Instruction

Manual

Para instrucciones en Español,

llamar al: 1-800-837-4044

www.centuryproducts.com

PM-1458AB 6/01 Avoid injury or death -

Read and understand this manual!

TABLE OF CONTENTS

Important Information.....................................1

Warnings.........................................................2

Basic Information.............................................4

Vehicle Seat Belts........................................... 14

• Locking Clip........................................ 19

Additional Information ...................................20

• Installation of Anchor Hardware . .

• Tether Storage

• Care and Cleaning

• Aircraft Use

• Second Hand Car Seat

Instruction manual is for:

• Ovation 5-Point Infant/Toddler Car Seat

• Ovation Overhead Infant/Toddler Car Seat

• Encore 5-Point Infant/Toddler Car Seat

• Encore Overhead Infant/Toddler Car Seat

Instructions for these models are the same unless

otherwise noted.

❃Before You Begin

❃Use

❃Special Information

Height & Weight Limits...................................5

Rear-facing Installation....................................6

Forward-facing Installation..............................7

Placing Child in Car Seat.................................8

Operations and Adjustments......................... 10

• Harness Straps

• Harness Tie

• Overhead Shield Adjustment

• Buckle

IMPORTANT INFORMATION

No car seat can guarantee protection from

injury in every situation, but proper use helps

reduce the risk of serious injury or death.

Child restraints (car seats) could be recalled for

safety reasons. You must register this restraint

to be reached in a recall. Fill out the

registration card attached to car seat and mail

today or send your name, address, and the

restraint’s model number and manufacturing

date to:

Century Products

P.O. Box 551

Elverson, PA 19520-9973

or call 1-888-224-6549

For recall information:

• Call the U.S Government’s Auto Safety

Hotline at 1-800-424-9393

(202-366-0123 in D.C. area)

• www.nhtsa.dot.gov

• Call Century Products at 1-800-837-4044

✔Read and understand instruction manual

and car seat labels.

✔Infants less than 20 lbs. (9.1 kg) must use

car seat rear-facing.

✔Do not use car seat rear-facing in vehicle seat

with air bag.

✔Secure children in back seat whenever

possible.

✔Never leave child unattended.

✔Install car seat securely.

✔Do not use after date shown on back of

car seat.

✔Do not allow anyone (babysitter, relatives,

etc.) to use car seat without first

understanding all instructions.

❃Registration Information

❃Safety First Check List

WARNINGS - Prevent serious injury or death:

DO NOT use rear-facing child

restraint in a vehicle seating

position equipped with an air bag.

Child’s head and neck may be

seriously injured when an inflating

air bag hits back of child restraint.

Never put a car seat in a front

vehicle seat unless recommended by

vehicle owner’s manual. National

Highway Traffic Safety

Administration (NHTSA) alerts

vehicle owners that according to

accident statistics, children up to

age 12 are safer in the back seat.

For vehicles with air bags, refer to

vehicle owner’s manual for child

restraint installation information.

If car seat is in a crash, it must be

replaced. DO NOT use it again! A

crash can cause unseen damage and

using it again could result in serious

injury or death.

Failure to follow these instructions

and car seat labels can result in child

striking the vehicle’s interior during

a sudden stop or accident. Secure

child restraint with a vehicle seat

belt as shown in this manual.

Infants less than 20 lbs. (9.1 kg)

must use this car seat rear-facing.

Serious crippling injury or death can

result if infant faces front of vehicle.

Vehicle seat belt system MUST hold

car seat securely. Not all vehicle seat

belts can be used with a car seat. If

vehicle seat belt does not hold car

seat securely, read “Vehicle Seat

Belts” section.

DO NOT use car seat if it is damaged

or has missing parts.

DO NOT use accessories or parts

other than those provided by

Century or Graco. Their use could

alter the performance of the

car seat.

Rear-facing car seat must be

properly leveled:

• Too reclined can result in injury

or ejection.

• Too upright can result in

breathing difficulties.

Never leave child unattended, even

when sleeping. Child may become

tangled in harness straps and

suffocate.

WARNINGS - Prevent serious injury or death (continued):

BASIC INFORMATION

This car seat meets or exceeds all applicable

requirements of Federal Motor Vehicle Safety

Standard 213 for use in motor vehicles and

aircraft.

Always secure car seat with a vehicle seat belt,

even when unoccupied. An unsecured car seat

can injure passengers.

Protect vehicle seat. Use a car seat mat, towel

or thin blanket under and behind car seat.

Car seat parts can get very hot in the sun or

warm weather.

To avoid burns, always check before putting

child in car seat.

Do not use car seat on rear-facing or

side-facing vehicle seats.

❃Certification ❃Unoccupied Car Seat

DO NOT use after date shown on back of

car seat due to changing requirements and

normal wear and tear.

Look for: Do not use this car

seat after December Year

❃Car Seat Useful Life

❃Dangerous Vehicle Seats ❃Vehicle Seat Protection

❃Warm Weather

Rear-facing: Birth to 30 lbs. (13.6 kg)

• Infants from birth to 20 lbs. (9.1 kg) MUST

be rear-facing.

• Infants or toddlers 20 to 30 lbs. (9.1 to

13.6 kg) may be rear-facing.

HEIGHT & WEIGHT LIMITS

A preterm infant or low birth weight infant may

be at special risk in a vehicle or aircraft.

According to the American Academy of

Pediatrics, these infants may suffer breathing

difficulties if improperly reclined in a car seat.

Century advises that you have your physician or

hospital staff evaluate your infant and

recommend the proper car seat or car bed

before you and your infant leave the hospital.

❃Preterm or Low Birth Weight

Infants

Forward-facing

Forward-facing: 20 to 40 lbs. (9.1 to 18.1 kg)

• Toddlers 20 to 30 lbs. (9.1 to 13.6 kg) who

are capable of sitting upright unassisted

may be forward-facing *. If unable to sit

unassisted, use rear-facing.

• Toddlers 30 to 40 lbs. (13.6 to 18.1 kg)

and up to 40 inches (101.6 cm) tall MUST

be forward-facing.

❃Outgrowing Car Seat

Rear-facing 40 lbs.

(18.1 kg)

Birth 30 lbs.

(13.6 kg)

20 lbs.

(9.1 kg)

To avoid injuries from whiplash, top of

child’s ears must be below top edge of

car seat.

WARNING

IMPORTANT: The Ovation/Encore car seat has

been certified for use rear-facing with children

up to 30 lbs. (13.6 kg). However, some

children approaching 30 lbs. (13.6 kg) may be

too tall to fit comfortably rear-facing. When

child can no longer comfortably fit and knees

remain bent, child should use car seat

forward-facing only if child is over 20 lbs.

(9.1 kg) and can sit upright unassisted *.

*The American Academy of Pediatrics recommends

that children should be at least one year of age

before being positioned forward facing.

Adjust car seat to recline position and place

rear-facing on vehicle seat. DO NOT use

any other position when using rear-facing.

Thread vehicle seat belt through openings and

buckle belt.

Press down firmly in center of car seat to

compress vehicle seat cushion while tightening

vehicle seat belt (fig. a).

Pull front to back and left to right to check for

secure installation (fig. b). Vehicle lap belt

MUST stay tight.

If not secure, see “Vehicle Seat Belts” section.

Check level indicator on car seat.

Ball MUST be entirely in green zone (fig. c). If

necessary place rolled towels under front of

car seat at vehicle seat crease.

NOTE: Vehicle must be on level

ground and child in car seat

when using level indicator.

REAR-FACING INSTALLATION

6(fig. a) (fig. b) (fig. c)

Openings

Towels

Adjust car seat to upright or semi-upright position

and place forward-facing on vehicle seat.

Lift seat pad flap and panel.

Thread vehicle seat belt through openings, behind

panel and buckle belt (fig. a).

Press down firmly in center of car seat to compress

vehicle seat cushion while tightening vehicle seat

belt.

HINT: Use your knee to press down in center of

car seat (fig. b).

Pull front to back and left to right to check for

secure installation (fig. c). Vehicle lap belt

MUST stay tight.

If not secure, see “Vehicle Seat Belts” section.

Attach tether strap clip (A) to anchor hardware (B)

and tighten strap to remove any slack (fig. d).

If tether anchor is not available, see “Installation of

Anchor Hardware“ section.

FORWARD-FACING INSTALLATION

(fig. a) (fig. b) (fig. c)

Openings

(fig. d)

(B)

(A)

Pull to

tighten

Place child in car seat with child’s back flat

against back of car seat.

Place harness straps over child’s shoulders and

insert tongue (s) into buckle.

Pull up on tongue (s) to be sure it is locked.

Close harness tie:

Position harness tie at arm pit level.

Adjust harness straps to be snug with just

enough room to insert one finger between

child’s chest and harness straps (fig. a).

For 5-Point models, check that harness straps

on chest and thighs are snug.

A rolled towel can be used on each side to

support small children (fig. b). Be sure towels

do not interfere with harness system.

To prevent serious injury or death:

• Keep harness straps snug and

positioned on shoulders.

• Do not use strap covers, blankets,

cushions, or padding under harness

straps or child.

• Child must be dressed in clothing with

arms and legs that will not interfere

with buckling harness.

PLACING CHILD IN CAR SEAT

WARNING

Check harness system:

•Rear-facing - Harness straps must be

through bottom or middle slots at or just

below shoulders.

•Forward-facing - Harness straps must be

through top slots.

Overhead Shield Models Only:

• Harness tongue must be in opening

closest to but not under child.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Asiento de coche de Century

Century

Century Brevessa Transit Manual de usuario

Century

Century assura series Manual de usuario

Century

Century PM-1378AB Manual de usuario

Century

Century SmartMove Manual de usuario

Century

Century STE 1000 Manual de usuario

Century

Century Next Step Deluxe Series Manual de usuario

Century

Century SmartFit Plus 22 Manual de usuario

Century

Century SMART MOVE PM-1634AB 6/01 Manual de usuario

Century

Century BREVERRA PM-1435AB Manual de usuario

Century

Century ISPC008BA 08/02 Manual de usuario

Century

Century Breverra Classic Premiere Series Manual de usuario

Century

Century Accel SE 5-Point 45100 Manual de usuario

Century

Century Drive On Manual de usuario

Century

Century 1000 STETM Manual de usuario

Century

Century 44164 Manual de usuario

Century

Century ISPB008BC 1/03 Manual de usuario

Century

Century 44164 Manual de usuario

Century

Century Breverra Ascend Series Manual de usuario

Century

Century 3-Point Manual de usuario

Century

Century STE Manual de usuario

Century

Century ISPB009BA Manual de usuario

Century

Century Bravo Manual de usuario

Century

Century PM-1373AD Manual de usuario

Century

Century 44892L Manual de usuario

Manuales populares de Asiento de coche de otras marcas

Britax

Britax PARKWAY SGL Manual de usuario

JANE

JANE nurse cruiser Manual de usuario

Digicom

Digicom Tippy Pad Manual de usuario

Fisher-Price

Fisher-Price Futura 20/60 Manual de usuario

Giordani

Giordani orion 012 Manual de usuario

BRIO

BRIO ZENTO Manual de usuario

Combi

Combi Zeus Turn 8815 Series Manual de usuario

Graco

Graco Car Booster Seat Manual de usuario

Coccolle

Coccolle Atira Manual de usuario

hifold

hifold HF01-GL Manual de usuario

CYBEX

CYBEX SOLUTION X2-FIX Manual de usuario

kiwy

kiwy SLF 123 Manual de usuario

Safety 1st

Safety 1st Summit ISO 30 Manual de usuario

Safety 1st

Safety 1st Grand 2-IN-1 Manual de usuario

Graco

Graco NAUTILUS Manual de usuario

Britax

Britax Multi-Tech BB0-702-00 Manual de usuario

Grammer

Grammer MSG45/421 Instrucciones de funcionamiento

Nuna

Nuna REBL PLUS Manual de usuario

Century ovation encore Manual de usuario

Manuales populares de Asiento de coche de otras marcas
