Cervis 302 Series Manual de usuario

CERVIS RADIO CONTROL

TROUBLESHOOTING GUIDE

FOR 302 AND 5 SERIES M ACHINES

TO TURN THE REM OTE ON,

PUSH GREEN BUTTON ON BACK OF REM OTE AND RELEASE.

302/ 5 SERIESREM OTE

THIS GUIDE APPLIES TO 302 & 5 SERIES M ACHINES

IF THE “TX” & “RX” LEDS FLASH 10 TIM ES PER SECOND, REM OTE IS SYNCHED TO M ACHINE,

M ACHINE HAS POW ER AND IS READY TO USE.

TURN REM OTE ON

DOES THE “ TX” LED FLASH 10 TIM ES PER SECOND?

IF YES, REM OTE IS READY TO USE, CONTINUE TO RECEIVER TROUBLESHOOTING SECTION.

IF NOT, CONTINUE REM OTE TROUBLESHOOTING.

THIS GUIDE APPLIES TO 302 & 5 SERIES M ACHINES

CHECK REM OTE

IF NO LED ILLUM INATE AT ALL, CHECK BATTERIESFIRST.

INSTALL NEW BATTERIESPAYING ATTENTION TO DIAGRAM IN BATTERY COM PARTM ENT.

BATTERIES ARE NOT ARRANGED IN TYPICAL “UP, DOW N, UP, DOW N” ORDER.

IF LI GHT S DO NOT COM E ON AFT ER REPLACI N G

BATT ERI ES, AN D RESTART I N G REM OT E, RET U RN REM OT E

FOR SERV I CE.

STEP 1

THIS GUIDE APPLIES TO 302 & 5 SERIES M ACHINES

TROUBLESHOOT REM OTE

LEDs ARE FLASHING IN REPEATING PATTERN.

TX AND RX FLASH

TOGETHER, FIRST

THEN, ERR AND BATT

FLASH TOGETHER

THIS ERROR INDICATES A SWITCH IS STUCK. CHECK ALL SWITCHES ARE IN THE CENTER

POSITION. M OVE ALL SWITCHES UP AND DOWN AND RELEASE.

HOLDING THE GREEN POW ER BUTTON TOO LONG, CAN CAUSE THIS TO

HAPPEN. LET GO OF GREEN POW ER BUTTON AND SEE IF PROBLEM GOES

AW AY.

IF PROBLEM CON T I N U ES AFT ER

CHECK I N G ALL SWI TCH ES,

RET U RN REM OT E FOR SERV I CE.

STEP 2

THIS GUIDE APPLIES TO 302 & 5 SERIES M ACHINES

TROUBLESHOOT REM OTE

LIGHTS FLASHING IN REPEATING PATTERN.

TX AND ERR FLASH

TOGETHER, FIRST

THEN, RX AND BATT

FLASH TOGETHER

THIS ERROR INDICATES THE ESTOP BUTTON IS NOT IN THE UP POSITION. RELEASE ESTOP

BY ROTATING RED BUTTON, GENTLY CLOCKWISE. IF BUTTON POPS UP RETRY TO POWER

UP REM OTE.

IF PROBLEM CON T I N U ES AFT ER

BU T TON I S I N T H E U P POSIT I ON ,

RET U RN REM OT E FOR SERV I CE.

STEP 3

THIS GUIDE APPLIES TO 302 & 5 SERIES M ACHINES

TROUBLESHOOT REM OTE

IF TX LED ISFLASHING ON REM OTE, IT IS SENDING OUT INFORM ATION.

IF M ACHINE IS POWERED UP AND RX LED IS NOT FLASHING ON REM OTE, THE M ACHINE

RECEIVER AND REM OTE ARE NOT COM M UNICATING.

#1 LED

IF POWER I S APPLI ED AND POWER LED I S N OT LIT, THERE I S A FAU LT

WIT H T H E RECEI V ER; RET U RN T H E RECEI V ER TO TH E FACTORY FOR

EVALUAT ION

RECEIVER POWER LED SHOULD BE LIT.

IF NOT, CHECK FOR 12 VOLT POWER AT

BATTERY, KEY SWITCH, HARNESS, AND

M ODULE PLUG.

STEP 1

THIS GUIDE APPLIES TO 302 & 5 SERIES M ACHINES

302/ 5 SERIES RECEIVER

TROUBLESHOOT RECEIVER

#3 LED

IS THE “ HEALTH” LED FLASHING GREEN, ONCE PER SECOND?

NO:

IF THE HEALTH LED IS OUT OR IS LIT STEADY, THE M AIN

M ICROCONTROLLER HAS STALLED.

IF THE HEALTH LED IS FLASHING RAPIDLY, THERE IS A M EM ORY

FAULT WITH THE RECEIVER.

RET U RN RECEI V ER FOR SERV I CE

IF HEALTH LED FLASHES TWICE THEN PAUSES FOR 2.5 SECONDS

AND REPEATS , THE RECEIVER IS RESETTING.

CONTINUE TO STEP: 3, PAGE 7

IF THE “ HEALTH” LED IS FLASHING GREEN, ONCE PER SECOND

CONTINUE TO STEP: 4, PAGE 10

STEP 2

THIS GUIDE APPLIES TO 302 & 5 SERIES M ACHINES

TROUBLESHOOT RECEIVER

KEYPAD

IF THE RECEIVER KEEPS RESETTING:

DO KEYPAD BUTTONSFLASH ORANGE WHEN POWER IS

APPLIED?

NO: CHECK POWER WIRING TO KEYPAD

IF WIRING IS DAM AGED—REPAIR WIRING

IF WIRING IS OKAY— REPLACE K EY PAD

RETURN TO STEP: 2

YES: CHECK CAN BUS WIRING TO KEYPAD CONTROLLER

CAN BUS WIRING ISDAM AGED—REPAIR WIRING

WIRING ISOKAY— REPLACE K EY PAD

RETURN TO STEP: 2

STEP 3

THIS GUIDE APPLIES TO 302 & 5 SERIES M ACHINES

TROUBLESHOOT RECEIVER

STEP 4

IS RX/ TX LIGHT FLASHING AM BER?

NO IT ISFLASHING RED, TX ONLY ISACTIVE:

POSSIBLE CAUSES:

1. REM OTE AND RECEIVER ARE NOT ASSOCIATED

FOLLOW DIRECTIONS TO RESYNCH REM OTE AND RECEIVER

2. INTERFERENCE

M OVE BARKBLOWER OR REM OTE AWAY FROM BUILDINGSOR

CHAINLINK FENCES

3. ANTENNA OR CABLE ARE BROKEN/ DAM AGED

REPLACE BROKEN/ DAM AGED ANTENNA OR CABLE

#4 LED

THIS GUIDE APPLIES TO 302 & 5 SERIES M ACHINES

TROUBLESHOOT RECEIVER
