Consider all cabling requirements and routing as in Figure 9. (IM page

14)

CABLING REQUIREMENTS

OPERATOR INSTALLATION

Figure 1 Gate Opening Angle Diagram

110

120

100 o

90 o

(Gate opening angle)



Check for the safety and suitability of the site by looking at: (IM page

13)

All safety and local authority requirements.

That the gate is within the operator specifications.

Check that there is enough ground clearance to enable assembly

of the drivearm clamps. (See Figure 4)

Estimate the gate swing angle with figure 1.

Then mark the operator’s position according to figure 2 or 3.

(IM page 15)

Check that you have all the tools required. (IM page 12)

1REQUIRED TOOLS & EQUIPMENT

SITE CONSIDERATIONS

All manuals and user guides at all-guides.com

100

79 158

110

Ensure that the gate does not exceed the

relevant specifications (IM page 9)

Only recommended values are provided. For

variances, refer to the Installation Manual.

All dimensions shown are indicated in millimetres.

All recommended values will result in gates with

similar opening times.



Gate Bracket

Gate Opening

Angle (Degrees)

60 7000

130

220

355

570

605

750

700

600

450

70 700

80 700

90 700

100 650

110

120

610

570

Figure 2 Standard Pedestal Mount Installation

B E S U R E T O U S E A L O N G

C O N N E C T I N G A R M F O R T H I S

INSTALLATION TYPE.

GATE LEAF IN CLOSED POSITION



Drive Arm D

see Fig. 6

158

Pedestal

50mm

GATE LEAF IN OPEN POSITION

Pedestal Mount

Installation

STANDARD PEDESTAL MOUNT

Gate Bracket CH

All manuals and user guides at all-guides.com

Ensure that the gate does not exceed the relevant specifications (IM page 9)

Only recommended values are provided. For variances, refer to the Installation Manual.

All dimensions shown are indicated in millimetres.

All recommended values will result in gates with similar opening times.

Figure 3 Standard Wall Mount Installation

BE SURE TO USE A SHORT CONNECTING ARM FOR

THIS INSTALLATION TYPE.

Drive Arm D see Fig. 6



Gate Opening

Angle (Degrees)

210

305

380

485

140

180

100

110

120

140

180

140

Wall Mount

Installation

PERPENDICULAR WALL MOUNT

GATE LEAF IN CLOSED POSITION



Gate Bracket C

100

272

110

Gate Bracket

700

610

700

All manuals and user guides at all-guides.com

5MOUNT THE GATE BRACKET AND

DETERMINE PEDESTAL HEIGHT

PEDESTAL MOUNT INSTALLATION

Locate a suitable place for mounting the gate bracket according to

dimension “C” in the tables of Figures 2 or 3.

Determine pedestal or wall mount bracket height relative to gate

bracket as in figure 4 and 5. (IM page 21)

Mount the gate bracket.

Minimum 125mm to allow for

drive arm clamp assembly

C (See Fig. 2)

37mm

Figure 4 Pedestal/Gate Bracket vertical position

300mm sqr

500mm

Concrete

Pedestal

Cabling

85mm

Gate

Bracket

All manuals and user guides at all-guides.com

C (See Fig. 3)

Wall

Bracket

Gate Bracket

Minimum 125mm to allow for

drive arm clamp assembly

WALL MOUNT INSTALLATION

37mm

Figure 5 Wall/Gate Position

6ROUTE CABLES & SECURE MOTOR

Route cables as determined in the cabling plan in Figure 9.

Make sure at least 400mm of cable protrudes above the pedestal or

wall mount bracket. (IM page 22)

All manuals and user guides at all-guides.com

all-guides.com

8CUT DRIVE ARM TO LENGTH

CUT DRIVEARM TO LENGTH

7FASTEN GEARBOX IN POSITION

Fasten the motor onto the pedestal adaptor plate or the wall bracket

using the M8 bolts and washers supplied. (IM page 23)

Using the relevant tables below, read off the required drive arm

length.

Then cut the drivearm 50mm longer than D, as shown in Figure 6.

Drivearm (D) + 50

Drivearm (D)



Standard

Pedestal Mount

Drivearm

Perpendicular

Wall Mount

Drivearm

D D

Gate Opening

Angle (Degrees)

60 325

430

370

470

490

480

470

100

110

120

480

500

250

300

350

420

Figure 6 Cut Drive Arm Length

Connecting Arm

Cut drivearm length=D+50mm

Drivearm

All manuals and user guides at all-guides.com

Put the gearbox into manual mode. (IM page 24).

Fit the drive arm to the operator as shown.

ASSEMBLE CLAMP TO DRIVE ARM

Clamp

Drive Arm

M12 Washer

Wedge

To mount: push clamp onto drive shaft,

tap into place, slide drive arm into clamp,

slip wedge in and fasten with bolt and

washer.

M12 x 65 Bolt

9FIT THE DRIVE ARM

Figure 7 Assemble Clamp to Drive Arm

Clamp

Drive Arm

M12 x 65 Bolt

M12 Washer

Wedge

0.07.A.0146_22072013

All manuals and user guides at all-guides.com

SET THE CONNECTING ARM LENGTH

Loosen the connecting arm slightly and move it to its fully retracted

position.

Open the gate ½ way.

Assemble the connecting arm to the gate bracket.

Now slowly push the gate to its closed position. (The drive arm will

turn, and the connecting arm will extend while doing so)

Check that the hinge points of the gate bracket, connecting arm and

motor output shaft are in a straight line as shown in Figure 8.

Carefully unhook the connecting arm from the gate bracket and

tighten lightly.

Check the gate opens and closes sufficiently by manually operating

the gate.



Fully tighten connecting arm.

Apply the warning decals supplied to either side of the gate frame.

IF THE GATE OPENS TOO LITTLE

IF THE GATE OPENS TOO MUCH

Lengthen the drivearm by 10 mm and readjust the connecting arm.

Shorten the drivearm by 10 mm and readjust the connecting arm.

NB. Hinge points must be in a

straight line when gates are closed

GATE LEAF IN CLOSED POSITION

Figure 8 Align Gates

ALIGNMENT OF HINGE POINTS

All manuals and user guides at all-guides.com

ELECTRICAL SET-UP

WARNING

1. Always check that the circuit breaker in the electrical panel is in the

OFF position, and that all high voltage circuits (more than 42.4V) are

completely isolated from the mains supply before doing any work.

2. Ensure that all low voltage systems (Less than 42.4V) are suitably

protected from damage, by disconnecting all sources of power such

as chargers and batteries before doing any work.

3. All electrical work must be carried out according to the requirements

of all applicable local electrical codes.(It is recommended that a

licensed electrical contractor perform such work.)

CONNECT ALL WIRING

Connect all cables as required to the control card and battery

charger (See Figure 11 & 12). (IM page 48 & 49)

Check that the power source jumper is in the correct position. (PSU

or STD refer to IM page 27, Fig. 24)

Figure 9 Cabling Requirements

To dwelling

Isolator

Box

All manuals and user guides at all-guides.com
