TEXTURE PAINT SPRAY GUN

66103

SET UP AND OPERATING INSTRUCTIONS

Distributed exclusively by Harbor Freight Tools®.

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our website at: http://www.harborfreight.com

Read this material before using this product.

Failure to do so can result in serious injury.

SAVE THIS MANUAL.

contained herein may be reproduced in any shape or form without the express written consent of

Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing

improvements, actual product may differ slightly from the product described herein. Tools required for

assembly and service may not be included.

For technical questions or replacement parts, please call 1-800-444-3353.

SKU 66103 For technical questions, please call 1-800-444-3353. Page 2

SAVE THIS MANUAL

Keep this manual for the safety warn-

ings and precautions, assembly, operat-

ing, inspection, maintenance and cleaning

procedures. Write the product’s serial

number in the back of the manual near the

assembly diagram (or month and year of

purchase if product has no number). Keep

this manual and the receipt in a safe and

dry place for future reference.

Safety Alert Symbol and Signal

Words

In this manual, on the labeling,

and all other information provid-

ed with this product:

This is the safety alert

symbol. It is used to alert

you to potential personal

injury hazards. Obey all

safety messages that

follow this symbol to avoid

possible injury or death.

DANGER indicates

a hazardous

situation which, if not

avoided, will result in death or

serious injury.

WARNING

indicates a

hazardous situation which, if

not avoided, could result in

death or serious injury.

CAUTION, used

with the safety

alert symbol, indicates a

hazardous situation which, if

not avoided, could result in

minor or moderate injury.

NOTICE is used to

address practices

not related to personal injury.

CAUTION, without

the safety alert

symbol, is used to address

practices not related to

personal injury.

IMPORTANT SAFETY

INSTRUCTIONS

INSTRUCTIONS PERTAINING

TO A RISK OF FIRE,

ELECTRIC SHOCK, OR

INJURY TO PERSONS

WARNING – When using this Texture

Paint Spray Gun, basic precautions

should always be followed, including:

General

a. To reduce the risks of electric

shock, re, and injury to persons,

read all the instructions before us-

ing.

Work area

a. Keep the work area clean and well

lighted. Cluttered benches and dark

areas increase the risks of personal

injury.

b. Keep bystanders, children, and

visitors away while operating the

Texture Spray Paint Gun. Distrac-

tions are able to result in the loss of

control.

SKU 66103 For technical questions, please call 1-800-444-3353. Page 3

Personal safety

a. Stay alert. Watch what you are do-

ing and use common sense when

operating. Do not use while tired

or under the inuence of drugs, al-

cohol, or medication. A moment of

inattention while operating increases

the risk of injury.

b. Dress properly. Do not wear loose

clothing or jewelry. Contain long

hair. Keep hair, clothing, and

gloves away from moving parts.

Loose clothes, jewelry, or long hair

increases the risk of personal injury

as a result of being caught in moving

parts.

c. Avoid unintentional starting. Be

sure the switch is off before con-

necting to the air supply. Do not

carry the tool with your nger on the

Spray Gun Trigger, or connect the

tool to the air supply with the Trigger

depressed.

d. Do not overreach. Keep proper

footing and balance at all times.

Proper footing and balance enables

better control in unexpected situa-

tions.

e. Use safety equipment. A

dust mask, non-skid safety

shoes and a hard hat must

be used for the applicable

conditions. Wear heavy-duty work

gloves during use.

f. Always wear eye protec-

tion. Wear ANSI-ap-

proved safety goggles.

g. Always wear hearing

protection when using

the tool. Prolonged expo-

sure to high intensity noise is able to

cause hearing loss.

h. Risk of Electric Shock. This Tex-

ture Spray Paint Gun is not pro-

vided with an insulated gripping

surface. Contact with a ″live″ wire will

also make exposed metal parts of the

tool ″live″ and shock the operator.

i. Avoid body contact with grounded

surfaces such as pipes, radiators,

ranges and refrigerators. There is

an increased risk of electric shock if

your body is grounded.

Tool use and care

a. Do not force the tool. Use the

correct tool for the application. The

correct tool will do the job better and

safer at the rate for which the tool is

designed.

b. Do not use the tool if the switch

does not turn the tool on or off.

Any tool that cannot be controlled

with the switch is dangerous and

must be repaired.

c. Disconnect the tool from the air

source before making any adjust-

ments, changing accessories, or

storing the tool. Such preventive

safety measures reduce the risk of

starting the tool unintentionally. Turn

off and detach the air supply, safely

discharge any residual air pressure,

and release the Gun Trigger before

leaving the work area.

d. Store the idle Texture Paint Spray

Gun out of reach of children and

other untrained persons. A tool is

dangerous in the hands of untrained

users.

SKU 66103 For technical questions, please call 1-800-444-3353. Page 4

e. Maintain the tool with care. Keep

this tool clean. A properly maintained

tool is easier to control.

f. Check for misalignment or bind-

ing of moving parts, breakage of

parts, and any other condition that

affects the tool’s operation. If dam-

aged, have the tool serviced before

using. Many accidents are caused

by poorly maintained tools. There is a

risk of bursting if the tool is damaged.

g. Use only accessories that are

identied by the manufacturer for

the specic tool model. Use of an

accessory not intended for use with

the specic tool model, increases the

risk of injury.

Service

a. Service on this Texture Paint Spray

Gun must be performed only by

qualied repair personnel.

b. When servicing, use only identical,

authorized replacement parts.

Air source

a. Never connect to an air

source that is capable of

exceeding 200 psi. Over

pressurizing the tool may

cause bursting, abnormal operation,

breakage of the tool or serious injury

to persons. Use only clean, dry,

regulated compressed air at the rated

pressure or within the rated pressure

range as marked on the tool. Always

verify prior to using the tool that the

air source has been adjusted to the

rated air pressure or within the rated

air-pressure range.

b. Never use oxygen, carbon dioxide,

combustible gases or any bottled

gas as an air source for the tool.

Such gases are capable of explosion

and serious injury to persons.

SAVE THESE

INSTRUCTIONS.

SYMBOLS AND

SPECIFIC SAFETY

INSTRUCTIONS

Symbol Denitions

Symbol Property or statement

noNo-load speed

.../min Revolutions or reciprocation per

minute

PSI Pounds per square inch of pressure

ft-lb Foot-pounds of torque

BPM Blows per minute

CFM Cubic Feet per Minute ow

SCFM Cubic Feet per Minute ow at

standard conditions

NPT National pipe thread, tapered

NPS National pipe thread, straight

WARNING marking concerning Risk

of Eye Injury. Wear ANSI-approved

eye protection.

WARNING marking concerning Risk

of Hearing Loss. Wear hearing

protection.

WARNING marking concerning Risk

of Respiratory Injury. Wear NIOSH-

approved dust mask/respirator.

Chart continued in next column.

SKU 66103 For technical questions, please call 1-800-444-3353. Page 5

Symbol Denitions

Symbol Property or statement

WARNING marking concerning Risk

of Explosion.

Specic Safety Instructions

1. CAUTION: To prevent serious injury:

a. Do not exceed maximum air pres-

sure of 90 PSI.

b. Do not direct spray at any person, or

animal at any time.

c. Always wear ANSI-approved safety

goggles and breathing respirator

while using.

d. Use coveralls (disposable, or wash-

able) to cover entire body while us-

ing this product.

e. Read entire manual before using this

Texture Paint Spray Gun.

2. The warnings and precautions dis-

cussed in this manual cannot cover

all possible conditions and situations

that may occur. It must be under-

stood by the operator that common

sense and caution are factors which

cannot be built into this product, but

must be supplied by the operator.

3. WARNING: Some dust created by

power sanding, sawing, grinding, drill-

ing, and other construction activities,

contains chemicals known [to the

State of California] to cause cancer,

birth defects or other reproductive

harm. Some examples of these

chemicals are:

• Lead from lead-based paints

• Crystalline silica from bricks and

cement or other masonry products

• Arsenic and chromium from chemi-

cally treated lumber

Your risk from these exposures var-

ies, depending on how often you do

this type of work. To reduce your

exposure to these chemicals: work in

a well ventilated area, and work with

approved safety equipment, such as

those dust masks that are specially

designed to lter out microscopic

particles. (California Health & Safety

Code § 25249.5, et seq.)

WARNING: The brass components

of this product contain lead, a chemi-

cal known to the State of California

to cause birth defects (or other repro-

ductive harm). (California Health &

Safety code § 25249.5, et seq.)

4. Only use with accessories rated to

handle the forces exerted by this tool

during operation. Other accessories

not designed for the forces gener-

ated may break and forcefully launch

pieces.

5. Attach all accessories properly to the

tool before connecting the air sup-

ply. A loose accessory may detach or

break during operation.

6. Install an in-line shutoff valve to allow

immediate control over the air supply

in an emergency, even if a hose is

ruptured.

Vibration Precautions

This tool vibrates during use. Re-

peated or long-term exposure to vibra-

tion may cause temporary or permanent

physical injury, particularly to the hands,

arms and shoulders. To reduce the risk of

vibration-related injury:

1. Anyone using vibrating tools regu-

larly or for an extended period should

rst be examined by a doctor and

then have regular medical check-

SKU 66103 For technical questions, please call 1-800-444-3353. Page 6

ups to ensure medical problems are

not being caused or worsened from

use. Pregnant women or people

who have impaired blood circulation

to the hand, past hand injuries, ner-

vous system disorders, diabetes, or

Raynaud’s Disease should not use

this tool. If you feel any medical or

physical symptoms related to vibra-

tion (such as tingling, numbness, and

white or blue ngers), seek medical

advice as soon as possible.

2. Do not smoke during use. Nico-

tine reduces the blood supply to the

hands and ngers, increasing the risk

of vibration-related injury.

3. Wear suitable gloves to reduce the

vibration effects on the user.

4. Use tools with the lowest vibration

when there is a choice between dif-

ferent processes.

5. Include vibration-free periods each

day of work.

6. Grip tool as lightly as possible (while

still keeping safe control of it). Let

the tool do the work.

7. To reduce vibration, maintain tool as

explained in this manual. If abnormal

vibration occurs, stop immediately.

SAVE THESE

INSTRUCTIONS.

SKU 66103 For technical questions, please call 1-800-444-3353. Page 7

FUNCTIONAL DESCRIPTION

Specications

Operating Air Pressure

Range 25 - 90 PSI

Maximum Air Pressure 90 PSI

Air Inlet 1/4” -18 NPS

Air Consumption 7 CFM @ 25 PSI

Nozzle Size

4 mm (5/32”)

6 mm (15/64”)

8 mm (5/16”)

Hopper Capacity 1.5 gal

INITIAL TOOL SET UP/

ASSEMBLY

Read the ENTIRE IMPORTANT

SAFETY INFORMATION

section at the beginning of this

manual including all text under

subheadings therein before set

up or use of this product.

Note: For additional information regarding

the parts listed in the following pages,

refer to the Assembly Diagram near

the end of this manual.

Unpacking

When unpacking, check to make sure

that the item is intact and undamaged. If

any parts are missing or broken, please

call Harbor Freight Tools at the number

shown throughout the manual as soon as

possible.

• This air tool may be shipped with a

protective plug covering the air inlet.

Remove this plug before set up.

Air Supply

TO PREVENT

EXPLOSION:

Use only clean, dry, regulated,

compressed air to power this

tool. Do not use oxygen,

carbon dioxide, combustible

gases, or any other bottled

gas as a power source for this

tool.

Note: The use of an in-line air and water

separator installed between the lter

and the regulator is recommended.

1. Attach an air hose to the compres-

sor’s air outlet. Connect the air hose

to the air inlet of the tool. Other com-

ponents, such as a connector and

quick coupler, will make operation

more efcient, but are not required.

WARNING! TO PREVENT SERIOUS

INJURY FROM ACCIDENTAL

OPERATION:

Do not install a female quick

coupler on the tool. Such a coupler

contains an air valve that will allow

the air tool to retain pressure and

SKU 66103 For technical questions, please call 1-800-444-3353. Page 8

operate accidentally after the air

supply is disconnected.

Note: Air ow, and therefore tool perfor-

mance, can be hindered by under-

sized air supply components.

2. The air hose must be long enough

to reach the work area with enough

extra length to allow free movement

while working.

3. Make sure the tool’s throttle or switch

is in the off position; refer to Opera-

tion section for description of con-

trols.

4. Close the in-line safety valve be-

tween the compressor and the tool.

5. Turn on the air compressor according

to the manufacturer’s directions and

allow it to build up pressure until it

cycles off.

6. Adjust the air compressor’s output

regulator so that the air output is

enough to properly power the tool,

but the output will not exceed the

tool’s maximum air pressure at any

time. Adjust the pressure gradually,

while checking the air output gauge

to set the right pressure range.

7. Inspect the air connections for leaks.

Repair any leaks found.

8. If the tool will not be used at this

time, turn off and detach the air sup-

ply, safely discharge any residual air

pressure, and release the throttle

and/or turn the switch to its off posi-

tion to prevent accidental operation.

Note: Residual air pressure should not be

present after the tool is disconnected

from the air supply. However, it is a

good safety measure to attempt to

discharge the tool in a safe fashion

after disconnecting to ensure that the

tool is disconnected and not pow-

ered.

OPERATING INSTRUCTIONS

Read the ENTIRE IMPORTANT

SAFETY INFORMATION

section at the beginning of this

manual including all text under

subheadings therein before set

up or use of this product.

Inspect this Texture Spray Paint

Gun before use, looking for

damaged, loose, and missing

parts. If any problems are

found, do not use tool until

repaired.

Tool Set Up

TO PREVENT

SERIOUS INJURY

FROM ACCIDENTAL

OPERATION:

Turn off the tool, detach the

air supply, safely discharge

any residual air pressure in

the tool, and release the

throttle and/or turn the switch

to its off position before

performing any inspection,

maintenance, or cleaning

procedures.

TO PREVENT SERIOUS

INJURY:

Do not adjust or tamper with

any control or component in a

way not specically explained

within this manual. Improper

adjustment can result in

tool failure or other serious

hazards.

SKU 66103 For technical questions, please call 1-800-444-3353. Page 9

Work Piece and Work Area Set Up

1. This Texture Paint Spray Gun is

meant for spraying heavy viscos-

ity products like rubberized decking

materials, texture coatings for interior

and exterior walls, heavy water proof-

ing materials, and the like. It is not

recommended for regular wall paint

or thin coatings of any type. While

these products can be used with this

Spray Gun, the results would not be

satisfactory, or even in coverage.

2. Designate a work area that is clean

and well-lit. The work area must not

allow access by children or pets to

prevent injury and distraction.

3. Route the air hose along a safe route

to reach the work area without creat-

ing a tripping hazard or exposing the

air hose to possible damage. The air

hose must be long enough to reach

the work area with enough extra

length to allow free movement while

working.

4. There must not be utility lines or

foreign objects nearby while working

that may present a hazard.

General Operating Instructions

1. Attach the Plastic Hopper (20) to the

top of the Gun Body (03) and tighten

the Hopper Clip (21) until the Plastic

Hopper is held securely in place.

2. Have an assistant pour the Texture

Paint mix into the top of the Plastic

Hopper lling no more than 3/4 full.

3. Turn on the air compressor and set

the air regulator between 25 and 90

PSI.

4. Using two hands, one to steady the

Plastic Hopper and the other to oper-

ate the Texture Paint Spray Gun, aim

the Spray Gun Nozzle at the surface

to be covered. NOTE: It may take a

few times to mix the proper spray

solution. Do not ll the Plastic

Hopper until you have achieved

the viscosity you need for each

job.

5. Squeeze the Gun Trigger (14) and

move the Texture Paint Spray Gun

in a back and forth motion, releasing

the Gun Trigger at the end of each

sweep.

6. If the product you are attempting to

spray either sputters, or stops spray-

ing, small adjustments in product

control may be made using the Fluid

Control Knob (8F), thinning the prod-

uct batch you are working with, or us-

ing a larger nozzle. NOTE: Nozzles

can be interchanged by un-thread-

ing the Nozzle attached to the

Spray Gun Body and threading on

a different sized Nozzle.

7. CAUTION: Do not stop for extended

periods when spraying. Most of the

products you are using are fast-dry

materials and will start to set-up and

dry as soon as they come in contact

with the air. If you need to discon-

tinue spraying for more than half an

hour, turn off the air supply, discon-

nect the Plastic Hopper from the Gun

Body and thoroughly rinse the Plastic

Hopper and Gun Body with fresh,

clear, water. The products you are

using can set-up quickly and if not

cleared from your equipment may

render that equipment unusable.

SKU 66103 For technical questions, please call 1-800-444-3353. Page 10

8. When you are completely nished or

are stopping for the day, disconnect

and empty the Plastic Hopper. Flush

the system with fresh cold water.

Rinse and clean the Plastic Hop-

per and the Gun Body and let both

dry completely before storing inside,

away from children.

9. If the tool requires more force to

accomplish the task, verify that the

tool receives sufcient, unobstructed

airow (CFM) and increase the

pressure (PSI) output of the regulator

up to the maximum air pressure

rating of this tool.

CAUTION! TO PREVENT TOOL

AND ACCESSORY FAILURE,

RESULTING IN INJURY:

Do not exceed the tool’s maximum

air pressure rating.

If the tool still does not have sufcient

force at maximum pressure and

sufcient airow, then a larger tool

may be required.

USER-MAINTENANCE

INSTRUCTIONS

Procedures not specically

explained in this manual

must be performed only by a

qualied technician.

TO PREVENT

SERIOUS INJURY

FROM ACCIDENTAL

OPERATION:

Turn off the tool, detach the

air supply, safely discharge

any residual air pressure in

the tool, and release the Gun

Trigger before performing any

inspection, maintenance,

nozzle changes, or cleaning

procedures.

TO PREVENT SERIOUS

INJURY FROM TOOL

FAILURE:

Do not use damaged

equipment. If abnormal

noise, vibration, or leaking

air occurs, have the problem

corrected before further use.

Cleaning, Maintenance, and

Lubrication

Note: These procedures are in addition to

the regular checks and maintenance

explained as part of the regular op-

eration of the air-operated tool.

1. Daily - Air Supply Maintenance:

Every day, perform maintenance on

the air supply according to the com-

ponent manufacturers’ instructions.

Performing routine maintenance on

the air supply will allow the tool to

operate more safely and will also

reduce wear on the tool.
