Centsys VECTOR2 Manual de usuario
VECTOR2 installation manual
LINEAR
SWING GATE
OPERATORS
Company ProfileCompany Profile
CENTURION SYSTEMS (Pty) Ltd reserves the right to make changes to the products described in this manual without notice
and without obligation of CENTURION SYSTEMS (Pty) Ltd to notify any persons of any such revisions or changes.
Additionally, CENTURION SYSTEMS (Pty) Ltd makes no representations or warranties with respect to this manual.
No part of this document may be copied, stored in a retrieval system or transmitted in any form or by any means electronic,
mechanical, optical or photographic, without the express prior written consentof CENTURION SYSTEMS (Pty) Ltd
Sales and technical support
to over 50 countries
worldwide
100%
testing to
specifications
In-house
R & D
development
team
Manufacture to
international
quality standard
ISO 9001:2008
1986 1990 1995 1999
Competent
after-sales
technical support
CENTSYS
today
Contents
CENTURION SYSTEMS (Pty) Ltd. reserves the right to make changes to the products described in this manual without notice and without
obligationof CENTURIONSYSTEMS (Pty)Ltd. tonotify anypersons ofany suchrevisions orchanges. Additionally,CENTURION SYSTEMS
(Pty)Ltd.makesnorepresentationsorwarrantieswithrespecttothismanual.
No part of this document may be copied, stored in a retrieval system or transmitted in any form or by any means electronic, mechanical,
opticalorphotographic,withouttheexpresspriorwrittenconsentofCENTURIONSYSTEMS(Pty)Ltd.
page 1
Page 2
page 2
page 3
Mechanical Setup
Commissioning and handover
IMPORTANT SAFETY INSTRUCTIONS
1. Declaration of conformity
2. General description page 6
Lightning protection page 7
3. Icons used in this booklet 7
4. Specifications 8
Physical dimensions PAGE 8
Control card page 10
Power supply page 10
5. Product identification 12
6. Required tools & equipment 14
7. Preparation of site 15
General considerations for the installation
8. Cabling requirements 19
9. Operator installation 21
Determine the gate bracket position
10. Determine gate swing angle 30
11. Allowable wind loading 26
12. Electrical Setup page 33
Secure control box to wall
Connecting all wiring
13. Wiring diagram for closing safety beam 35
15. Wiring diagram for external radio receiver and loop detector
Electrical Setup
page 5
page
page
Power supply, wall box and control card assembly page 10
Allowable gate mass page 10
page
page
page
page 15
Strength of the pillar page 16
Strength of the gate and gate bracket page 17
The Mechano Kit page 18
page
page
page 22
Adjust origin clamp page 24
Inward swing gate Setup page 25
Outward swing gate Setup page 28
page
page
page 33
page 33
Setting the Limits page 34
page
14. Wiring diagram for opening safety beam page 36
page page 37
16. Wiring diagram for other inputs page 38
17. Wiring diagram for Master motor (MTRM) page 39
18. Wiring diagram for Slave motor (MTRS) page 40
19. Charger and Pillar Light connections page 41
page
page
page
page
page
page
page 61
page
page
page
page
20. Setting up additional features 42
21. Menu navigation map 43
22. Controller features 44
23. Factory defaults schedule 56
24. Description of terminal functions 58
25. Diagnostics 61
Diagnostic LEDs
Gate status LEDs 61
LCD display 62
Buzzer feedback 63
26. Installation handover 64
Check cabling requirements
Mechanical setup
Gather required tools and equipment Page 14
Heed necessary site considerations Page 15
Page 19
Mount the wall bracket Page 22
Install motor and link to gate Page 22
Set limit switches and/or fit
mechanical endstops Page 34
These quick steps are for the experienced installer who needs
a checklist to get a standard installation up and running in the
minimum of time.
Detailed installation features and functions are referred to
later in this manual.
Page 1
Electrical setup
Page 2
Commission system
Commissioning
and handover
Carry out professional handover to
client
Mount controller enclosure and
connect all wiring Page 33
Page 64
Page 64
Warnings for the installer
CAREFULLY READ AND FOLLOW ALL INSTRUCTIONS
before beginning to install the product.
All installation, repair, and service work to this product
must be carried out by a suitably qualified person
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety
Do not activate your gate unless you can see it and can
determine that its area of travel is clear of people, pets, or
other obstructions
NO ONE MAY CROSS THE PATH OF A MOVING GATE.
Always keep people and objects away from the gate and its
area of travel
NEVER LET CHILDREN OPERATE OR PLAY WITH THE
GATE CONTROLS
Secure all easily accessed gate opener controls in order to
prevent unauthorised use of the gate
Do not in any way modify the components of the
automated system
Do not install the equipment in an explosive atmosphere:
the presence of flammable gasses or fumes is a serious
danger to safety
Before attempting any work on the system, cut electrical
power to the operator and disconnect the batteries
The mains power supply of the automated system must be
fitted with an all-pole switch with contact opening distance
of 3mm or greater. Use of a 5A thermal breaker with all-
pole circuit break is recommended
!
!
!
!
!
!
!
!
!
!
IMPORTANT
Safety Instructions
ATTENTION
To ensure the safety of people, it is important that you
read all the following instructions. Incorrect
installation or incorrect use of the product could cause
serious harm to people.
The installer, being either professional or DIY, is the
last person on the site who can ensure that the
operator is safely installed, and that the whole system
can be operated safely.
Page 3
!Make sure that an earth leakage circuit breaker with a
thresholdof30mAis fittedupstream ofthe system
!Never short circuit the battery and do not try to recharge the
batteries with power supply units other than that supplied with
theproduct, orby CENTSYS
!Make sure that the earthing system is correctly constructed,
andthat allmetal partsof thesystem aresuitably earthed
!Safety devices must be fitted to the installation to guard
against mechanical movement risks such as crushing,
draggingand shearing
!It is recommended that at least one warning indicator light be
fittedto everysystem
!Always fit the warning signs visibly to the inside and outside of
thegate
!The installer must explain and demonstrate the manual
operation of the gate in case of an emergency, and must hand
theUser/Warningsguide overto the user
!Explain these safety instructions to all persons authorised to
use this gate, and be sure that they understand the hazards
associatedwith automatedgates
!Do not leave packing materials (plastic, polystyrene, etc.)
within reach of children as such materials are potential
sourcesof danger
!Dispose of all waste products like packaging materials, worn
outbatteries, etc,according tolocal regulations
!Always check the obstruction detection system, and safety
devicesfor correctoperation
!CENTSYS does not accept any liability caused by improper use
of the product, or for use other than that for which the
automatedsystem wasintended
!This product was designed and built strictly for the use
indicated in this documentation. Any other use, not expressly
indicated here, could compromise the service life/operation of
theproduct and/orbe asource ofdanger
!Everything not expressly specified in these instructions is not
permitted
Page 4
1. Declaration of conformity
Page 5
2. General description
Page 6
The VECTOR2 operator has been designed to safely and cost-effectively automate a
wide variety of swing gates, from single light-domestic swing gates to heavy industrial
double swing gates.
The fail-safe and fully redundant position and Collision Detection system has been
designed and tested to set the standard in safety of operation and to provide an
unparalleled level of reliability and durability in operation.
The gate Travel Limits are managed by a sealed double-redundant opto-electronic
system that has been designed not only to ensure ultra-reliable operation, but also to
ensure precise position and trajectory control. This enables very accurate and reliable
collision detection to ensure safe operation even under trying conditions.
The VECTOR2 control card has been designed to be easy and intuitive to use with
helpful instructions on the status of the operation during and after the installation. It also
has a built-in diagnostic procedure that can verify every aspect of the control card on
site.
Some of the advanced features offered by the VECTOR2 controller are:
Fully automated single button Limit Setup for single and double swing gates
Full graphics LCD display provides an intuitive user interface with built-in diagnostics
to speed up and simplify the installation process
Separate safety inputs for sensitive edges or beams on both the closing and opening
directions of the gate
Advanced closed-loop speed control to maintain safe and reliable operation on
inclined gates under windy conditions
Fully configurable gate Run Profiles
Selectable and adjustable Autoclose with pushbutton override.
Pedestrian (Partial) opening with automatic closure.
Free-exit input
Positive Close Mode
Multiple Modes of Operation
Solenoid lock drive output up to 2A
Holiday Lockout
A status LED output to indicate the gate status remotely
Pillar Light control
Leaf delay selectable for either gate leaf
Onboard CENTSYS receiver with selective adding and deleting of remotes
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
