consumer Guarantees Act 1993.

You are entitled to a replacement or refund for a major failure and for

compensation for any other reasonably foreseeable loss or damage. You are

also entitled to have the goods repaired or replaced if the goods fail to be of

acceptable quality and the failure does not amount to a major failure.

All trade names used herein are trademarks of respective manufacturers listed.

114A4938C

ONE YEAR LIMITED WARANTY
